TB
Low Profile
Dipped Tantalum Capacitors
nemco
Dipped Tantalum Capacitors
FEATURES
Reliable, solid tantalum construction
Small size per C / V combination
Capacitance range: 0.1
μf
to 330
μf
Voltage range: 6.3 to 50 WVDC
Surge tested for maximum robustness
Operating temperature range -55°C to +125°C, 2/3 x Vr (linear derating) above +85°C
Meniscus control eliminates thru-hole plugging for excellent top side solder joints
Laser marking and bold polarity stripe
Supplied bulk or available packaged for auto insertion
Flame retardant, self extinguishing epoxy coating meets UL94 VO
Lead cutting and forming is available
Available lead-free, RoHS compliant or with 90% Sn / 10% Pb termination finish
MSL (moisture sensitivity level) per IPC/Jedec J-STD-020B is level 1
Pb
Lead Free
RoHS
compliant
TB
Capacitance
(μF)
Low Profile
Dipped Tantalum Capacitors
nemco
Capacitance
(μF)
Case
Size
.
PART NUMBERS & SPECIFICATIONS
Case
Size
Nemco Part No.
DCL
(μA) max.
tan
δ
max.
(%)
ESR
@ 100Khz
max. (Ω)
Nemco Part No.
DCL
(μA) max.
tan
δ
max.
(%)
ESR
@ 100Khz
max. (Ω)
6.3 V DC
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
68.0
100.0
150.0
220.0
330.0
A
A
A
B
C
D
E
F
G
H
K
M
N
@
85°C
TB3.3
TB4.7
TB6.8
TB10
TB15
TB22
TB33
TB47
TB68
TB100
TB150
TB220
TB330
/
/
/
/
/
/
/
/
/
/
/
/
/
6
6
6
6
6
6
6
6
6
6
6
6
6
_
_
_
_
_
_
_
_
_
_
_
_
_
1
1
1
1
1
1
1
1
1
1
2
2
2
0.5
0.5
0.5
0.5
0.8
1.1
1.7
2.4
3.4
5.0
7.6
11.0
16.6
6
6
6
8
8
8
8
8
8
10
10
10
10
13.0
10.0
8.0
6.0
5.0
3.7
3.0
2.0
1.8
1.6
0.9
0.9
0.7
20 V DC
22
33
47
68
100
H
J
K
N
N
@
85°C
Continued
TB22
TB33
TB47
TB68
TB100
/
/
/
/
/
20 _ 1
20 _ 2
20 _ 2
20 _ 2
20 _ 2
3.5
5.2
7.5
10.8
16.0
8
8
8
8
10
1.8
1.4
1.2
0.9
0.6
25 V DC
1.5
2.2
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
68.0
A
A
B
C
D
E
F
H
J
M
N
@
85°C
TB1.5
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
TB22
TB33
TB47
TB68
/
/
/
/
/
/
/
/
/
/
/
25
25
25
25
25
25
25
25
25
25
25
_1
_1
_1
_1
_1
_1
_1
_1
_2
_2
_2
0.5
0.5
0.6
0.9
1.3
2.0
3.0
4.4
6.6
9.4
13.6
4
6
6
6
6
8
8
8
8
8
8
8.0
6.0
5.0
4.0
3.1
2.5
2.0
1.5
1.2
1.0
0.8
10 V DC
2.2
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
68.0
100.0
150.0
220.0
330.0
@
85°C
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
TB22
TB33
TB47
TB68
TB100
TB150
TB220
TB330
/
/
/
/
/
/
/
/
/
/
/
/
/
/
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 1
10 _ 2
10 _ 2
10 _ 2
10 _ 2
0.5
0.5
0.5
0.5
0.8
1.2
1.7
2.6
3.7
5.4
8.0
12.0
17.6
20.0
6
6
6
6
8
8
8
8
8
8
10
10
10
10
13.0
10.0
8.0
6.0
5.0
3.7
2.7
2.1
1.7
1.3
1.0
0.8
0.6
0.5
A
A
A
B
C
D
E
F
G
H
K
N
O
O
35 V DC
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
A
A
A
A
A
A
A
A
B
C
E
F
F
H
K
M
N
@
85°C
TB.1
TB.15
TB.22
TB.33
TB.47
TB.68
TB1
TB1.5
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
TB22
TB33
TB47
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_2
_2
_2
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.9
1.3
1.9
2.8
4.2
6.1
9.2
10.0
4
4
4
4
4
4
4
4
6
6
6
6
8
8
8
8
8
26.0
21.0
