ALUMINUM ELECTROLYTIC CAPACITORS
KG
Lug / Snap-in Terminal Type,
For Audio Equipment
series
Disigned for high grade audio equipment, giving priority to high fidelity sound quality.
The variation expansion of the KG series.
TYPE-1: The low profile high tone quality grade of the new development
electrolyte adoption.
Super Through
TYPE-2: The center grade that the best sound is provided electrode foil,
with the multiple use.
High Grade
TYPE-3: The highest tone quality grade by the low drag the gold plating
terminal adoption.
Gold Tune
The sound quality that it meets the high tone quality needs of the DVD age.
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
–
40 ~ +85°C
Performance Characteristics
16 ~ 100V (TYPE-1
•
TYPE-2), 50~100V (TYPE-3)
680 ~ 33000µF
± 20% at 120Hz, 20°C
After 5 minutes' application of rated voltage, leakage current is not more than
3 CV
(µA), [C:Rated Capacitance(µF),V:Voltage]
Measurement frequency : 120Hz, Temperature : 20°C
TYPE
Rated voltage (V)
tan
δ
tan
δ
TYPE-1
•
TYPE-2
TYPE-3
16
0.35
25
•
63
0.3
80
•
100
0.25
16~100
4
12
50
•
63
0.22
80
•
100
0.2
Rated voltage (V)
Measurement frequency : 120Hz
Stability at Low Temperature
Impedance ratio ZT/Z20(MAX.)
Z—25°C/ Z+20°C
Z—40°C/ Z+20°C
Endurance
After 1000 hours application of rated voltage at 85°C,
capacitors meet the characteristic requirements listed
at right.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
After leaving capacitors under no load at 85°C for 1000 hours, they meet the specified
value for endurance characteristics listed above.
Printed with gold color letter on black sleeve
Type numbering system (Snap-in terminal type)
(Example : Gold Tune 25 V 6800µF, Dia.φ30)
1
2
3
4
5
6
7
8
9 10 11
12
13 14
Type numbering system (Lug terminal type)
(Example : Super Through 50 V 15000µF)
1
2
3
4
5
6
7
8
9 10 11
12
L KG 1 E 6 8 2 MH S B B K
Grade
Grade
Code
TYPE-1(Fine Tune)
AK
TYPE-2(Gold Tune) BK
TYPE-3(Super Through)
CK
Case dia.code
Configuration
φD
20
22
25
30
35
Code
Y
Z
A
B
C
L KG 1 H 1 5 3 ML Z S
Grade
TYPE-1(Fine Tune)
TYPE-2(Gold Tune)
TYPE-3(Super Through)
Code
F
—
S
Grade
Configuration
Capacitance tolerance(±20%)
Rated Capacitance(15000µF)
Rated voltage(50V)
Series name
Type
Capacitance tolerance (±20%)
Rated Capacitance(6800mF)
Rated voltage(25V)
Series name
Type
(Snap-in terminal type)
Polarity bar
Sleeve
0.8
-0.1
+0.2
+0
0.1
0.8
-
.2
10
±
0.1
φD
+1MAX.
10
L±
2
2-2φ±
0.1
(PC board hole dimensions)
6.3±1
3.5
1.5
+0.2
-0.1
(Terminal dimensions)
6.3±1
Pressure relief vent
(Lug terminal type)
Bottom plate
Sleeve
Configuration
φ
35 ~
φ
40
4.5
φ
50~φ 76
8
φD
+2MAX.
P±
1
φD
t=1.0
t=1.0
11
11
35
14
40
14
50
18
63
25
76
25
P
Configuration
L
+3MAX.
LN
LZ
LN
11±2
LZ
Dimension table in next page.
Wider range of rating.
CAT.8100R
