F-214 (Rev 15APR14)
FW–20–05–F–D–610–065
FW–12–05–G–D–530–101
(1,27 mm) .050"
FW-SM SERIES
SMT MICRO BOARD STACKER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?FW-SM
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +125°C
RoHS Compliant:
Yes
Mates with:
CLP, FFSD, FLE
Low profile or
skyscraper styles
APPLICATIONS
Variable
board spacing
MATED
HEIGHT
FW
CLP
Processing:
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10 mm) .004" max (02-30)
(0,15 mm) .006" max (31-50)
LEAD STYLE
FW
FW-XX-03-X-X-233-065
FW-XX-03-X-X-303-065
MATED
CLP HEIGHT*
– 02
(8,13)
.320
(9,91)
.390
*Processing conditions will affect mated height.
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(1,27 mm x 1,27 mm)
.050" x .050" micro pitch
Surface
mount
FW
FILE NO: 090871_0_000
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
D
STACKER
HEIGHT
POST
HEIGHT
OPTION
ALSO AVAILABLE
(MOQ Required)
• Smaller stack heights
Contact Samtec.
02 thru 50
–F
= Gold flash on post,
Matte Tin on tail
–“XXX”
= Stacker
Height
(in inches)
Example:
–250
= (6,35 mm)
.250"
–“XXX”
= Post Height
(in inches)
(1,65 mm)
.065"
minimum
Example:
–065
= (1,65 mm)
.065"
(3,45)
.136
x
(5,08)
.200
(4,06)
.160
LEAD STACKER
STYLE HEIGHT
–03
–05
STACKER
+ POST
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
= End Shroud
(–075 post height only.
Mate only with CLP)
(5,46 mm) .215" to
(15,49 mm) .610"
stacker height only
9 pins/row min.
–ES
(5,46) (8,51) (7,11) (10,16)
.215 to .335 .280 to .400
(8,64) (15,49) (10,29) (17,15)
.340 to .610 .405 to .675
–EP
= End Shroud
with Guide Post
(–075 post height only.
Mate only with CLP.)
(5,46 mm) .215"
to (15,49 mm) .610"
stacker height only)
9 pins/row min.
–G
= 10µ" (0,25 µm)
Gold on post,
Gold flash on tail
100
TAPE
arges.
No tooling ch e lesser of
er is th
Minimum ordntity or 125 pieces.
a
a full reel quantity above minimum.
r any qu gn, manufacture.
Orde
si
In-house de turn-around.
Quick
ns
tio
for specifica
Call Samtecring information.
and orde
AILABILITY
& REEL AV
02
No. of positions x
(1,27) .050
(3,42)
.135
(1,27)
.050
01
(1,19)
.047
(1,27) .050
(0,41) .016 SQ
99
(4,76)
.188
POST HEIGHT
(1,65) .065
MIN
(4,27)
.168
–A
= Alignment Pin
(3 positions min.)
(5,46 mm) .215" to
(15,75 mm) .620"
stacker height only
(0,76)
.030
–ES
–P
Note:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
Note:
This Series is
non-standard, non-returnable.
(3,05)
.120
STACKER
HEIGHT
(2,51)
.099
(2,92)
.115
(1,91)
.075
DIA
(0,86)
.034
–P
= Pick & Place Pad
(5 positions min.)
–TR
= Tape & Reel
(Post+Stacker Height+
Pad+Alignment Pin =
.700 (17.78))
–EP
(0,89)
.035
DIA
–A
WWW.SAMTEC.COM
