Polyester
Film Capacitors
F
EATURES
•
•
•
•
High stability and reliability
Excellent environmental performance
Low equivalent series resistance
Non-inductive construction minimizes dissipation factor
PEN
Series
(Non-Inductive)
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-40
o
C to +85
o
C
0.001μF to 0.47μF
±5%(J), ±10%(K), ±20%(M)
50VDC, 100VDC, 200VDC
0.8% max. at 1KHz, 25
o
C
>20000MΩ (C
≤
0.1μF)
>2000MΩ
μF
(C > 0.1
μF)
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
PEN
682
J
2A
PEN
are constructed with polyester film dielectric,
aluminum foil electrodes, tinned copper lead and a
non-inductive epoxy resin coating. They are ideal
for commercial and industrial use and are
completely noiseless in small signal circuits.
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
Rated Voltage
CODE
1H
50V
2A
100V
2D
200V
Tape & Reel Tape & Ammo available for lead space
Please contact factory for part number
10 mm
Dimensions in millimeters (mm)
RV
DIM.
CAP (μF)
0.0010
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.47
50VDC/100VDC
W
10.0
10.0
10.0
10.0
10.0
10.0
10.0
12.0
12.0
14.0
14.0
14.0
14.0
20.0
20.0
20.0
26.0
H
8.0
8.0
8.0
8.0
8.5
8.5
8.5
9.0
9.0
10.0
11.0
11.0
13.0
14.0
16.0
18.0
21.0
T
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.5
6.0
6.0
6.5
6.5
8.0
8.0
9.0
11.0
11.0
P±
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
8.0±1.0
8.0±1.0
10.0±1.5
10.0±1.5
10.0±1.5
10.0±1.5
16.0±1.5
16.0±1.5
16.0±1.5
21.0±1.5
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
W
10.0
10.0
10.0
10.0
10.0
10.0
12.0
14.0
14.0
14.0
16.0
16.0
20.0
20.0
26.0
26.0
31.0
H
8.0
8.0
8.0
8.0
8.5
8.5
9.0
10.0
11.0
13.0
10.0
12.5
17.0
18.0
21.0
22.0
24.0
200VDC
T
5.0
5.0
5.0
5.0
5.0
5.0
6.0
6.0
6.0
7.0
6.5
7.8
9.0
10.0
10.5
11.5
13.0
P± 1
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
7.0±1.0
8.0±1.0
10.0±1.5
10.0±1.5
10.0±1.5
12.0±1.5
12.0±1.5
15.0±1.5
15.0±1.5
21.5±1.5
21.5±1.5
27.5±1.5
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
rev.6a
Specifications are
subject to change without notice.
