ExpressPort QSFP+ / QSFP
TM
U90-C101-3000
The ExpressPort™ QSFP+/QSFP interconnect system is comprised of a 38-position 0.8 mm pitch SMT
connector, and a press- t cage designed to comply with the Quad Small Form-factor Pluggable (QSFP)
Transceiver intended for external connections. High speed serial interconnect applications include
clusters, servers, and storage devices.
The ExpressPort™ QSFP+ E-Series and H-Series connector families are rated to 28 Gbps and 40 Gbps
respectively per channel (4x28), featuring a stamped and formed contact design providing improved
mechanical durability. This connector features an integrated grounding structure and resonance
dampening features for superior crosstalk performance. The contact design is optimized for a smooth
impedance pro le resulting in improved SI performance.
Speci cation Highlights
The QSFP interconnect system is comprised of a
press- t cage assembly which is used with
38-position connectors complying with QSFP
Transceiver Speci cations.
Mechanical Characteristics
•
Cage is Keyed According to QSFP MSA
o
QSFP+: SFF-8436
o
E-Series: SFF-8672
o
H-Series: TBD
•
Durability: 250 Mating Cycles min
•
Connector Insertion Force: 40 N max
•
Connector Withdrawal Force: 30 N max
Electrical Characteristics
•
Hot Swappable
•
Operating Voltage: 30 V
•
Operating Current: 0.5 A
•
Differential Impedance: 100 Ω +/- 10 Ω
•
DWV: 300 V AC
•
Insulation Resistance: 1000 MΩ min
•
Contact Resistance: 70 mΩ max
Packaging
•
Tape and Reel Packaging: Connector
or 1x1 Cage
•
Tray Packaging: Cage of all Sizes
•
Bulk Packaging: Dust Cover
Temperature Rating
•
Operating Temperature: -40°C to +85°C
•
Storage Temperature: -40°C to +85°C
Con gurations
(Rows x Ports per Row)
• 1x1 • 1x2 • 1x3 • 1x4
Options
•
Dust Cover
•
Light Pipe
o
Round 1.4 mm
o
Square 2.6x2.6 mm
•
Heat Sink
•
Cage Design
o
Through or Behind the Bezel
•
1x6
Materials
•
Cage
o
Base Material: Copper Alloy
o
Plating: Nickel or Tin
o
Light Pipe: Optical Grade Polycarbonate
o
Heat Sink: Aluminum Alloy
o
Heat Sink Clip: Stainless Steel
o
Dust Cover: Thermoplastic
•
Connector
o
Contact Base Material: Copper Alloy
o
Contact Plating: Gold on Mating Area, Matte Tin
on Terminations and Grounding Tabs
o
Housings: Glass Reinforced, Lead-Free Solder
Reflow Process Compatible Thermoplastic,
UL94V-0 Rated
Signal Integrity Characteristics
QSFP, ExpressPort™ QSFP+
•
Return Loss: -12 dB
•
Near-End Isolation: -30 dB (frequencies up to 3 GHz)
•
Insertion Loss: -1 dB max
•
Rise Time for Impedance Measurement: 35 ps
•
Within Pair Skew: 1 ps
•
NEXT: ≤ 2%
ExpressPort™ QSFP+ E-Series Connector
•
Return Loss: -12 dB max (frequencies up to 14 GHz)
•
Insertion Loss: 1.4 dB max (frequencies up to 14 GHz)
•
Common Mode Conversion: -24 dB max (up to 14 GHz)
•
Integrated Crosstalk Noise: 3 mV rms
-
Assumes 3 Nearest-Neighbour (most detrimental)
Aggressor Parameters and Receiver Parameters:
o
Near- and Far-End Aggressors’ Peak Differential
Amplitude: 600 mV
o
Near- & Far-End Aggressors’ 20-80% Risetime: 9.6 ps
o
3 dB Reference Receiver Bandwidth: 18.75 GHz
o
Range of Integration: 10 MHz to 40 GHz
o
MDNEXT: 1 mV rms; MDFEXT: 2.8 mV rms
ExpressPort™ QSFP+ H-Series Connector
•
Return Loss: < -20 dB to 12GHz, -12 dB to 20GHz
•
Near End Isolation: -40 to 20 GHz
•
