535843-4

Description
HEADER CONNECTOR,PCB MNT,RECEPT,120 CONTACTS,PIN,0.1 PITCH,WRAP POST TERMINAL,BLACK
CategoryThe connector    The connector
File Size115KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

535843-4 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,120 CONTACTS,PIN,0.1 PITCH,WRAP POST TERMINAL,BLACK

535843-4 Parametric

Parameter NameAttribute value
Objectid301475862
Reach Compliance Codeunknown
ECCN codeEAR99
Board mount options#2-56 THD HOLE
body width0.65 inch
subject depth0.48 inch
body length2.368 inch
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact to complete cooperationAU
Contact completed and terminatedGOLD
Contact point genderMALE
Contact materialBERYLLIUM COPPER
contact modeRECTANGULAR
Contact resistance20 mΩ
Contact styleSQ PIN-SKT
Dielectric withstand voltage900VAC V
Durability250 Cycles
maximum insertion force.6672 N
Insulation resistance5000000000 Ω
Insulator colorBLACK
insulator materialGLASS FILLED POLYESTER
Manufacturer's serial number535843
Plug contact pitch0.1 inch
Match contact row spacing0.1 inch
Installation methodSTRAIGHT
Installation typeBOARD
Number of connectorsONE
PCB row number6
Number of rows loaded6
Maximum operating temperature105 °C
Minimum operating temperature-55 °C
PCB contact patternRECTANGULAR
PCB contact row spacing2.54 mm
Plating thickness30u inch
polarization keyPOLARIZED KEY
GuidelineUL, CSA
reliabilityCOMMERCIAL
Terminal length0.684 inch
Terminal pitch2.54 mm
Termination typeWIRE WRAP
Total number of contacts120

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Two-Piece C onnector
>
Product Feature Selector
> Product Details
535843-4 Product Details
Live Product Chat
Product View
AMP-HDI (Four Beam) & TBC (Twin Beam) Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
535843-4
T E I nternal N umber: 5 3 5 8 4 3 - 4
Product Highlights:
l
C onnector
l
Plug
l
Number of Positions = 120
l
Module Type = Left Key
l
PC B Mount Style = Through Hole
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Plug
l
Number of Positions
= 120
l
PC B Mount Style
= Through Hole
l
PC B Mount Angle
= Vertical
l
Make First / Break Last
= Yes
l
Mating Polarization
= With
l
PC B Retention Feature
= Yes
l
Mating Polarization Type = Keying System
Mechanical Attachment:
l
Module Type
= Left Key
Termination Related Features:
l
Termination Post Length (mm [in])
= 17.37 [0.684]
l
Solder Tail C ontact Plating
= Tin
Body Related Features:
l
Number of Rows = 6
l
C enterline (mm [in])
= 2.54 [0.100]
l
PC B Retention Method = AC TION PIN (C ompliant) Posts
Contact Related Features:
l
C ontact Type
= Twin-Beam
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
l
C ontact Underplating = Nickel
Housing Related Features:
l
Housing Material = Polyester GF
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
C enter Guide = Without
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
