SIT9102AI-243H25S220.00000 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> SIT9102AI-243H25S220.00000

SIT9102AI-243H25S220.00000: DescriptionXO, Clock, 1MHz Min, 220MHz Max, 220MHz Nom, CMOS,; CategoryPassive components oscillator; File Size961KB，13 Pages; ManufacturerSiTime; Environmental Compliance

Download Datasheet Parametric View All

SIT9102AI-243H25S220.00000 Overview

XO, Clock, 1MHz Min, 220MHz Max, 220MHz Nom, CMOS,

SIT9102AI-243H25S220.00000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1148386289
Reach Compliance Code	compliant
Country Of Origin	Malaysia, Taiwan, Thailand
YTEOL	3
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	6
Maximum operating frequency	220 MHz
Minimum operating frequency	1 MHz
Nominal operating frequency	220 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	DILCC6,.2
power supply	2.5 V
Certification status	Not Qualified
Maximum slew rate	76 mA
Nominal supply voltage	2.5 V
surface mount	YES
technology	CMOS
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)

Preview

Download Datasheet

View All

SiT9102

LVPECL / HCSL / LVDS / CML

1 to 220 MHz High Performance Oscillator

Features

• Extremely low RMS phase jitter (random)

• <1 ps (typical)

• Wide frequency range

• 1 MHz to 220 MHz

• 220 MHz to 800 MHz refer to SiT9107

• High frequency stability

• ±10 PPM, ±15 PPM, ±20 PPM

• ±25 PPM, ±50 PPM

• Operating voltage

• 1.8, 2.5 or 3.3 V

• Other voltages up to 3.63 V (contact SiTime)

• Operating temperature range

• Industrial, -40 to 85 °C

• Extended Commercial, -20 to 70 °C

• Commercial, 0 to 70 °C

• Small footprint

• 5.0 x 3.2 x 0.75 mm

• 7.0 x 5.0 x 0.90 mm

• Pb-free and RoHS compliant

• For Spread Spectrum see SiT9002

• Ultra-reliable start up and greater immunity from inter

ference

Benefits

•

Ultra fast lead time: 2 to 3 weeks

No crystal or capacitors required

Eliminates crystal qualification time

50% + board saving space

More cost effective than quartz oscillators, quartz crystals

and clock ICs.

• Completely quartz-free

Applications

•

Server

Router

RAID controller

Gigabit Ethernet

10 Gigabit Ethernet

Fiber Channel

SATA / SAS

PCI-Express

Fully Buffered DIMM

System clock

Networking and computing

Block Diagram

VDD

OUT- OUT+

Pinout

ST/OE

VDD

OUT-

MEMS

Resonator

High Performance

Phase Lock Loop

GND

OUT+

ST/OE

GND

SiTime Corporation

Rev. 1.52

990 Almanor Avenue

Sunnyvale, CA 94085

(408) 328-4400

www.sitime.com

Revised June 23, 2010
