2 Watt
o Pi Input Filter
o Regulated Output
o Single & Dual Output
o Short Circuit Protection
24 Pin DIL Package V
o 1000 VDC I/O-Isolation
2000 VDC I/O-Isolation add Suffix „H2“
3000 VDC I/O-Isolation add Suffix „H3“
4000 VDC I/O-Isolation add Suffix „H4“
5200 VDC I/O-Isolation add Suffix „H5“
6000 VDC I/O-Isolation add Suffix „H6“
o Metal Case Available (up to 3000 VDC Isolation)
MODEL NUMBER
INPUT
VOLTAGE
OUTPUT
VOLTAGE
3.3 VDC
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
OUTPUT
CURRENT
500 mA
400 mA
222 mA
INPUT CURRENT
Eff.%
NO LOAD
FULL LOAD
622 mA
615 mA
597 mA
75 mA
571 mA
588 mA
615 mA
638 mA
30 mA
588 mA
53
65
67
Capacitor
Load (µF)
2VRS5N3.3M
2VRS5N5M
2VRS5N9M
2VRS5N12M
2VRS5N15M
2VRS5N24M
5 VDC
2VRD5N3.3M
2VRD5N5M
2VRD5N9M
2VRD5N12M
2VRD5N15M
2VRD5N24M
last up-date 10.03.2011
330
70
68
65
62
±1000
68
166 mA
133 mA
83.3 mA
±300 mA
±200 mA
±111 mA
±83 mA
±67 mA
±42 mA
50 mA
40 mA
±3.3 VDC
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
571 mA
70
±470
579 mA
69
±220
2 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
2/6
MODEL NUMBER
INPUT
VOLTAGE
OUTPUT
VOLTAGE
3.3 VDC
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
OUTPUT
CURRENT
500 mA
400 mA
222 mA
INPUT CURRENT
Eff.%
NO LOAD
FULL LOAD
245 mA
260 mA
245 mA
70 mA
238 mA
252 mA
256 mA
250 mA
228 mA
20 mA
222 mA
213 mA
216 mA
35 mA
219 mA
120 mA
56
64
68
Capacitor
Load (µF)
2VRS12N3.3M
2VRS12N5M
2VRS12N9M
2VRS12N12M
2VRS12N15M
2VRS12N24M
12 VDC
2VRD12N3.3M
2VRD12N5M
2VRD12N9M
2VRD12N12M
2VRD12N15M
2VRD12N24M
2VRS24N3.3M
2VRS24N5M
2VRS24N9M
2VRS24N12M
2VRS24N15M
2VRS24N24M
24 VDC
2VRD24N3.3M
2VRD24N5M
2VRD24N9M
2VRD24N12M
2VRD24N15M
2VRD24N24M
330
70
66
65
66
±1000
73
75
78
77
76
57
±220
±470
166 mA
133 mA
83.3 mA
±300 mA
±200 mA
±111 mA
±83 mA
±67 mA
±42 mA
500 mA
400 mA
±3.3 VDC
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
3.3 VDC
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
±3.3 VDC
±5 VDC
±9 VDC
±12 VDC
±15 VDC
±24 VDC
132 mA
222 mA
25 mA
166 mA
133 mA
83.3 mA
±300 mA
±200 mA
15 mA
±111 mA
±83 mA
±67 mA
20 mA
±42 mA
111 mA
111 mA
104 mA
108 mA
121 mA
114 mA
122 mA
63
330
68
68
±1000
73
75
80
77
75
±220
±470
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
2 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/6
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
Input Reflected Ripple Current
1)
±10%
Pi Type
35 mA p-p
OUTPUT SPECIFICATIONS
Voltage Accuracy
Temperature Coefficient
Ripple and Noise, 20MHz BW
2)
Short Circuit Protection
Capacitor Load
3)
Line Regulation
Load Regulation
(From 0% to 100% Load)
(Output 3.3 V Model)
±2% max.
±0.02%/°C
75 mV p-p
Indefinite (Automatic Recovery)
see table
±0.5%
±0.5%
±1.5%
NOTE:
1. Measured Input reflected ripple current with a simulated source inductance of 12 µH.
2. Ripple & Noise measured with 20 MHz bandwidth.
3. Tested by minimal Vin and constant resistive load.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
2 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
4/6
GENERAL SPECIFICATION
Efficiency
I/O Isolation Voltage (3 sec.)
1)
Suffix "H2"
Suffix "H3"
Suffix "H4"
Suffix "H5"
Suffix "H6"
Isolation Resistance
Isolation Capacitance
Switching Frequency
Operating Temperature Range
Case Temperature
Storage Temperature Range
Humidity
Cooling
Reliability Calculated MTBF (MIL-HDBK-217F)
Case Material Standard Model
Case Material Suffix "A" Model
Base Material
Pin Material
Potting Material
Weight
Dimensions
Safety Standard (designed to meet)
NOTE:
1. Isolation Voltage Input & Output for metal case up to 3000 VDC min. only available.
see table
1000
2000
3000
4000
5200
6000
VDC
VDC
VDC
VDC
VDC
VDC
min.
min.
min.
min.
min.
min.
1000 Mohms min.
60 pF
Single
Dual
40 kHz
300 kHz
-40°C to +85°C (see derating curve)
+100°C max.
-40°C to +125°C
95% rel H
Nature Convection
>3.072 Mhrs
Non-Conductive Black Plastic (UL94V-0 rated)
Nickel-Coated Copper
Non-conductive Black Plastic (UL94V-0 rated)
0.5 mm Alloy42 Solder-coated
ø0.5 mm Brass Solder-coated
Epoxy (UL94V-0 rated)
Plastic Case
Metal Case
12.5 g
15.0 g
31.75 x 20.32 x 10.16 mm (1.25 x 0.8 x 0.4 Inches)
IEC 60950-1
ABSOLUTE SPECIFICATIONS
These are stress ratings. Exposure of devices to any of these conditions may adversely affect long-term reliability.
Input Voltage (100 mS)
Lead Soldering Temperature (1.5 mm from case 10 sec.)
NOTE:
Exceeding the absolute ratings of the unit could cause damage. It is not allowed for continuous operating.
Operation under no-load conditions will not damage these devices, however they may not meet all listed specifications.
5V
12 V
24 V
0 VDC to 7 VDC
0 VDC to 15 VDC
0 VDC to 28 VDC
+260°C
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
2 Watt - 24 Pin DIL - Package V
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
5/6
MECHANICAL SPECIFICATIONS
CASE "V"
Non Conductive Black Plastic
PIN
1 & 24
2 & 23
3 & 22
9 & 16
10 & 15
11 & 14
12 & 13
PIN CONNECTIONS 1000 VDC
SINGLE
+INPUT
NC*
NC*
NO PIN
-OUTPUT
+OUTPUT
-INPUT
DUAL
+INPUT
-OUTPUT
COMMON
NO PIN
COMMON
+OUTPUT
-INPUT
*
Option "No Pin" at Single Output add Suffix "NP" to
Part No.
PIN CONNECTIONS 2000 to 6000 VDC
PIN
1&2
SINGLE
+INPUT
NO PIN
NO PIN
NO PIN
-OUTPUT
+OUTPUT
NO PIN
NO PIN
-INPUT
DUAL
+INPUT
NO PIN
NO PIN
COMMON
NO PIN
-OUTPUT
NO PIN
+OUTPUT
-INPUT
Nickel-Coated Copper
3 & 22
9 & 16
10 & 11
12
13
14
15
23 & 24
Application Note:
Please don't operate in parallel use.
