ATC 700 A Series NPO
Porcelain and Ceramic
Multilayer Capacitors
• Case A Size
(.055" x .055")
• Low ESR/ESL
• Low Noise
• Rugged
Construction
• Capacitance Range
0.1 pF to 1000 pF
• Zero TCC
• High Self-Resonance
• Established Reliability (QPL)
ELECTRICAL AND MECHANICAL
SPECIFICATIONS
QUALITY FACTOR (Q):
Greater than 10,000 (0.1 pF to 100 pF) @ 1 MHz.
Greater than 2000 (110 pF to 1000 pF) @ 1 MHz.
ATC, the industry leader, offers new improved ESR/ESL performance
for the 700 A Series RF/Microwave Capacitors. The superior high self-
resonance and zero TCC characteristic of this Series provide excellent
performance over a broad range of RF and microwave applications
requiring minimum drift. High density porcelain and ceramic construc-
tions provide a rugged, hermetic package.
Typical functional applications: Bypass, Coupling, Tuning and DC
Blocking.
Typical circuit applications: Filters, Oscillators and Timing
TEMPERATURE COEFFICIENT OF CAPACITANCE (TCC):
0 ±30 PPM/°C (-55°C to +125°C)
INSULATION RESISTANCE (IR):
0.1 pF to 470 pF:
10
6
Megohms min. @ +25°C at rated WVDC.
10
5
Megohms min. @ +125°C at rated WVDC.
510 pF to 1000 pF:
10
5
Megohms min. @ +25°C at rated WVDC.
10
4
Megohms min. @ +125°C at rated WVDC.
ENVIRONMENTAL TESTS
ATC 700 A Series Capacitors are designed and manufactured to
meet and exceed the requirements of EIA-198, MIL-PRF-55681 and
MIL-PRF-123.
WORKING VOLTAGE (WVDC):
See Capacitance Values Table, p 2.
DIELECTRIC WITHSTANDING VOLTAGE (DWV):
Case A: 250% of rated WVDC for 5 secs.
THERMAL SHOCK:
MIL-STD-202, Method 107, Condition A.
RETRACE:
Less than ±(0.02% or 0.02 pF), whichever is greater.
AGING EFFECTS:
None
PIEZOELECTRIC EFFECTS:
None
(No capacitance variation with voltage or pressure).
MOISTURE RESISTANCE:
MIL-STD-202, Method 106.
LOW VOLTAGE HUMIDITY:
MIL-STD-202, Method 103, Condition A, with 1.5 Volts DC applied
while subjected to an environment of 85°C with 85% relative humidity
for 240 hours min.
CAPACITANCE DRIFT:
±(0.02% or 0.02 pF), whichever is greater.
OPERATING TEMPERATURE RANGE:
From -55°C to +125°C (No derating of working voltage).
LIFE TEST:
MIL-STD-202, Method 108, for 2000 hours, at 125°C.
200% WVDC applied.
TERMINATION STYLES:
Available in various surface mount
styles. See Mechanical Configurations, page 3.
TERMINAL STRENGTH:
Terminations for chips and pellets withstand
a pull of 5 lbs. min., 10 lbs. typical, for 5 seconds in direction perpendicular to
the termination surface of the capacitor.
American
ATC North America
631-622-4700
sales@atceramics.com
Technical
ATC Europe
+46 8 6800410
sales@atceramics-europe.com
Ceramics
ISO 9001 REGISTERED
ATC # 001-813 Rev. G 12/04
ATC Asia
+86-755-8366-4318
sales@atceramics-asia.com
www.atceramics.com
ATC 700 A Capacitance Values
CAP.
CODE
0R1
0R2
0R3
0R4
0R5
0R6
0R7
0R8
0R9
1R0
1R1
1R2
1R3
1R4
1R5
1R6
1R7
1R8
1R9
2R0
2R1
2R2
CAP.
(pF) TOL.
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
RATED
WVDC
CAP.
CODE
2R4
2R7
3R0
3R3
3R6
3R9
4R3
4R7
5R1
5R6
CAP.
(pF)
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
TOL.
RATED
WVDC
CAP.
CODE
200
220
240
270
300
330
360
390
430
470
CAP.
(pF)
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
TOL.
RATED
WVDC
CAP.
CODE
151
161
181
201
221
241
271
301
331
361
391
431
471
511
561
621
681
751
821
911
102
CAP.
(pF)
150
160
180
200
220
240
270
300
330
360
390
430
470
510
560
620
680
750
820
910
1000
TOL.
