5962-9220506M3A datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> 5962-9220506M3A

5962-9220506M3A: Description8-BIT, DSP-PIPELINE REGISTER, CQCC28, LCC-28; CategoryThe embedded processor and controller Microcontrollers and processors; File Size866KB，8 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

5962-9220506M3A Overview

8-BIT, DSP-PIPELINE REGISTER, CQCC28, LCC-28

5962-9220506M3A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	QLCC
package instruction	QCCN,
Contacts	28
Reach Compliance Code	unknown
Other features	MULTIPLEXED OUTPUT; ICC SPECIFIED @ 2.5MHZ
boundary scan	NO
External data bus width	8
JESD-30 code	S-CQCC-N28
JESD-609 code	e0
length	11.4554 mm
low power mode	NO
Humidity sensitivity level	NOT SPECIFIED
Number of terminals	28
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output data bus width	8
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	MILITARY
Filter level	MIL-STD-883
Maximum seat height	2.54 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	11.4554 mm
uPs/uCs/peripheral integrated circuit type	DSP PERIPHERAL, PIPELINE REGISTER
Base Number Matches	1

Preview

Download Datasheet

View All
