5149009-7 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 5149009-7

Preview

5149009-7: Descriptionconn plug vert 160pos gold bcb; CategoryThe connector; File Size144KB，1 Pages; ManufacturerAll Sensors; Environmental Compliance

Download Datasheet Parametric Compare View All

5149009-7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5149009-7	-	-	View	Buy Now

5149009-7 Overview

conn plug vert 160pos gold bcb

5149009-7 Parametric

Parameter Name	Attribute value
Datasheets
5149009-4
RoHS Informati
5149009-7 Statement of Compliance
RoHS 2 Stateme
3D Model
5149009-7.pdf
Standard Package	5
Category	Connectors, Interconnects
Family	Rectangular - Board to Board Connectors - Headers, Male Pins
Packaging	Tray
Connector Type	Shrouded
Number of Positions	160
Number of Positions Loaded	All
Pitch	0.050" (1.27mm)
Number of Rows	2
Row Spacing	0.100" (2.54mm)
Height Stacking (Mating)	0.738" (18.75mm)
Molding Height Above Board	0.648" (16.46mm)
Contact Mating Length	-
Mounting Type	Through Hole
Terminati	Solde
Contact Finish	Gold
Contact Finish Thickness	30µin (0.76µm)
Features	Ground Bus (Plane)
Col	Natural
Other Names	5149009-7-NDA115302

Preview

Download Datasheet

View All

5149009-7 Related Products

	5149009-7	5149009-1	5149009-4
Description	conn plug vert 160pos gold bcb	conn plug 40pos vert solder	conn plug vert 100pos 30gold pcb
Standard Package	5	19	8
Category	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects
Family	Rectangular - Board to Board Connectors - Headers, Male Pins	Rectangular - Board to Board Connectors - Headers, Male Pins	Rectangular - Board to Board Connectors - Headers, Male Pins
Packaging	Tray	Tray	Tray
Connector Type	Shrouded	Shrouded	Shrouded
Number of Positions	160	40	100
Number of Positions Loaded	All	All	All
Pitch	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)
Number of Rows	2	2	2
Row Spacing	0.100" (2.54mm)	0.100" (2.54mm)	0.100" (2.54mm)
Height Stacking (Mating)	0.738" (18.75mm)	0.738" (18.75mm)	0.738" (18.75mm)
Molding Height Above Board	0.648" (16.46mm)	0.648" (16.46mm)	0.648" (16.46mm)
Mounting Type	Through Hole	Through Hole	Through Hole
Terminati	Solde	Solde	Solde
Contact Finish	Gold	Gold	Gold
Contact Finish Thickness	30µin (0.76µm)	30µin (0.76µm)	30µin (0.76µm)
Features	Ground Bus (Plane)	Ground Bus (Plane)	Ground Bus (Plane)
Col	Natural	Natural	Natural
Other Names	5149009-7-NDA115302	51490091	51490094
Mating Products	-	5536297-1-ND - CONN RCPT 40POS R/A 30GOLD5536255-1-ND - CONN RECEPT 40POS VERT GOLD5536296-9-ND - CONN RCPT 40POS R/A GOLDA115432-ND - CONN RCPT VERT SOLERTAIL 40POS5536279-1-ND - CONN RECEPT VERT 40 POS 30AU PCB536295-1-ND - CONN RECEPT RTANG 40POS GOLD PCB536279-1-ND - CONN RECEPT VERT 40 POS 30AU PCB536254-1-ND - CONN RECEPT VERT 40 POS 30AU PCB536255-1-ND - MICRO VERT STRIP RECEPT 40POS	5536279-4-ND - CONN RCPT 100POS VERT SOLDERTAIL
