REVISION N
DO NOT
SCALE FROM
THIS PRINT
1.70 .067
REF
DESIGNED & DIMENSIONED
IN MILLIMETERS
(INCHES FOR REFERENCE ONLY)
(No OF POS x 0.80[.031]) + 3.00[.118] REF
C
MECT-1XX-XX-XX-D-RAX-XX
No OF POSITIONS
-10, -15, -20, -35
(PER ROW)
CARD THICKNESS
-01: 1mm [.039] THICK CARD
(USE MECT-XX-01-D-RAX)
OPTION
-TR: TAPE & REEL
TAIL OPTION
-RA1: STANDARD (SEE FIG. 1)
(USE MECT-XX-01-D-RA1,
C-173-01-X & C-174-04-X)
-RA2: ELEVATED (SEE FIG. 2)
*
(USE MECT-XX-01-D-RA2,
C-173-02-X & C-174-02-X)
(No OF POS -1) x 0.80[.0315]
0.80±0.05 .031±.002
(TOL NON-ACCUM)
70
C
L
36
POSITION #1
INDICATOR
01
35
7.40 .291
REF
PLATING
-M: SELECTIVE MEDIUM GOLD
(USE C-173-XX-M & C-174-XX-M)
ROW SPECIFICATION
-S: SELECTIVE GOLD
-D: DOUBLE
(USE C-173-XX-S & C-174-XX-S)
(USE MECT-XX-XX-D-RAX)
-MM: SELECTIVE MEDIUM GOLD, MATTE
TIN TAIL (USE C-173-XX-M & C-174-XX-M)
-SM: SELECTIVE GOLD, MATTE TIN
TAIL (USE C-173-XX-S & C-174-XX-S)
* = NOT TOOLED
0.80±0.05 .031±.002
(TOL NON-ACCUM)
0.400 .0157
C
FOR POSITIONS -10, -20 & -35
(MECT-135-01-XX-D-RA1 SHOWN)
FIG 1
(No OF POS -1) x 0.80[.0315]
(No OF POS x 0.80[.031]) + 1.40[.055] REF
'D'
1.20 .047
REF
"B"
C
L
"A"
'E'
"B"
0.90 .035 REF
"A"
1.40 .055 REF
(No OF POS + 2) x 0.80[.031] REF
0.20 .008 REF (TYP)
C
L
MECT-XX-01-D-RA1
C
C
SEE TABLE 1
SEE TABLE 1
C
L
DETAIL 'D'
SCALE 5 : 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS.
DETAIL 'E'
SCALE 5 : 1
1.40 .055
REF
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM BURR ALLOWANCE: 0.381[.0015].
3. MINIMUM PUSHOUT FORCE: .5 LB.
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
TOLERANCES ARE:
DECIMALS
.X: .3 [.01]
2
.XX: .13 [.005]
.XXX: .051 [.0020]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
INSULATOR: LCP, COLOR: BLACK
CONTACT: PHOS BRONZE
0.8mm [.031"] RIGHT ANGLE EDGE CARD ASSEMBLY
DWG. NO.
DESCRIPTION:
F:\DWG\MISC\MKTG\MECT-1XX-XX-XX-D-RAX-XX-MKT.SLDDRW
BY:
KEVIN B
MECT-1XX-XX-XX-D-RAX-XX
10/18/01
SHEET
1
OF
3
REVISION N
C
6.25 .246 REF
C-173-01-X
C
L
0.85±0.08 .033±.003 (TYP)
C
0.45±0.15 .018±.006
C
C
C-174-04-X
SEE TABLE 1
2.65 .104 REF
3.25 .128 REF
0.95 .037
(TYP)
9.10 .358
C
5.20 .205
(TYP)
0.90 x 45 REF
0.85±0.08 .033±.003 (TYP)
1.05 .041
REF (TYP)
SECTION "A"-"A"
SECTION "B"-"B"
"C"
MECT-XX-01-D-RA2
C-173-02-X
C-174-02-X
4.65 .183
REF
5.25 .207
REF
"C"
SECTION "C"-"C"
-RA2: ELEVATED OPTION
(SAME AS FIG 2, UNLESS OTHERWISE STATED)
(MECT-135-01-XX-D-RA2 SHOWN)
* = NOT TOOLED
FIG 2
F:\DWG\MISC\MKTG\MECT-1XX-XX-XX-D-RAX-XX-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.4
0.8mm [.031"] RIGHT ANGLE EDGE CARD ASSEMBLY
BY:
KEVIN B
MECT-1XX-XX-XX-D-RAX-XX
10/18/01
SHEET
2
OF
3
REVISION N
-TR OPTION
ROUND HOLES
16.00 .630
POSITION 1
INDICATOR
(LOAD PARTS WITH POSITION #1 INDICATOR
IN SAME DIRECTION AS ARROW ON TUBE)
"C"
PT-1-24-01-113
PT-1-24-03-113
PACKAGING VIEWS
OBLONG HOLES
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
*
* = NOT TOOLED
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.4
0.8mm [.031"] RIGHT ANGLE EDGE CARD ASSEMBLY
F:\DWG\MISC\MKTG\MECT-1XX-XX-XX-D-RAX-XX-MKT.SLDDRW
BY:
KEVIN B
MECT-1XX-XX-XX-D-RAX-XX
10/18/01
SHEET
3
OF
3
