POLYMER MULTI-LAYER CAPACITORS
ST
ST
SERIES
◆FEATURES
・
Surface-mounted device.
・
Lead free reflow soldering is available.
・
RoHS compliance.
◆CAUTION
ST series shall be used in only reflow method. Do not use in flow, dipping, and VPS soldering method.
Please storage in moisture proof bag with dry silica-gel after opening the moisture proof bag. Please ask for detail.
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Dissipation Factor
（tanδ）
Characteristics
−55∼＋125℃
16∼63V.DC
0.047∼22μF
（473∼226）
E6 series
100V.DC
0.001∼0.1μF
（102∼104）
E6 series
±10%
（K）
,±20%
（M）
1.5% or less(1kHz±20%, 5Vrms or less)
Voltage Proof
Nothing abnormal shall be found, when applying 150% of the rated voltage for 1minute
or 175% of the rated voltage for 1 second to 5 seconds.
Insulation Resistance
C≦0.1μF 3000MΩor more (After 1 minute application of rated voltage)
：
C＞0.1μF 300MΩ μF or more (After 1 minute application of rated voltage)
：
・
1000MΩ or more (After 1 minute application of rated voltage)
◆PART NUMBER
□□□
Rated Voltage
ST
Series
□□□
Capacitance
□
Capacitance
Tolerance
□□□
Option
□□
TP code
□□□□
Chip Size
Code
Rated Voltage
Code
Capacitance
Code
Tolerance
Code
Chip Size
16
25
35
50
63
100
16V.DC
25V.DC
35V.DC
50V.DC
63V.DC
100V.DC
102
473
684
335
106
226
0.001μF
0.047μF
0.68μF
3.3μF
10μF
22μF
K
M
±10%
±20%
3216
3225
4532
5750
3.2×1.6mm
3.2×2.5mm
4.5×3.2mm
5.7×5.0mm
◆PERMISSIBLE CURRENT FOR FREQUENCY
16V
35V
50V
Permissible current
（Arms)
Permissible current
（Arms)
Permissible current
（Arms)
226
106
475
475
106
105
105
105
224
Frequency kHz)
（
Frequency kHz)
（
Frequency kHz)
（
POLYMER MULTI-LAYER CAPACITORS
ST
□ Tolerance
：
◆STANDARD SIZE
(L±0.3×W±0.3×H±0.2)
Rated Voltage Capacitance
(V.DC)
(μF)
Size
L
(mm)
W
(mm)
H
(mm)
Part No.
Rated Voltage Capacitance
(V.DC)
(μF)
Size
L
(mm)
W
(mm)
H
(mm)
Part No.
16
25
35
50
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
3.2
3.2
3.2
3.2
4.5
4.5
4.5
5.7
5.7
3.2
3.2
3.2
3.2
4.5
4.5
4.5
5.7
5.7
3.2
3.2
3.2
3.2
4.5
4.5
4.5
5.7
5.7
3.2
3.2
3.2
3.2
3.2
3.2
4.5
4.5
4.5
5.7
5.7
1.6
1.6
2.5
2.5
3.2
3.2
3.2
5.0
5.0
1.6
1.6
2.5
2.5
3.2
3.2
3.2
5.0
5.0
1.6
1.6
2.5
2.5
3.2
3.2
3.2
5.0
5.0
1.6
1.6
1.6
1.6
2.5
2.5
3.2
3.2
3.2
5.0
5.0
1.4
1.4
1.8
2.0
1.4
1.8
2.6
1.8
2.6
1.4
1.4
2.0
1.8
1.4
1.8
2.6
1.8
2.6
1.0
1.4
1.4
2.0
1.4
1.8
2.6
1.8
2.6
1.0
1.0
1.0
1.4
1.4
1.8
1.4
1.8
2.6
1.8
2.6
16ST105□A23216
16ST155□A23216
16ST225□B23225
16ST335□B33225
16ST475□C14532
16ST685□C24532
16ST106□C44532
16ST156□D15750
16ST226□D35750
25ST684□A23216
25ST105□A23216
25ST155□B33225
25ST225□B23225
25ST335□C14532
25ST475□C24532
25ST685□C44532
25ST106□D15750
25ST156□D35750
35ST474□A13216
35ST684□A23216
35ST105□B13225
35ST155□B33225
35ST225□C14532
35ST335□C24532
35ST475□C44532
35ST685□D15750
35ST106□D35750
50ST104□A13216
50ST154□A13216
50ST224□A13216
50ST334□A23216
50ST474□B13225
50ST684□B23225
50ST105□C14532
50ST155□C24532
50ST225□C44532
50ST335□D15750
50ST475□D35750
63
100
0.047
0.068
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
0.0010
0.0015
0.0022
0.0033
0.0047
0.0068
0.010
0.015
0.022
0.033
0.047
0.068
0.10
3.2
3.2
3.2
3.2
3.2
3.2
3.2
4.5
4.5
4.5
5.7
5.7
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
1.6
1.6
1.6
1.6
1.6
2.5
2.5
3.2
3.2
3.2
5.0
5.0
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
2.5
2.5
1.0
1.0
1.0
1.0
1.4
1.4
1.8
1.4
1.8
2.6
1.8
2.6
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.4
1.4
1.8
63ST473□A13216
63ST683□A13216
63ST104□A13216
63ST154□A13216
63ST224□A23216
63ST334□B13225
63ST474□B23225
63ST684□C14532
63ST105□C24532
63ST155□C44532
63ST225□D15750
63ST335□D35750
100ST102□A13216
100ST152□A13216
100ST222□A13216
100ST332□A13216
100ST472□A13216
100ST682□A13216
100ST103□A13216
100ST153□A13216
100ST223□A13216
100ST333□A13216
100ST473□A23216
100ST683□B13225
100ST104□B23225
◆DIMENSIONS
(mm)
W±0.3
Size Code Conversion
mm
3216
3225
4532
5750
inch
1206
1210
1812
2220
0.5±0.3
Outer Electrode
H±0.2
L±0.3
