*4,000 pieces on 7'' reel and 500 pieces on prototype reel. Consult ATC for other options.
The above part number refers to a 600F Series (case size F) 10 pF capacitor, J tolerance (±5%), 250 WVDC, with T termination (Tin Plated over Nickel Barrier,
RoHS Compliant), Laser Marking and Tape and Reel packaging.
**
Marking is optional.
ATC accepts orders for our parts using designations
with
or
without
the
“ATC” prefix. Both methods of defining the part number are equivalent, i.e.,
part numbers referenced with the “ATC” prefix are interchangeable to parts
referenced without the “ATC” prefix. Customers are free to use either in
specifying or procuring parts from American Technical Ceramics.
For additional information and catalogs contact your ATC representative
or call direct at (631) 622-4700.
Consult factory for 500 piece reels for prototyping.
Consult factory for additional performance data.
A M E R I C A N
ATC North America
631-622-4700
•
sales@atceramics.com
T E C H N I C A L
ATC Europe
+46 8 6800410
•
sales@atceramics-europe.com
C E R A M I C S
ATC Asia
86-755-8366-4318
•
sales@atceramics-asia.com
2
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
ATC 600F Series Ultra-Low ESR, High Q NPO RF & Microwave Capacitors
600 F ESR vs Frequency
1.000
ESR (Ohms)
0.100
1.0 pF
3.3 pF
3.9 pF
10 pF
15 pF
47 pF
120 pF
180 pF
(Typical)
0.010
100
1000
10000
Frequency (MHz)
600 F Resonant Frequency Data
100
Frequency (GHz)
10
Fpr
F
s
r
1
( Typical)
0
0.1
1.0
10.0
100.0
1000.0
Capacitance (pF)
ATC 600F Series Data Sheet Test Condition Description
Capacitors horizontally mounted on 23.3-mil thick Rogers RO4350
®
softboard, 52-mil wide, 1/2 oz. Cu traces.
FSR
= lowest frequency at which S11 response, referenced at capacitor edge, crosses real axis on Smith Chart.
FPR
= lowest frequency at which there is a notch in S21 magnitude response.
A M E R I C A N
ATC North America
631-622-4700
•
sales@atceramics.com
T E C H N I C A L
ATC Europe
+46 8 6800410
•
sales@atceramics-europe.com
C E R A M I C S
ATC Asia
86-755-8366-4318
•
sales@atceramics-asia.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
3
ATC 600F Series Ultra-Low ESR, High Q NPO RF & Microwave Capacitors
Outline Dimensions
Y
W
L
T
F (0805)
L: .079 ± .008 (2.01 ± 0.20)
W: .049 ± .008 (1.24 ± 0.20)
T: .051 max. (1.30 max.)
Y: .020 ± 0.01 (0.51 ± 0.25)
Inches (mm)
Suggested Mounting Pad Dimensions
W
T
L
A
1
L
W
Case Sizes L, S and F
Case Size
0402 (1005)
A Min.
.0275
(0.70)
.0393
(1.00)
.0590
(1.50)
B Min.
.0354
(0.90)
.0433
(1.10)
.0512
(1.30)
C Min.
.0157
(0.40)
.0236
(0.60)
.0236
(0.60)
D Min.
.0866
(2.20)
.110
(2.80)
.1259
(3.20)
Inches (mm)
T
A1
Horizontal
Electrode Orientation
B
Vertical
Electrode Orientation
B
0603 (1608)
A
C
0805 (2012)
D
Design Kits
Kit #
Kit
32T
Item #
DK0032T
Each Kit contains a selection of standard capacitor values for circuit prototyping.
Description
600F Series Ultra-low ESR,
High Q Microwave Capacitors
16 different values, 15 pcs. min. per valuE
Cap. Value
Range (pF)
0.1 to 2.0
Cap. Values
(pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9,
1.0, 1.1, 1.2, 1.5
1.6, 1.8, 2.0
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3
Tol.
(pF)
±0.1
Price
$90.00
±0.25
±0.1
±0.25
±5%
Kit
33T
DK0033T
600F Series Ultra-low ESR,
High Q Microwave Capacitors
16 different values, 15 pcs. min. per value
1.0 to 10
3.9, 4.7, 5.6, 6.8, 8.2
10
$90.00
Kit
34T
Kit
35T
DK0034T
600F Series Ultra-low ESR,
High Q Microwave Capacitors
16 different values, 15 pcs. min. per value
10 to 100
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39,
47, 56, 68, 82, 100
±5%
$90.00
DK0035T
600F Series Ultra-low ESR,
High Q Microwave Capacitors
7 different values, 15 pcs. min. per value
100 to 240
100, 120, 150, 180, 200, 220, 240
±5%
$50.00
For Online Kit Orders, Catalog & Application Notes,
Visit: www.atceramics.com
Sales of ATC products are subject to the terms and conditions contained in American Technical Ceramics Corp. Terms and Conditions of Sale(ATC document #001-992 Rev. B 12/05).
Copies of these terms and conditions will be provided upon request. They may also be viewed on ATC's website at www.atceramics.com/productfinder/default.asp. Click on the link for
Terms and Conditions of Sale.
ATC has made every effort to have this information as accurate as possible. However, no responsibility is assumed by ATC for its use, nor for any infringements of rights of third parties which
may result from its use. ATC reserves the right to revise the content or modify its product without prior notice.