RATED
WVDC
B
B, C
B, C, D
150
F, G,
J, K,
M
150
B, C,
D
6R2
6R8
7R5
8R2
9R1
100
110
120
130
150
160
180
150
B, C, J,
K, M
510
560
620
680
750
820
910
101
F, G,
J, K,
M
150
F, G, J,
K, M
111
121
131
110
120
130
50
VRMS = 0.707 x WVDC
SPECIAL VALUES, TOLERANCES, HIGHER WVDC AND MATCHING AVAILABLE. PLEASE CONSULT FACTORY.
Capacitance values in
bold
type indicate porcelain dielectric. All other capacitance values indicate ceramic dielectric.
ATC PART NUMBER CODE
ATC700 A 6R 8
Series
Case Size
Capacitance Code:
First 2 significant digits for capacitance.
R=Decimal Point
Indicates number of zeros following digits
of capacitance in picofarads except for decimal values.
Capacitance Tolerance
J
W 150 X
C
Packaging
T - Tape and Reel, 1000 pc. qty., 7" Reel std.*
TV - Vertical Orientation of Product,
Tape and Reel, 1000 pc. qty., 7" Reel std.*
C - ATC Cap-Pac
®
, 100 pc. qty. std.*
B - Bulk Packaging (packed in plastic bags)
I - Special Packaging. Consult Factory.
*
Consult ATC for other quantities
Laser Marking
CAPACITANCE TOLERANCE
Code
B
C
D
F
G
J
K
M
WVDC
Termination Code
Tol.
±0.1 pF ±0.25 pF ±0.5 pF ±1% ±2% ±5% ±10% ±20%
The above part number refers to a 700 A Series (case size A) 6.8 pF capacitor,
J tolerance (±5%), 150 WVDC, with W termination (Tin /Lead, Solder Plated over Nickel Barrier), laser marking and ATC Cap-Pac
®
packaging.
ATC accepts orders for our parts using designations
with
or
without
the
“ATC” prefix. Both methods of defining the part number are equivalent, i.e.,
part numbers referenced with the “ATC” prefix are interchangeable to parts
referenced without the “ATC” prefix. Customers are free to use either in
specifying or procuring parts from American Technical Ceramics.
For additional information and catalogs contact your ATC
representative or call direct at (631) 622-4700.
Consult factory for additional performance data.
A M E R I C A N
2
ATC North America
631-622-4700 • sales@atceramics.com
T E C H N I C A L
ATC Europe
+46 8 6800410 • sales@atceramics-europe.com
C E R A M I C S
ATC Asia
+86-755-8366-4318 • sales@atceramics-asia.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
ATC 700 A Capacitors: Mechanical Configurations
ATC
ATC
MIL-PRF-
SERIES
TERM.
55681
& CASE
CODE
SIZE
OUTLINES
CASE SIZE
& TYPE
W/T IS A
TERMINATION SURFACE
Y
BODY DIMENSIONS
Inches (mm)
LENGTH
(L)
WIDTH
(W)
THICKNESS
(T)
LEAD AND TERMINATION
DIMENSIONS AND MATERIALS
OVERLAP
(Y)
.010
+.010 -.005
(0.25
+0.25 -0.13)
.010
+.010 -.005
(0.25
+0.25 -0.13)
.010
+.010 -.005
(0.25
+0.25 -0.13)
.010
+.010 -.005
(0.25
+0.25 -0.13)
MATERIALS
700A
W
CDR12BG
A
Solder Plate
L
W
T
.055
+.015 -.010
.055 ±.015 .057 (1.45)
(1.4
max.
(1.4 ±0.38)
+0.38
-0.25)
.055
+.025 -.010
.055 ±.015 .057 (1.45)
(1.4
(1.4 ±0.38)
max.
+0.64
-0.25)
.055
+.015 -.010
.
055 ±.015 .057 (1.45)
(1.4
max.
(1.4 ±0.38)
+0.38
-0.25)
.055
+.015 -.010
.
055 ±.015 .057 (1.45)
(1.4
max.
(1.4 ±0.38)
+0.38
-0.25)
Tin /Lead, Solder Plated over
Nickel Barrier Termination
Y
700A
P
CDR12BG
A
Pellet
L
W
T
Heavy Tin/Lead Coated,
over Nickel Barrier Termination
700A
T
N/A
A
Lead-Free
Solderable
Nickel Barrier
Y
W
L
T
Lead-Free
and RoHS Compliant
Tin Plated over
Nickel Barrier Termination
Y
700A
CA
CDR11BG
A
Gold Chip
L
W
T
Lead-Free
and RoHS Compliant
Gold Plated over
Nickel Barrier Termination
For a complete military catalog, request American Technical Ceramics document ATC 001-818.
