FFB
38 x 38 x 28 MM SERIES
DIMENSIONS DRAWING
38.0 0.5
(1.496 0.020)
32.0 0.3
(1.260 0.012)
28.0 0.5
(1.102 0.020)
2-4.0 0.3
(2-0.157 0.012)
38.0 0.5
(1.496 0.020)
32.0 0.3
(1.496 0.012)
LABEL
8- 3.5 0.2
(8- 0.138 0.008)
10.0
(0.394)
335.0 10.0
(13.189 0.394)
UNIT:
mm
(INCH)
*
Bearing Type
Air Pressure
Ball Bearings
*
Material
Impeller & Frame : Plastic (UL 94V-0)
*
Lead Wires :
UL 1061 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
*
Weight : 46g (1.62 oz)
P & Q CURVE
(AT RATED VOLTAGE)
1.68
1.40
1.12
0.84
0.56
0.28
0
(IN H
2
O)
MOUNTING PANEL CUTOUT
OUTLET SIDE
36.0
(1.417)
42.0
35.0
28.0
21.0
14.0
7.0
0
0
(mm H
2
O)
FFB03812XN
INLET SIDE
36.0
(1.417)
32.0
(1.260)
36.0
(1.417)
32.0
(1.260)
36.0
(1.417)
32.0
(1.260)
4
1 . 0. 0
57
5)
(
.15
6.0
.30
12.0
Air Flow
.45
18.0
.60
.75
(M /MIN)
(CFM)
3
4- 3.5
(4- 0.138)
4- 3.5
(4- 0.138)
0
24.0
(
4
1. 0 . 0
57
5)
VH
HH
H
M
L
32.0
(1.260)
UNIT:
mm
(INCH)
MODEL
PART NO.
FFB03812LN
FFB03812MN
FFB03812HN
FFB03812HHN
FFB03812VHN
FUNCTION
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
Rated
Voltage
VDC
12
12
12
12
12
Operating
Voltage
Range
VDC
7.0 to 13.8
7.0 to 13.8
7.0 to 13.8
7.0 to 13.8
7.0 to 13.2
Rated
Current
Amp
0.20
0.25
0.34
0.47
0.65
Rated
Input
Power
Watt
2.40
3.00
4.08
5.64
7.80
Speed
R.P.M.
8000
10000
12000
14000
16000
Maximum
Air Flow
CFM
0.265
0.352
0.431
0.490
0.573
9.35
12.44
15.22
17.30
20.23
Maximum
Air Pressure
mmH
2
O
10.07
14.38
21.31
28.22
37.15
IN H
2
O
0.396
0.566
0.839
1.111
1.463
Noise
dB-A
39.0
45.0
51.5
55.5
58.5
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
