Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | TOP 4GS/6.35 | TOP
4GS/90-6.35
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Product family
Conductor connection system
Fitted to PCB
Outgoing direction of conductor
Pitch
Pitch in inch
No. of poles
Fitted by customer
No. of rows
Solder pin length
Dia. of fitting hole
Fitting hole tolerance
No. of solder pins per pole
Screwdriver blade
Tightening torque, min.
Tightening torque, max.
Clamping screw
Stripping length
L1 in mm
L1 in inch
Material data
Insulating material
Colour
colour chart
1786030000
TOP4GS4/90 6.35 OR
PCB terminal, TOP connection, Soldered
connection, Clamping range, max.: 6 mm², Pitch:
6.35 mm, No. of poles: 4, 90°, Box
4032248200665
50 pc(s).
System TOP4GS
TOP connection
Soldered connection
90°
6.35 mm
0.25 inch
4
no
1
3.5 mm
1.3 mm
+ 0.1 mm
2
0.6 x 3.5
0.5 Nm
0.6 Nm
M3
13 mm
19.05 mm
0.75 inch
PA
orange
Similar to RAL 2000
-1-
Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | TOP 4GS/6.35 | TOP
4GS/90-6.35
Material data
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Storage temperature, min.
Storage temperature, max.
Connectable conductors
Clamping range, min.
Clamping range, max.
AWG, min.
AWG, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
With wire end ferrule, acc. to DIN 46 228/1, min.
With wire end ferrule, acc. to DIN 46 228/1, max.
w. plastic collar ferrule, DIN 46228 pt 4, min.
w. plastic collar ferrule, DIN 46228 pt 4, max.
Gauge to EN 60999 a x b; ø
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor (field wiring), min.
AWG conductor (field wiring), max.
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
AWG conductor, min.
AWG conductor, max.
I
V-2
>= 600
E-Cu
tinned
-25 °C
55 °C
0.13 mm²
6 mm²
26
10
0.5 mm²
6 mm²
0.5 mm²
4 mm²
0.5 mm²
4 mm²
0.5 mm²
4 mm²
2.8 mm x 2.4 mm;
32 A
32 A
320 V
320 V
320 V
2.5 kV
2.5 kV
2.5 kV
300 V
10 A
26
10
300 V
10 A
26
10
-2-
Product catalogue | PCB connection systems | PCB terminals | TOP screw connection | TOP 4GS/6.35 | TOP
4GS/90-6.35
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
TOP 4GS.LIB
NK
EC001284
NK
NK
NK
Similar products
Order No.
1401760000
1650300000
1786040000
1786050000
1786060000
1667910000
1786070000
1786080000
1786090000
1786100000
Part designation
TOP4GS2/90 6.35 OR
TOP4GS3/90 6.35 OR
TOP4GS5/90 6.35 OR
TOP4GS6/90 6.35 OR
TOP4GS7/90 6.35 OR
TOP4GS8/90 6.35 OR
TOP4GS9/90 6.35 OR
TOP4GS10/90 6.35 OR
TOP4GS11/90 6.35 OR
TOP4GS12/90 6.35 OR
Version
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 2, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 3, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 5, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 6, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 7, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 8, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 9, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 10, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 11, 90°, Box
PCB terminal, TOP connection, Soldered connection, Clamping
range, max.: 6 mm², Pitch: 6.35 mm, No. of poles: 12, 90°, Box
-3-
