DDTC (R1 = R2 SERIES) UA
NPN PRE-BIASED SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
•
•
•
•
•
•
•
Epitaxial Planar Die Construction
Complementary PNP Types Available (DDTA)
Built-In Biasing Resistors, R1 = R2
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. "Green" Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Part Number
R1, R2 (NOM)
DDTC123EUA
2.2KΩ
DDTC143EUA
4.7KΩ
DDTC114EUA
10KΩ
DDTC124EUA
22KΩ
DDTC144EUA
47KΩ
DDTC115EUA
100KΩ
Mechanical Data
•
•
•
•
•
Case: SOT323
Case Material: Molded Plastic, "Green" Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.008 grams (approximate)
OUT
3
SOT323
B
R1
C
IN B
R2
1
3
C OUT
E
1
IN
2
GND(0)
GND (0)
Top View
Device Schematic
Equivalent Inverter Circuit
Ordering Information
(Notes 4 & 5)
Product
DDTC123EUA-7-F
DDTC143EUA-7-F
DDTC114EUA-7-F
DDTC114EUAQ-7-F
DDTC124EUA-7-F
DDTC124EUAQ-7-F
DDTC124EUAQ-13-F
DDTC144EUA-7-F
DDTC144EUAQ-7-F
DDTC144EUAQ-13-F
DDTC115EUA-7-F
DDTC115EUAQ-7-F
Notes:
Compliance
AEC-Q101
AEC-Q101
AEC-Q101
Automotive
AEC-Q101
Automotive
Automotive
AEC-Q101
Automotive
Automotive
AEC-Q101
Automotive
Marking
N04
N08
N13
N13
N17
N17
N17
N20
N20
N20
N24
N24
Reel size (inches)
7
7
7
7
7
7
13
7
7
13
7
7
Tape width (mm)
8
8
8
8
8
8
8
8
8
8
8
8
2
E
Quantity per reel
3,000
3,000
3,000
3,000
3,000
3,000
10,000
3,000
3,000
10,000
3,000
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
Nxx = Product Type Marking Code (See Table Above)
YM = Date Code Marking
Y = Year (ex: X = 2010)
M = Month (ex: 9 = September)
Nxx
Date Code Key
Year
Code
Month
Code
2010
X
Jan
1
Feb
2
2011
Y
Mar
3
2012
Z
Apr
4
May
5
YM
2013
A
Jun
6
2014
B
Jul
7
Aug
8
2015
C
Sep
9
2016
D
Oct
O
Nov
N
2017
E
Dec
D
DDTC (R1 = R2 SERIES) UA
Document number: DS30321 Rev. 12 - 2
1 of 5
www.diodes.com
November 2013
© Diodes Incorporated
DDTC (R1 = R2 SERIES) UA
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Supply Voltage <Pine: (3) to (2)>
DDTC123EUA
DDTC143EUA
DDTC114EUA
DDTC124EUA
DDTC144EUA
DDTC115EUA
DDTC123EUA
DDTC143EUA
DDTC114EUA
DDTC124EUA
DDTC144EUA
DDTC115EUA
All
Symbol
V
CC
Value
50
-10 to +12
-10 to +30
-10 to +40
-10 to +40
-10 to +40
-10 to +40
100
100
50
30
100
20
100
Unit
V
Input Voltage <Pin: (1) to (2)>
V
IN
V
Output Current
I
O
mA
Output Current
I
C(MAX)
mA
Thermal Characteristics
Characteristic
Power Dissipation (Notes 6)
Thermal Resistance, Junction to Ambient Air (Note 6)
Operating and Storage Temperature Range
Symbol
P
D
R
θJA
T
J
, T
STG
Value
200
625
-55 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
V
l(OFF)
Min
0.5
Typ
1.1
Max
⎯
Unit
V
Test Condition
V
CC
= 5V, I
O
= 100 µA
V
O
= 0.3V, I
O
= 20mA, DDTC123EUA
V
O
= 0.3V, I
O
= 20mA, DDTC143EUA
V
O
= 0.3V, I
O
= 10mA, DDTC114EUA
V
O
= 0.3V, I
O
= 5mA, DDTC124EUA
V
O
= 0.3V, I
O
= 1mA, DDTC115EUA
V
O
= 0.3V, I
O
= 2mA, DDTC144EUA