17.0
15.0
13.0
10.0
8.0
6.0
5.0
4.0
3.0
2.5
2.0
1.6
1.3
1.0
0.8
16 V DC
1.5
2.2
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
68.0
100.0
150.0
220.0
@
85°C
TB1.5
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
TB22
TB33
TB47
TB68
TB100
TB150
TB220
/
/
/
/
/
/
/
/
/
/
/
/
/
/
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 1
16 _ 2
16 _ 2
16 _ 2
16 _ 2
0.5
0.5
0.5
0.6
0.8
1.2
1.9
2.8
4.2
6.0
8.7
12.8
19.2
20.0
4
6
6
6
6
8
8
8
8
8
8
10
10
10
10.0
8.0
6.0
5.0
4.0
3.2
2.5
2.0
1.6
1.3
1.0
0.8
0.6
0.5
A
A
A
B
C
D
E
F
F
H
L
M
N
O
50 V DC
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
15.0
A
A
A
A
A
B
C
D
E
F
G
H
J
K
@
85°C
TB.1
TB.15
TB.22
TB.33
TB.47
TB.68
TB1
TB1.5
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
/
/
/
/
/
/
/
/
/
/
/
/
/
/
50
50
50
50
50
50
50
50
50
50
50
50
50
50
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_1
_2
_2
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.8
1.3
1.8
2.7
4.0
6.0
4
4
4
4
4
4
4
4
6
6
6
6
8
8
26.0
21.0
17.0
15.0
13.0
10.0
8.0
5.0
3.5
3.0
2.5
2.0
1.6
1.2
20 V DC
1.5
2.2
3.3
4.7
6.8
10.0
15.0
A
A
B
C
D
E
F
@
85°C
TB1.5
TB2.2
TB3.3
TB4.7
TB6.8
TB10
TB15
/
/
/
/
/
/
/
20 _ 1
20 _ 1
20 _ 1
20 _ 1
20 _ 1
20 _ 1
20 _ 1
0.5
0.5
0.5
0.7
1.0
1.6
2.4
4
6
6
6
6
8
8
9.0
7.0
5.5
4.5
3.6
2.9
2.3
_
Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
TB
Low Profile
Dipped Tantalum Capacitors
nemco
Standard
Standard
.200 inch
Lead Spacing
.
Dimensions and Lead Spacings
Standard
.100 inch
Lead Spacing
CASE
SIZE
A
B
C
D
E
F
G
H
D
max
mm (inches)
4.5 (.177)
4.5 (.177)
5.0 (.197)
5.0 (.197)
5.5 (.217)
6.0 (.236)
6.5 (.256)
7.0 (.276)
L
max
mm (inches)
7.0 (.276)
7.5 (.295)
8.5 (.335)
9.0 (.354)
9.0 (.354)
10.0 (.394)
10.0 (.394)
10.5 (.413)
S
± 0.5 mm
(.02 inches)
mm (inches)
2.5 (.100)
2.5 (.100)
2.5 (.100)
2.5 (.100)
2.5 (.100)
2.5 (.100)
2.5 (.100)
2.5 (.100)
CASE
SIZE
J
K
L
M
N
O
D
max
mm (inches)
8.0 (.315)
8.5 (.335)
9.0 (.354)
9.0 (.354)
9.0 (.354)
10.0 (.394)
L
max
mm (inches)
13.0 (.512)
14.0 (.550)
14.0 (.550)
14.5 (.570)
16.0 (.630)
17.0 (.670)
S
± 0.5 mm
(.02 inches)
mm (inches)
5.0 (.200)
5.0 (.200)
5.0 (.200)
5.0 (.200)
5.0 (.200)
5.0 (.200)
NOTE: Industry standard lead spacings and lead styles shown above are a function of physical case size. Case sizes are
determined by the capacitance value and voltage combination.
Optional Lead Styles
.200 inch Lead Spacing
.250 inch Lead Spacing
.100 inch Lead Spacing
Snap-In
.200 inch Lead Spacing
Snap-In
.100 inch Lead Spacing
Back to Back form
Available in
Case Sizes A - H
P/N Suffix Code 2
Available in
Case Sizes A - O
P/N Suffix Code 250
Available in
Case Sizes A - H
P/N Suffix Code E1
Available in Bulk Only
Available in
Case Sizes A - H
P/N Suffix Code E2
Available in Bulk Only
Available in
Case Sizes A - H
P/N Suffix Code F
NOTE: Seated component heights for optional lead styles will vary based on case size.
Contact your Nemco sales representative for samples of optional lead styles.
