MTC & MTJ Series
9.6mm x 11.7mm SMD
• Industry Standard Package
• 5.0 or 3.3 Volt
• HCMOS, Sinewave, Clipped Sine
• 9.600MHz to 50.000MHz
• Stability Down to ±1ppm
Electrical Specifications
H Option = HCMOS Output
Frequency Range
Frequency Stability
Load
Supply Current
Output
Frequency Range
Frequency Stability
Load
Supply Current
Output
Sinewave Output
Frequency Stability
Load
Supply Current
Output
9.600MHz to 50.000MHz
Down to ±1ppm
10K Ohms // 15pF
35mA max.
Logic”1” Level = 0.9Vdd min.
Logic”0” Level = 0.1Vdd max.
9.600MHz to 50.000MHz
Down to ±1ppm
10K Ohms // 15pF
3mA max.
1.0V p-p min.
9.600MHz to 50.000MHz
Down to ±1ppm
50 Ohms
5mA max.
7dBm min.
See Part Numbering Guide
-40°C to +85°C
5.0Vdc ±5%
3.3Vdc ±5%
±3ppm min.
2.5Vdc±2.0Vdc Positive Slope
1.65Vdc±1.5Vdc Positive Slope
No Connect
±10ppm min.
±1ppm per year max.
±0.3ppm
±0.3ppm
40/60% or 45/55%
S Option = Clipped Sine Output
Z Option = Sinewave Output
Operating Temperature Range
Storage Temperature Range
Supply Voltage (Vdd)
Internal Trim (Top of can)
Control Voltage
Pin 1 Connection
Frequency Stability
Vdd = 5V
Vdd = 3.3V
Vdd = 5V
Vdd = 3.3V
Blank
V Option
vs. Aging
vs. Voltage (with a 5% change)
vs. Load (with a 10% change)
@50% of waveform w/CMOS load
Symmetry
www.mmdcomp.com
Phone 949-709-5075 / Fax: 949-709-3536
OS16
Specifications subject to change without notice
Revision: 3/21/04 H
Part Numbering Guide
MT
9.6 x 11.7 SMD
Frequency
Supply Voltage
5 = 5 Volt
3 = 3.3 Volt
Frequency Stability *
10 = ±1ppm
15 = ±1.5ppm
20 = ±2ppm
25 = ±2.5ppm
30 = ±3ppm
35 = ±3.5ppm
50 = ±5ppm
Operating Temp. Range *
A = 0°C to +50°C
B = -10°C to +60°C
C = -20°C to +70°C
D = -30°C to +70°C
H = -30°C to +75°C
F = -40°C to +85°C
G = 0°C to +70°C
Output Type
H = HCMOS
S = Clipped Sinewave
Z = Sinewave
Pin 1 Connection
Blank = No Connect
V = Voltage Control
Symmetry
Blank = 40%/60%
A = 45%/55%
Series Option
C = C series(w/ trimmer)
J = J series(w/o trimmer)
* Check with factory for additional stability vs. temperature options
Mechanical Dimensions
9.612 max
.3784 max
2.05 max
.081 max
7.0
.276
1.5max
.059 max
#3
#2
#2
1.2 max
.047 max
#3
7.82 max
.308 max
Optional
Markings
11.7 max
.461 max
0.7
.028
#4
#1
#1
#4
1.4
.055
0.6
.024
Pin Connections
Markings
Pin
Pin
Pin
Pin
1:
2:
3:
4:
C o n t r o l Vo l t a g e o r N / C
Case Ground
Output
S u p p l y Vo l t a g e
Line
Line
Line
Line
1:
2:
3:
4:
MMD
Part Number
Frequency
Date Code
Suggested Solder Pad Layout
Solder Pad
(X4)
7.62
.300
2.54
.100
www.mmdcomp.com
Phone 949-709-5075 / Fax: 949-709-3536
8.26
.325
2.54
.100
OS16
Specifications subject to change without notice
Revision: 3/21/04 H
