57349-5300 STRAIGHT-ACTION HAND CRIMP TOOL
PRODUCT SPECIFICATION
ATP-57349-5300E
2005/01/28, Rev.- A
Molex Japan Co., Ltd.
1. Description
This tool is a straight-action hand crimp tool (long-handle type), which is designed for
crimp-connecting a wire to crimp a terminal of Molex.
Please take the time to read attached the operating manual (IS-0116) of Hand Crimp Tool,
making sure you understand the crimping procedures and management method described it
before attempting to operate this hand tool.
2. Specifications
1) Tool name:
2) Tool number:
3) Outer dimensions and weight:
4) Management method:
5) Applicable terminal and wires:
Terminal
number
56125
Applicable wire
size (AWG)
#14
#16
56125
#18
Extruded wire length
2.8-3.1
0.2-1.0
1.23-1.33
3.95+/-0.1
9.0 MIN.
3.8-4.3
Applicable
insulation outer
diameter (mm)
3.5-3.8
3.3-3.5
Crimp height
(mm)
1.47-1.59
1.29-1.39
Insulation crimp
height (reference)
(mm)
57349-5300 Straight-Action Hand Crimp Tool (Long-Handle)
57349-5300
290 (width) x 90 (depth) x 15 (thickness) mm, Approx. 500gf
Crimp height and crimp strength (Details are described to the
corresponding crimp specification)
Crimp strength
(kgf)
15.0 MIN.
13.0 MIN.
4.1+/-0.1
4.0+/-0.1
Wire strip length
3. Tool Appearance
Applicable Terminal
56125
57349-5300
5.6/7.5 mm Pitch Multi Terminal Connector
