MLCC Tin/Lead Termination “B”
General Specifications
AVX Corporation will support those customers for commercial and military Multilayer Ceramic
Capacitors with a termination consisting of 5% minimum lead. This termination is indicated by
the use of a “B” in the 12th position of the AVX Catalog Part Number. This fulfills AVX’s
commitment to providing a full range of products to our customers. AVX has provided in the
following pages a full range of values that we are currently offering in this special “B” termination.
Please contact the factory if you require additional information on our MLCC Tin/Lead
Termination “B” products.
Check for up-to-date CV Tables at
http://www.avxcorp.com/docs/Catalogs/tinterm.pdf
HOW TO ORDER
LD05
Size
LD02 - 0402
LD03 - 0603
LD04 - 0504
LD05 - 0805
LD06 - 1206
LD08 - 1808*
LD10 - 1210
LD12 - 1812
LD13 - 1825
LD14 - 2225
LD15 - 0204 LICC*
LD16 - 0306 LICC
LD17 - 0508 LICC
LD18 - 0612 LICC
5
Voltage
6.3V = 6
10V = Z
16V = Y
25V = 3
50V = 5
100V = 1
200V = 2
A
Dielectric
C0G (NP0) = A
X7R = C
X5R = D
101
Capacitance
Code (In pF)
2 Sig. Digits +
Number of
Zeros
J
Capacitance
Tolerance
A
Failure
Rate
A = Not
Applicable
B
Terminations
B = 5% min lead
2
Packaging
2 = 7" Reel
4 = 13" Reel
7 = Bulk Cass.
9 = Bulk
A
Special
Code
A = Std. Product
B
C
D
F
G
J
K
=
=
=
=
=
=
=
±.10 pF (<10pF)
±.25 pF (<10pF)
±.50 pF (<10pF)
±1% (≥ 10 pF)
±2% (≥ 10 pF)
±5%
±10%
Contact
Factory
For
Multiples
*Contact factory
NP0 Dielectric
SIZE
Cap
(pF)
WVDC
0.5
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
