KTC3605T-J: DescriptionRF Small Signal Bipolar Transistor, 0.04A I(C), 2-Element, Ultra High Frequency Band, Silicon, NPN, TS6, 6 PIN; CategoryDiscrete semiconductor The transistor; File Size399KB，5 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/

Download Datasheet Parametric Compare View All

KTC3605T-J Overview

RF Small Signal Bipolar Transistor, 0.04A I(C), 2-Element, Ultra High Frequency Band, Silicon, NPN, TS6, 6 PIN

KTC3605T-J Parametric

Parameter Name	Attribute value
Maker	KEC
package instruction	SMALL OUTLINE, R-PDSO-G6
Contacts	6
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LOW NOISE
Maximum collector current (IC)	0.04 A
Collector-based maximum capacity	0.95 pF
Collector-emitter maximum voltage	10 V
Configuration	SEPARATE, 2 ELEMENTS
highest frequency band	ULTRA HIGH FREQUENCY BAND
JESD-30 code	R-PDSO-G6
Number of components	2
Number of terminals	6
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Nominal transition frequency (fT)	10000 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

VHF/UHF WIDE BAND AMPLIFIER APPLICATION.

KTC3605T

EPITAXIAL PLANAR NPN TRANSISTOR

FEATURES

・Low

Noise Figure, High Gain.

・NF=1.1dB,

21e

=13dB (f=1GHz).

・

Two internal isolated Transistors in one package.

DIM

MILLIMETERS

2.9 + 0.2

1.6+0.2/-0.1

0.70 + 0.05

0.4 + 0.1

2.8+0.2/-0.3

1.9 + 0.2

0.95

0.16 + 0.05

0.00-0.10

0.25+0.25/-0.15

0.60

0.55

MAXIMUM RATING (Ta=25℃)

CHARACTERISTIC

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Collector Power Dissipation

Junction Temperature

Storage Temperature Range

SYMBOL

CBO

CEO

EBO

stg

RATING

1.5

900

150

-55½150

UNIT

℃

1. Q1 Base

2. Q1 Emitter

3. Q2 Collector

4. Q2 Base

5. Q2 Emitter

6. Q1 Collector

TS6

*Package mounted on a ceramic board (600mm

0.8mm)

EQUIVALENT CIRCUIT (Top View)

Marking

Rank

Lot No.

Type Name

ELECTRICAL CHARACTERISTICS (Ta=25℃)

CHARACTERISTIC

Collector Cut-off Current

Emitter Cut-off Current

DC Current Gain

Collector Output Capacitance

Reverse Transfer Capacitance

Transition Frequency

Insertion Gain

21e

(2)

NF (1)

Noise Figure

NF (2)

=8V, I

=5mA, f=2GHz

1.7

Note 1 : h

Classification

H:50~100, J:80~160, K:125~250

Note 2 : C

is measured by 3 terminal method with capacitance bridge.

=8V, I

=20mA, f=2GHz

=8V, I

=5mA, f=1GHz

1.1

2.5

SYMBOL

CBO

EBO

(Note1)

=10V, I

=0, f=1MHz (Note2)

21e

(1)

=8V, I

=20mA

=8V, I

=20mA, f=1GHz

0.5

0.95

GHz

TEST CONDITION

=10V, I

=1V, I

=8V, I

=20mA

MIN.

TYP.

0.7

MAX.

250

UNIT

2007. 6. 21

Revision No : 0

1/5