A M E R I C A N
3
ATC North America
631-622-4700 • sales@atceramics.com
T E C H N I C A L
ATC Europe
+46 8 6800410 • sales@atceramics-europe.com
C E R A M I C S
ATC Asia
+86-755-8366-4318 • sales@atceramics-asia.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
ATC 700 A Non-Magnetic Capacitors: Mechanical Configurations
ATC
ATC
MIL-PRF-
SERIES
TERM.
55681
& CASE
CODE
SIZE
OUTLINES
CASE SIZE
& TYPE
W/T IS A
TERMINATION SURFACE
Y
W
BODY DIMENSIONS
Inches (mm)
LENGTH
(L)
WIDTH
(W)
THICKNESS
(T)
LEAD AND TERMINATION
DIMENSIONS AND MATERIALS
OVERLAP
(Y)
.010
+.010 -.005
(0.25
+0.25 -0.13)
.010
+.010 -.005
(0.25
+0.25 -0.13)
.010
+.010 -.005
(0.25
+0.25 -0.13)
MATERIALS
700A
WN
Meets
Require-
ments
A
Non-Mag
Solder Plate
L
T
.055
+.025 -.010
.055 ±.015 .057 (1.45)
(1.4
max.
(1.4 ±0.38)
+0.64
-0.25)
.055
+.035 -.010
.055 ±.015 .057 (1.45)
(1.4
(1.4 ±0.38)
max.
+0.89
-0.25)
.055
+.025 -.010
.
055 ±.015 .057 (1.45)
(1.4
max.
(1.4 ±0.38)
+0.64
-0.25)
Tin/Lead, Solder Plated over
Non-Magnetic Barrier Termination
700A
PN
Meets
Require-
ments
A
Non-Mag
Pellet
A
Non-Mag
Lead-Free
Solderable
Nickel Barrier
Y
W
L
T
Heavy Tin/Lead Coated, over
Non-Magnetic Barrier Termination
700A
TN
Meets
Require-
ments
Y
W
L
T
Lead-Free
and RoHS Compliant
Tin Plated over
Non-Magnetic Barrier Termination
All 700 A Capacitors are available laser marked with ATC's identification, capacitance code and tolerance.
Suggested Mounting Pad Dimensions
L
6R
8J
W
L
T
W
6R8J
T
Case A
Pad Size
A Min.
.070
.050
.080
.060
B Min.
.050
.030
.050
.030
C Min.
.030
.030
.030
.030
D Min.
.130
.090
.130
.090
Horizontal
Electrode Orientation
B
Vertical
Electrode Orientation
B
Vertical Mount
Horizontal Mount
Normal
High Density
Normal
High Density
A
C
D
A M E R I C A N
4
ATC North America
631-622-4700 • sales@atceramics.com
T E C H N I C A L
C E R A M I C S
ATC Europe
ATC Asia
+46 8 6800410 • sales@atceramics-europe.com +86-755-8366-4318 • sales@atceramics-asia.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
ATC 700 A Performance Data
ESR VS. CAPACITANCE
ATC SERIES 700, CASE A
1
10000
Q VS. CAPACITANCE
ATC SERIES 700, CASE A
150 MHz
1000 MHz
1000
500 MHz
100
1000 MHz
ESR (Ohms)
0.1
500 MHz
150 MHz
(Typical)
0.01
1
10
100
10
1
10
Q
(Typical)
100
CAPACITANCE (pF)
(1.0 pF to 100 pF)
CAPACITANCE (pF)
(1.0 pF to 100 pF)
ESR VS. CAPACITANCE
ATC SERIES 700, CASE A
1
1000
Q VS. CAPACITANCE
ATC SERIES 700, CASE A
100
150 MHz
ESR (Ohms)
1000 MHz
Q
0.1
500 MHz
150 MHz
500 MHz
10
1000 MHz
(Typical)
0.01
100
300
1
1000
100
300
(Typical)
1000
CAPACITANCE (pF)
(110 pF to 1000 pF)
CAPACITANCE (pF)
(110 pF to 1000 pF)
A M E R I C A N
5
ATC North America
631-622-4700 • sales@atceramics.com
T E C H N I C A L
ATC Europe
+46 8 6800410 • sales@atceramics-europe.com
C E R A M I C S
ATC Asia
+86-755-8366-4318 • sales@atceramics-asia.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
京公网安备 11010802033920号
EEWORLD
