ELECTRICAL SOLUTIONS
A.
System
Overview
Male Metric Disconnect, Non-Insulated
–
Butted Seam
B1.
Cable Ties
Type DM-M
• Male tab couples with (all 6.3mm x 0.8mm) female disconnects
• Male tab can be inserted and removed from the female disconnect
without the use of tools for lower installed cost
• Internal barrel serrations assure good wire contact and maximum
tensile strength
Wire
Range
(mm
2
)
0.5 – 1.0
1.5 – 2.5
4.0 – 6.0
B2.
Cable
Accessories
• Barrel of terminal internally beveled to provide quick and easy
wire insertion
• Maximum recommended operating temperature 302°F (150°C)
• Rated up to 2000 V
Figure Dimensions
(mm)
L
19.2
19.2
18.2
B3.
Stainless
Steel Ties
Part Number
DM1-63M-C
DM2-63M-C
DM6-63M-L*
L
Tab
Size
(mm)
6.3 x 0.8
6.3 x 0.8
6.3 x 0.8
Recommended
Installation
Tool
Std.
Pkg.
Qty.
100
100
50
Std.
Ctn.
Qty.
500
500
250
C1.
Wiring
Duct
CT-1570,
CT-2500
C2.
Surface
Raceway
*Brazed seam.
For crimping tool information, see pages D1.84 and D1.88.
C3.
Abrasion
Protection
Metric Pin Terminal, Vinyl Insulated
–
Funnel Entry
Type PMV-P
• Solid pin designed to prevent damage to the wire from over
tightening, resulting in a reliable electrical connection
• For use with pin-type terminal blocks
• Insulation support helps to prevent wire damage in bending
applications
• Brazed seam protects terminal barrel from splitting during the
crimp process
• Internal barrel serrations assure good wire contact and maximum
tensile strength
• Maximum insulation temperature 221°F (105°C)
• Rated up to 600 V
Color
Code
Red
Blue
Yellow
Max.
Ins.
(mm)
3.80
4.30
6.40
Figure Dimensions
(mm)
L
21.1
21.1
27.9
W
2.0
2.0
2.5
P
11.9
11.9
14.0
Recommended
Installation
Tool
Std.
Pkg.
Qty.
100
100
50
Std.
Ctn.
Qty.
500
500
250
C4.
Cable
Management
D1.
Terminals
Wire
Range
(mm
2
)
0.5 – 1.0
1.5 – 2.5
4.0 – 6.0
D2.
Power
Connectors
Part Number
PMV1-P10-CY
PMV2-P10-C
D3.
Grounding
Connectors
CT-1550,
CT-2500
L
PMV6-P10-L
For crimping tool information, see pages D1.84 and D1.88.
E1.
Labeling
Systems
P
W
Metric Pin Terminal, Non-Insulated
Type PM-P
• Solid pin designed to prevent damage to the wire from over
tightening, resulting in a reliable electrical connection
• For use with pin-type terminal blocks
• Insulation support helps to prevent wire damage in
bending applications
• Brazed seam protects terminal barrel from splitting during the
crimp process
• Internal barrel serrations assure good wire contact and maximum
tensile strength
• Maximum recommended operating temperature 302°F (150°C)
• Rated up to 2000 V
Figure Dimensions
(mm)
L
19.0
19.0
20.1
W
1.8
1.8
2.8
P
12.4
12.4
14.0
Recommended
Installation
Tool
Std.
Pkg.
Qty.
100
100
50
Std.
Ctn.
Qty.
500
500
250
E2.
Labels
E3.
Pre-Printed
& Write-On
Markers
E4.
Permanent
Identification
E5.
Lockout/
Tagout
& Safety
Solutions
F.
Index
Part Number
PM1-P10-C
PM2-P10-C
L
P
Wire
Range
(mm
2
)
0.5 – 1.0
1.5 – 2.5
4.0 – 6.0
CT-1570,
CT-2500
PM6-P10-L
For crimping tool information, see pages D1.84 and D1.88.
W
Order number of pieces required, in multiples of Standard Package Quantity.
Prime items appear in
BOLD.
