HM86-20075LF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> HM86-20075LF

HM86-20075LF: DescriptionData Line Filter, 2 Function(s), 4.75A, ROHS COMPLIANT PACKAGE-4; CategoryAnalog mixed-signal IC filter; File Size218KB，2 Pages; ManufacturerTT Electronics plc; Websitehttp://www.ttelectronics.com/

Download Datasheet Parametric View All

HM86-20075LF Overview

Data Line Filter, 2 Function(s), 4.75A, ROHS COMPLIANT PACKAGE-4

HM86-20075LF Parametric

Parameter Name	Attribute value
Objectid	1988802040
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum DC resistance	0.0065 Ω
filter type	DATA LINE FILTER
high	6 mm
inductance	75 µH
length	11.4 mm
Installation type	SURFACE MOUNT
Number of functions	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
method of packing	TAPE AND REEL
physical size	L11.4XB8.8XH6.0 (mm)/L0.449XB0.346XH0.236 (inch)
Rated current	4.75 A
width	8.8 mm

Preview

Download Datasheet

View All

Electrical / Environmental

• Operating Temperature Range

• Ambient Temperature, Maximum

• Temperature Rise, Maximum

-40°C to +125°C

+85°C

40°C

Surface Mount Common Mode Chokes

HM86

RoH

liant

Schematic

Specifications @ 25°C

Part

Number

HM86-10025LF

HM86-10040LF

HM86-10070LF

HM86-10095LF

HM86-10150LF

HM86-10275LF

HM86-10320LF

HM86-10400LF

HM86-10500LF

HM86-10620LF

HM86-10750LF

HM86-11100LF

HM86-11300LF

HM86-11600LF

HM86-20035LF

HM86-20050LF

HM86-20075LF

HM86-20105LF

HM86-20175LF

HM86-20260LF

HM86-20310LF

HM86-20420LF

HM86-20480LF

HM86-20620LF

HM86-20780LF

HM86-20950LF

HM86-21250LF

HM86-21600LF

Inductance

(1-2 or 4-3)

µH

30%

25.0

40.0

70.0

95.0

150.0

275.0

320.0

400.0

500.0

620.0

750.0

1100.0

1300.0

1600.0

34.9

50.0

75.0

105.0

175.0

260.0

310.0

420.0

480.0

620.0

780.0

950.0

1250.0

1600.0

Rated

Current

(Max.)

Amps

5.35

4.40

3.60

2.80

2.30

1.85

1.60

1.35

1.10

0.94

0.80

0.67

0.58

0.50

5.70

5.10

4.75

3.95

3.10

2.85

2.45

2.00

1.70

1.45

1.20

1.05

0.88

0.75

Resistance

(1-2 or 4-3)

mΩ Typ.

3.10

3.89

5.35

7.97

16.85

34.53

39.72

42.73

57.43

73.72

98.34

161.2

245.5

350.5

4.63

5.12

6.52

7.92

15.9

19.5

25.3

36.8

50.2

62.1

92.3

132.1

192.2

286.5

Leakage

Inductance

(µH)

Max.

0.22

0.34

0.47

0.80

1.25

1.75

2.00

2.60

3.30

4.00

5.00

6.30

7.30

9.00

0.31

0.46

0.64

0.85

1.30

1.90

2.20

3.00

3.30

4.20

5.10

6.10

7.80

9.60

Interwinding

Capacitance

Typ.

2.00

2.30

2.50

2.80

3.10

3.40

3.60

3.90

4.10

4.30

4.60

4.90

5.10

5.40

2.80

3.05

3.30

3.50

3.70

3.90

4.15

4.40

4.65

4.85

5.10

5.35

5.55

5.80

Height

Max.

5.2

6.0

Figure

Notes: (1) Inductance, leakage inductance and interwinding capacitance are measured at 100kHz, 0.1Vrms.

(2) Leakage inductance is measured at pin-1-2 with N2 (pin 4-3) winding shorted.

(3) It is recommended that the temperature of the component (ambient plus temperature rise) does not exceed 125°C under worst case operating condtions.

120

MAGNETIC COMPONENTS SELECTOR GUIDE 2009/10 EDITION

We reserve the right to change specifications without prior notice.

www.bitechnologies.com
