V I S H AY I N T E R T E C H N O L O G Y, I N C .
INNOVAT
CeRAmiC CAPACitORs
MONO-K AP
K10 series multilayer Ceramic
Dipped Radial Capacitors
I
O
N
AND
TEC
HN
O
L
OGY
19
62-2012
Capacitors - High Capacitance in Small Size
Key Benefits
• High capacitance in small size
• Cost effective solution
• Compliant to RoHS Directive 2011/65/EU, and REACH Regulation EC 1907/2006
Key sPeCifiCAtiOns
• Capacitance range: Class 1 C0G range 10 pF to 1 nF;
Class 2 X7R range 100 pF to 100 nF; Class 2 Y5V range 10 nF to 150 nF
• Dielectric strength: 250 % of rated voltage
• Insulation resistance: ≥ 10 000 MΩ
• IEC 60384-9 Class 2
• IEC 60384-8 Class 1 and EIA 198
• Operating Temperature: C0G, X7R: - 55 °C to + 125 °C; Y5V: - 30 °C to + 85 °C
APPLiCAtiOns
• Bypassing
• Coupling/decoupling
• Signal comparison
ResOuRCes
• Datasheet: Mono-Kap® - http://www.vishay.com/doc?45183
• For technical questions contact cmll@vishay.com
Discrete Semiconductors and Passive Components
One of the World’s Largest Manufacturers of
PRODUCT SHEET
1/2
VMN-PT9161-1202
THIS DOCUMENT IS SUBjECT TO CHANGE wITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBjECT TO
SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
V I S H AY I N T E R T E C H N O L O G Y, I N C .
INNOVAT
CeRAmiC CAPACitORs
MONO-K AP
®
Mono-Kap
Multilayer Ceramic Dipped Radial K10 Capacitors
CAPACITANCE RANGE CHART
C0G (NP0) DIELECTRIC
SIZE
RATED VOLTAGE
VALUE
CODE
10 pF
100
12 pF
120
15 pF
150
18 pF
180
22 pF
220
27 pF
270
33 pF
330
39 pF
390
47 pF
470
56 pF
560
68 pF
680
82 pF
820
100 pF
101
120 pF
121
150 pF
151
180 pF
181
220 pF
221
270 pF
271
330 pF
331
390 pF
391
470 pF
471
560 pF
561
680 pF
681
820 pF
821
1000 pF
102
1200 pF
122
1500 pF
152
1800 pF
182
2200 pF
222
2700 pF
272
3300 pF
332
3900 pF
392
4700 pF
472
5600 pF
562
6800 pF
682
8200 pF
822
0.01 µF
103
I
O
N
AND
TEC
HN
O
L
OGY
19
62-2012
Dipped Radial multilayer Ceramic K10 Capacitors
X7R DIELECTRIC
10
50
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
100
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SIZE
RATED VOLTAGE
VALUE
CODE
100 pF
101
120 pF
121
150 pF
151
180 pF
181
220 pF
221
270 pF
271
330 pF
331
390 pF
391
470 pF
471
560 pF
561
680 pF
681
820 pF
821
1000 pF
102
1200 pF
122
1500 pF
152
1800 pF
182
2200 pF
222
2700 pF
272
3300 pF
332
3900 pF
392
4700 pF
472
5600 pF
562
6800 pF
682
8200 pF
822
0.01 µF
103
0.012 µF
123
0.015 µF
153
0.018 µF
183
0.022 µF
223
0.027 µF
273
0.033 µF
333
0.039 µF
393
0.047 µF
473
0.056 µF
563
0.068 µF
683
0.082 µF
823
0.10 µF
104
0.12 µF
124
0.15 µF
154
0.22 µF
224
0.33 µF
334
0.47 µF
474
0.68 µF
684
1.0 µF
105
10
50
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
100
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Vishay
Capacitors - High Capacitance in Small Size
Y5V DIELECTRIC
SIZE
RATED VOLTAGE
VALUE
CODE
0.01 µF
103
0.015 µF
153
0.022 µF
223
0.033 µF
333
0.047 µF
473
0.068 µF
683
0.10 µF
104
0.15 µF
154
0.22 µF
224
0.33 µF
334
0.47 µF
474
0.68 µF
684
1.0 µF
105
10
50
•
•
•
•
•
•
•
•
Mono-Kap
Vishay
Multilayer Ceramic Dipped Radial K10 Capacitors
For technical questions, contact:
cmll@vishay.com
www.vishay.com
97
Document Number: 45183
Revision: 16-Nov-09
DESCRIPTION
Capacitance range
Rated DC voltage
QUICK REFERENCE DATA
VALUE
10 pF to 1000 pF
50 V
100 V
100 pF to 0.1 µF
50 V
100 V
0.01 µF to 0.15 µF
50 V
+ 80 %/- 20 %
Y5V
Tolerance on capacitance
Dielectric Code
± 5 %, ± 10 %
C0G (NP0)
± 10 %, ± 20 %
X7R
ORDERING INFORMATION
K
PRODUCT
TYPE
103
CAPACITANCE
CODE
K
CAPACITANCE
TOLERANCE
10
SIZE
CODE
X7R
TEMP.
CHAR.
F
RATED
VOLTAGE
5
LEAD
DIA.
3
LEAD LENGTH/
PACKAGING
H
LEAD
STYLE
5
LEAD
SPACING
Revision 16-Nov-09
K=
Mono-Kap
Two significant
digits followed by
the number of
zeros.
For example:
103 = 10 000 pF
J=±5%
K = ± 10 %
M = ± 20 %
Z = + 80%/- 20 %
Ref.
mech.
spec.
C0G
X7R
Y5V
F=
50 V
DC
H=
100 V
DC
5=
0.5 mm
(0.020")
3 = Bulk, with lead
length of 30 ± 5.0
mm (1.25")
T = Tape and reel
U = Ammopack
L=
Straight
Lead
H=
High
seated
assy
2=
2.5 (0.100")
5=
5.0 (0.200")
Ordering Example: K-103-K-10-X7R-F-5-3-H-5
PRODUCT SHEET
2/2
VMN-PT9161-1202
THIS DOCUMENT IS SUBjECT TO CHANGE wITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBjECT TO
SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