I
O
/I
l
= 10mA/0.5mA, DDTC123EUA
I
O
/I
l
= 10mA/0.5mA, DDTC143EUA
I
O
/I
l
= 10mA/0.5mA, DDTC114EUA
I
O
/I
l
= 10mA/0.5mA, DDTC124EUA
I
O
/I
l
= 10mA/0.5mA, DDTC144EUA
I
O
/I
l
= 5mA/0.25mA, DDTC115EUA
Input Voltage
V
l(ON)
⎯
1.9
3
V
1.4
2
Output Voltage
V
O(ON)
⎯
0.1
0.3
V
Input Current
DDTC123EUA
DDTC143EUA
DDTC114EUA
DDTC124EUA
DDTC144EUA
DDTC115EUA
DDTC123EUA
DDTC143EUA
DDTC114EUA
DDTC124EUA
DDTC144EUA
DDTC144EUAQ
DDTC115EUA
I
l
⎯
⎯
Output Current
I
O(OFF)
⎯
20
20
30
56
68
80
82
-30
0.8
⎯
⎯
3.8
1.8
0.88
0.36
0.18
0.15
0.5
mA
V
I
= 5V
µA
DC Current Gain
G
l
⎯
⎯
⎯
Input Resistor (R
1
) Tolerance
Resistance Ratio
Gain-Bandwidth Product (Note 7)
Notes:
ΔR
1
R
2
/R
1
f
T
⎯
1
250
+30
1.2
⎯
%
⎯
MHz
V
CC
= 50V, V
I
= 0V
V
O
= 5V, I
O
= 20mA
V
O
= 5V, I
O
= 10mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
⎯
⎯
V
CE
= 10V, I
E
= 5mA,
f = 100MHz
6. Mounted on FR4 PC Board with minimum recommended pad layout.
7. Transistor - For Reference Only.
DDTC (R1 = R2 SERIES) UA
Document number: DS30321 Rev. 12 - 2
2 of 5
www.diodes.com
November 2013
© Diodes Incorporated
DDTC (R1 = R2 SERIES) UA
Typical Curves – DDTC143EUA
250
(@T
A
= +25°C, unless otherwise specified.)
1,000
P
D
, POWER DISSIPATION (mW)
h
FE
, DC CURRENT GAIN
0
50
100
150
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Power Dissipation vs. Ambient Temperature
1
I
C
/I
B
= 10
200
100
150
100
10
50
0
-50
1
1
10
100
I
C
, COLLECTOR CURRENT (mA)
Fig. 2 Typical DC Current Gain vs. Collector Current
f = 1MHz
5
V
CE(SAT)
, COLLECTOR EMITTER
SATURATION VOLTAGE (V)
4
0.1
CAPACITANCE (pF)
75
°
C
-25
°
C
25
°
C
3
2
0.01
1
0.001
0
0
10
40
20
30
50
I
C
, COLLECTOR CURRENT (mA)
Fig. 3. Collector Emitter Saturation Voltage
vs. Collector Current
0
10
15
25
20
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Capacitance Characteristics
5
30
100
10
I
C
, COLLECTOR CURRENT (mA)
1
V
in
, INPUT VOLTAGE (V)
0
1
8
9 10
6
7
3 4
5
V
in
, INPUT VOLTAGE (V)
Fig. 5 Collector Current vs. Input Voltage
2
10
1
0.1
0.01
0
0
10
20
30
40
50
I
C
, COLLECTOR CURRENT (mA)
Fig. 6 Input Voltage vs. Collector Current
DDTC (R1 = R2 SERIES) UA
Document number: DS30321 Rev. 12 - 2
3 of 5
www.diodes.com
November 2013
© Diodes Incorporated
DDTC (R1 = R2 SERIES) UA
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
A
B C
G
H
K
M
J
D
L
SOT323
Dim
Min
Max
Typ
A
0.25
0.40
0.30
B
1.15
1.35
1.30
C
2.00
2.20
2.10
D
-
-
0.65
G
1.20
1.40
1.30
H
1.80
2.20
2.15
J
0.0
0.10
0.05
K
0.90
1.00
1.00
L
0.25
0.40
0.30
M
0.10
0.18
0.11
0°
8°
-
α
All Dimensions in mm
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
Y
Z
C
Dimensions Value (in mm)
Z
2.8
X
0.7
Y
0.9
C
1.9
E
1.0
X
E
DDTC (R1 = R2 SERIES) UA
Document number: DS30321 Rev. 12 - 2
4 of 5
www.diodes.com
November 2013
© Diodes Incorporated
DDTC (R1 = R2 SERIES) UA
