GBL005, GBL01, GBL02, GBL04, GBL06, GBL08, GBL10
www.vishay.com
Vishay General Semiconductor
Glass Passivated Single-Phase Bridge Rectifier
FEATURES
• UL recognition file number E54214
• Ideal for printed circuit boards
• High surge current capability
• Typical I
R
less than 0.1 μA
• High case dielectric strength
• Solder dip 275 °C max. 10 s, per JESD 22-B106
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
~
~
Case Type GBL
~
~
TYPICAL APPLICATIONS
General purpose use in AC/DC bridge full wave rectification
for monitor, TV, printer, SMPS, adapter, audio equipment,
and home appliances application.
GBL
4.0 A
50 V, 100 V, 200 V, 400 V, 600 V,
800 V, 1000 V
150 A
5 μA
1.0 V
150 °C
In-line
PRIMARY CHARACTERISTICS
Package
I
F(AV)
V
RRM
I
FSM
I
R
V
F
at I
F
= 4.0 A
T
J
max.
Diode variations
MECHANICAL DATA
Case:
GBL
Molding compound meets UL 94 V-0 flammability rating
Base P/N-M3 - halogen-free, RoHS-compliant, and
commercial grade
Terminals:
Matte tin plated leads, solderable
J-STD-002 and JESD 22-B102
M3 suffix meets JESD 201 class 1A whisker test
Polarity:
As marked on body
per
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward
rectified output current at
T
C
= 50 °C
T
A
= 40 °C
SYMBOL GBL005 GBL01
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
T
J
, T
STG
50
35
50
100
70
100
GBL02
200
140
200
GBL04
400
280
400
4.0
(1)
3.0
(2)
150
93
-55 to +150
GBL06
600
420
600
GBL08
800
560
800
GBL10
1000
700
1000
UNIT
V
V
V
A
A
A
2
s
°C
Peak forward surge current single sine-wave
superimposed on rated load
Rating for fusing (t < 8.3 ms)
Operating junction and storage temperature range
Notes
(1)
Unit mounted on 3.0" x 3.0" x 0.11" thick (7.5 cm x 7.5 cm x 0.3 cm) aluminum plate
(2)
Unit mounted on PCB at 0.375" (9.5 mm) lead length and 0.5" x 0.5" (12 mm x 12 mm) copper pads
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum
instantaneous forward
voltage drop per diode
Maximum DC reverse
current at rated DC
blocking voltage per diode
Typical junction
capacitance per diode
TEST CONDITIONS SYMBOL GBL005 GBL01
4.0 A
T
A
= 25 °C
T
A
= 125 °C
4.0 V, 1 MHz
I
R
C
J
95
V
F
GBL02
GBL04
1.00
5.0
500
40
μA
pF
GBL06
GBL08
GBL10
UNIT
V
Revision: 05-Aug-15
Document Number: 89300
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBL005, GBL01, GBL02, GBL04, GBL06, GBL08, GBL10
www.vishay.com
Vishay General Semiconductor
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
SYMBOL GBL005 GBL01
R
JA
(2)
R
JC
(1)
GBL02
GBL04
22
3.5
GBL06
GBL08
GBL10
UNIT
°C/W
Notes
(1)
Unit mounted on 3.0" x 3.0" x 0.11" thick (7.5 cm x 7.5 cm x 0.3 cm) aluminum plate
(2)
Unit mounted on PCB at 0.375" (9.5 mm) lead length and 0.5" x 0.5" (12 mm x 12 mm) copper pads
ORDERING INFORMATION
(Example)
PREFERRED P/N
GBL06-M3/45
GBL06-M3/51
UNIT WEIGHT (g)
2.18
2.18
PREFERRED PACKAGE CODE
45
51
BASE QUANTITY
20
400
DELIVERY MODE
Tube
Anti-static PVC tray
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
5.0
100
Average Forward Output Current (A)
4.0
Heat-Sink Mounting
3.0 x 3.0 x 0.11" Thick
(7.5 x 7.5 x 0.3 cm)
Aluminum Plate
Instantaneous Forward Current (A)
60 Hz Resistive or Inductive Load
10
3.0
1
2.0
PCB Mounted
0.47 x 0.47" (12 x 12 mm)
Copper Pads with 0.375"
(9.5 mm) Lead Length
0
50
100
150
0.1
1.0
T
J
= 25 °C
Pulse Width = 300 µs
1 % Duty Cycle
0.6
0.8
1.0
1.2
1.4
1.6
0
0.01
0.4
Ambient Temperature (°C)
Instantaneous Forward Voltage (V)
Fig. 1 - Derating Curves Output Rectified Current
Fig. 3 - Typical Forward Voltage Characteristics Per Diode
150
1000
Instantaneous Reverse Current (µA)
Peak Forward Surge Current (A)
T
J
= T
J
Max.
Single Sine-Wave
100
T
A
= 125 °C
10
50 - 400 V
60 - 1000 V
100
1
50
0.1
T
A
= 25 °C
1.0 Cycle
0
1
10
100
0.01
0
20
40
60
80
100
Number of Cycles at 60 Hz
Percent of Rated Peak Reverse Voltage (%)
Fig. 2 - Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
Fig. 4 - Typical Reverse Characteristics Per Diode
Revision: 05-Aug-15
Document Number: 89300
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBL005, GBL01, GBL02, GBL04, GBL06, GBL08, GBL10
www.vishay.com
Vishay General Semiconductor
100
1000
Transient Thermal Impedance (°C/W)
Junction Capacitance (pF)
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
10
100
1
50 - 400 V
600 - 1000 V
10
0.1
1
10
100
0.1
0.01
0.1
1
10
100
Reverse Voltage (V)
t - Heating Time (s)
Fig. 5 - Typical Junction Capacitance Per Diode
Fig. 6 - Typical Transient Thermal Impedance Per Diode
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Type GBL
0.125 (3.17) x 45°
Chamfer
0.825 (20.9)
0.815 (20.7)
0.080 (2.03)
0.060 (1.50)
0.421 (10.7)
0.411 (10.4)
0.095 (2.41)
0.080 (2.03)
0.098 (2.5)
0.075 (1.9)
0.050 (1.27)
0.040 (1.02)
0.210 (5.3)
0.190 (4.8)
0.040 (1.02)
0.030 (0.76)
0.022 (0.56)
0.018 (0.46)
0.098 (2.5)
0.075 (1.9)
0.718 (18.2)
0.682 (17.3)
Lead Depth
0.022 (0.56)
0.018 (0.46)
0.140 (3.56)
0.128 (3.25)
Polarity shown on front side of case, positive lead beveled corner
Revision: 05-Aug-15
Document Number: 89300
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
