Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Socket connectors,
insulation displacement connection, pitch 3.5 | BLIDC 3.5 | BLIDC 3.5 SN
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Conductor connection system
Outgoing direction of conductor
Pitch
Pitch in inch
No. of poles
No. of rows
Screwdriver blade
Screwdriver blade standard
L1 in mm
L1 in inch
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
1750880000
BLIDC 3.5/11 SN OR
PCB plug-in connector, Female connectors, IDC
terminal, Clamping range, max.: 0.5 mm², Pitch:
3.50 mm, No. of poles: 11, 90°/180°, Box
4032248146185
50 pc(s).
IDC terminal
90°/180°
3.5 mm
0.138 inch
11
1
0.4 x 2.5
DIN 5264-A
35 mm
1.378 inch
IP 20
Safe from finger touch
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Socket connectors,
insulation displacement connection, pitch 3.5 | BLIDC 3.5 | BLIDC 3.5 SN
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Connectable conductors
Clamping range, min.
Clamping range, max.
AWG, min.
AWG, max.
Outer diameter of insulation, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor (field wiring), min.
AWG conductor (field wiring), max.
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor, min.
AWG conductor, max.
PBT
orange
Similar to RAL 2000
IIIa
V-0
>= 200
CuSn
tinned
0.32 mm²
0.5 mm²
22
20
2.1 mm
0.2 mm²
0.5 mm²
0.2 mm²
0.5 mm²
6A
6A
6A
5A
320 V
160 V
160 V
2.5 kV
2.5 kV
2.5 kV
3 x 1s with 60 A
300 V
7A
22
20
300 V
7A
22
20
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Socket connectors,
insulation displacement connection, pitch 3.5 | BLIDC 3.5 | BLIDC 3.5 SN
Approvals
Approvals institutes
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1750790000
1770940000
1750800000
1750810000
1750820000
1750830000
1750840000
1750850000
1750860000
1750870000
1750890000
Part designation
BLIDC 3.5/2 SN OR
BLIDC 3.5/2 SN SW
BLIDC 3.5/3 SN OR
BLIDC 3.5/4 SN OR
BLIDC 3.5/5 SN OR
BLIDC 3.5/6 SN OR
BLIDC 3.5/7 SN OR
BLIDC 3.5/8 SN OR
BLIDC 3.5/9 SN OR
BLIDC 3.5/10 SN OR
BLIDC 3.5/12 SN OR
Version
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 2, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 2, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 3, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 4, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 5, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 6, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 7, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 8, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 9, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 10, 90°/180°,
Box
PCB plug-in connector, Female connectors, IDC terminal, Clamping
range, max.: 0.5 mm², Pitch: 3.50 mm, No. of poles: 12, 90°/180°,
Box
-3-