Insertion Loss: -1dB up to 20GHz
•
Differential Impedance:100 +/- 5 Ω at 35 ps
•
Within pair skew: <1 ps
12
Ordering Information
U90-G351-101A
FS1-R38-2000
QSFP
ExpressPort™ QSFP+
ExpressPort™ QSFP+ E-Series
ExpressPort™ QSFP+ H-Series
FS1
SERIES DESIGNATION
(RoHS)
X38
Connectors:
FS1- X38
-
X 0 XX-XX
QSFP+ (12 Gbps and Up)
00
- No Resonance Dampening, No Hold Down Tabs
01
- No Resonance Dampening, Hold Down Tabs
QSFP+ (16 Gbps)
10
- Resonance Dampening, No Hold Down Tabs
11
- Resonance Dampening, Hold Down Tabs
E-Series (28 Gbps) / H-Series (40 Gbps)
10
- Resonance Dampening, No Hold Down Tabs
SPECIAL
XX
R38
- 38 Position Connector (QSFP 10G, ExpressPort™ QSFP+ 12G+ & 16G)
E38
- 38 Position Connector (ExpressPort™ QSFP+ E-Series 28G)
H38
- 38 Position Connector (ExpressPort™ QSFP+ H-Series 40G)
X
PLATING
2
- 30 µ" Gold Plating on Mating Area; Matte Tin Plating on Termination
3
- 15 µ" Gold Plating on Mating Area; Matte Tin Plating on Termination
OPTIONS
00
- QSFP Connector
0A
- Connector with Hold Down Tabs
A2
- QSFP+ Connector
M0
- E-Series Connector
HX
- H-Series Connector
XX
0
0
- Standard
QSFP
ExpressPort™ QSFP+
U90
SERIES DESIGNATION (RoHS)
X
X
STYLE
Cages:
U90- X X X 1
-
1 X X X
A
- One Row Cage 0°, Through the Bezel (No Light Pipe)
C
- One Row Cage 1°, Through the Bezel (1x1 Only, No Light Pipe)
D
- One Row Cage 0°, Hybrid with Elastomeric Gasket
G
- One Row Cage 0°, Behind the Bezel
H
- One Row Cage 0°, Through the Bezel with Optional Light Pipe
K
- One Row Cage 0°, Through the Bezel with No Heat Sink Opening
L
- One Row Cage 0°, No Pins on Back Wall
P
- One Row Cage 0°, Behind the Bezel with Low Profile Heat Sink and Clip
R
- One Row Cage 0°, Through the Bezel with Low Profile Heat Sink
T
- One Row Cage 0°, Through the Bezel with Low Profile Heat Sink and Clip
and Optional Light Pipe
1
- Tray Packaging
T
- Tape and Reel Packaging (1x1 Only)
A
- Tray Packaging Heat Sink and Clip
or Light Pipe Shipped Assembled
PACKAGING
X
0
- Without Light Pipe
1
- Round 1.4 mm Outlet Light Pipe,
No EMI gasket
3
- Square 2.6x2.6 mm Outlet Light Pipe,
No EMI gasket
LIGHT PIPE OPTION
X
X
1
- 1x1
3
- 1x3
4
- 1x4
6
- 1x6
NUMBER OF PORTS IN ROW
0
- Without Dust Cover
D
- With Dust Cover (Shipped Loose)
DUST COVER OPTION
X
1
- Nickel
PLATING
APPLICATION
1
1
X
1
- No Heat Sink or Clip Shipped
2
- Fin Style (Black Oxide) Heat Sink and Clip (H = 6.5 mm)
3
- Fin Style (Black Oxide) Heat Sink and Clip (H = 4.2 mm)
4
- Fin Style (Black Oxide) Heat Sink and Clip (H = 13.5 mm)
5
- Pin Style (Nickel Plated) Heat Sink and Clip (H = 6.5 mm)
6
- Pin Style (Nickel Plated) Heat Sink and Clip (H = 4.2 mm)
7
- Pin Style (Nickel Plated) Heat Sink and Clip (H = 13.5 mm)
D
- Pin-Fin Style (Black Oxide) Heat Sink and Clip (H = 6.5 mm)
E
- Pin-Fin Style (Black Oxide) Heat Sink and Clip (H = 4.2 mm)
F
- Pin-Fin Style (Black Oxide) Heat Sink and Clip (H = 13.5 mm)
N
- Pin-Fin Style (Nickel Plated) Heat Sink and Clip (H = 6.5 mm)
P
- Pin-Fin Style (Nickel Plated) Heat Sink and Clip (H = 4.2 mm)
R
- Pin-Fin Style (Nickel Plated) Heat Sink and Clip (H = 13.5 mm)
HEAT SINK OPTION
1
- Press Fit Pins (2.5 mm Long)
Telephone: (416)-291-4401
All specifications are subject to change without notice.
Website: www.amphenol-highspeed.com
13
Email: sales@amphenol-highspeed.com
