IP 67 Com bina tion D -SU B C onne c t or s
IP67
Combination HD-SUB Solid Body
Solder cup – Precision machined contacts – For wire size AWG 22 and AWG 12 - 14
Description
Signal contacts for wire size
AWG 22
High power contacts 20A for cable
AWG 12 - 14
Mounting style:
with 4-40 UNC threaded insert
Quality class 3 (Also available in quality class 1)
One-piece zinc die-cast nickel plated shell
IP67 for harsh environments, pressure-proof up to 1.45 PSI
Stainless steel hex bolts are supplied loose
RoHS compliant
Socket connector
Shellsize
2
3
4
Plug connector
A
47.70
61.40
78.00
+ 0.3
- 0
+ 0.3
- 0
+ 0.3
- 0
B2
-0.25
24.79
38.50
54.96
C
33.32
47.04
63.50
+ 0.13
- 0.12
± 0.13
± 0.13
Shellsize
2
3
4
A
47.70
-
61.40
+ 0.3
0
+ 0.3
- 0
+ 0.3
0
B1
25.14
-
38.86
+ 0.23
0.02
+ 0.23
- 0.02
+ 0.23
0.02
C
33.32
-
+ 0.13
0.12
D
6.00
+ 0.12
- 0.18
- 0.3
- 0.3
47.04
± 0.13
5.99
63.50
± 0.13
5.99
78.00
-
55.32
-
Shellsize 2-4
Shellsize 2-4
Order data
Socket connector
Design
15W4
19W1
45W2
Plug connector
Power contact
High power 20A
High power 20A
High power 20A
Mounting style 4-40 UNC
Threaded insert
Threaded insert
Threaded insert
Part number
15-005893
15-005903
15-005913
Design
15W4
19W1
45W2
Mounting style 4-40 UNC
Threaded insert
Threaded insert
Threaded insert
Power contact
High power 20A
High power 20A
High power 20A
Part number
15-005923
15-005933
15-005943
Other high power or coaxial contacts on request.
