CM200DU-12H
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Dual IGBTMOD™
U-Series Module
200 Amperes/600 Volts
T
C
Measured
Point
E
F
G
E2
A
B
H
J
D
C
G1 E1
G2 G2
U
C1
3-M5 Nuts
O
P
O
Q
CM
C2E1
K
2 - Mounting
Holes
(6.5 Dia.)
V
L
M
N
0.110 - 0.5 Tab
P
S
R
T
E2
G2
Description:
Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of two IGBT Transistors in a half-
bridge configuration with each tran-
sistor having a reverse-connected
super-fast recovery free-wheel
diode. All components and inter-
connects are isolated from the
heat sinking baseplate, offering
simplified system assembly and
thermal management.
Features:
□
Low Drive Power
□
Low V
CE(sat)
□
Discrete Super-Fast Recovery
Free-Wheel Diode
□
Isolated Baseplate for Easy
Heat Sinking
Applications:
□
AC Motor Control
□
Motion/Servo Control
□
UPS
□
Welding Power Supplies
□
Laser Power Supplies
Ordering Information:
Example: Select the complete
module number you desire from
the table - i.e. CM200DU-12H is a
600V (V
CES
), 200 Ampere Dual
IGBTMOD™ Power Module.
Type
CM
Current Rating
Amperes
200
V
CES
Volts (x 50)
12
C2E1
E2
C1
E1
G1
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
K
L
Inches
3.7
3.15±0.01
1.89
0.94
0.28
0.67
0.91
0.91
0.43
0.71
0.16
Millimeters
94.0
80.0±0.25
48.0
24.0
7.0
17.0
23.0
23.0
11.0
18.0
4.0
Dimensions
M
N
O
P
Q
R
S
T
U
V
Inches
0.47
0.53
0.1
0.63
0.98
Millimeters
12.0
13.5
2.5
16.0
25.0
1.18 +0.04/-0.02 30.0 +1.0/-0.5
0.3
0.83
0.16
0.51
7.5
21.2
4.0
13.0
29
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CM200DU-12H
Dual IGBTMOD™ U-Series Module
200 Amperes/600 Volts
Absolute Maximum Ratings,
T
j
= 25
°C
unless otherwise specified
Ratings
Junction Temperature
Storage Temperature
Collector-Emitter Voltage (G-E SHORT)
Gate-Emitter Voltage (C-E SHORT)
Collector Current (T
c
= 25°C)
Peak Collector Current
Emitter Current** (T
c
= 25°C)
Peak Emitter Current**
Maximum Collector Dissipation (T
c
= 25°C, T
j
≤
150°C)
Mounting Torque, M5 Main Terminal
Mounting Torque, M6 Mounting
Weight
Isolation Voltage (Main Terminal to Baseplate, AC 1 min.)
Symbol
T
j
T
stg
V
CES
V
GES
I
C
I
CM
I
E
I
EM
P
c
–
–
–
V
iso
CM200DU-12H
-40 to 150
-40 to 125
600
±20
200
400*
200
400*
650
31
40
310
2500
Units
°C
°C
Volts
Volts
Amperes
Amperes
Amperes
Amperes
Watts
in-lb
in-lb
Grams
Volts
* Pulse width and repetition rate should be such that the device junction temperature (T
j
) does not exceed T
j(max)
rating.
**Represents characteristics of the anti-parallel, emitter-to-collector free-wheel diode (FWDi).
Static Electrical Characteristics,
T
j
= 25
°C
unless otherwise specified
Characteristics
Collector-Cutoff Current
Gate Leakage Voltage
Gate-Emitter Threshold Voltage
Collector-Emitter Saturation Voltage
Symbol
I
CES
I
GES
V
GE(th)
V
CE(sat)
Q
G
V
EC
Test Conditions
V
CE
= V
CES
, V
GE
= 0V
V
GE
= V
GES
, V
CE
= 0V
I
C
= 20mA, V
CE
= 10V
I
C
= 200A, V
GE
= 15V, T
j
= 25°C
I
C
= 200A, V
GE
= 15V, T
j
= 125°C
Total Gate Charge
Emitter-Collector Voltage**
V
CC
= 300V, I
C
= 200A, V
GE
= 15V
I
E
= 200A, V
GE
= 0V
Min.
–
–
4.5
–
–
–
–
Typ.
–
–
6
2.4
2.6
400
–
Max.
1
0.5
7.5
3.0
–
–
2.6
Units
mA
µA
Volts
Volts
Volts
nC
Volts
**Represents characteristics of the anti-parallel, emitter-to-collector free-wheel diode (FWDi).
Dynamic Electrical Characteristics,
T
j
= 25
°C
unless otherwise specified
Characteristics
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Resistive
Load
Switch
Times
Turn-on Delay Time
Rise Time
Turn-off Delay Time
Fall Time
Symbol
C
ies
C
oes
C
res
t
d(on)
t
r
t
d(off)
t
f
t
rr
Q
rr
V
CC
= 300V, I
C
= 200A,
V
GE1
= V
GE2
= 15V,
R
G
= 3.1 , Resistive
Load Switching Operation
I
E
= 200A, di
E
/dt = -400A/µs
I
E
= 200A, di
E
/dt = -400A/µs
V
CE
= 10V, V
GE
= 0V
Test Conditions
Min.
–
–
–
–
–
–
–
–
–
Typ.
–
–
–
–
–
–
–
–
0.48
Max.
17.6
9.6
2.6
150
400
300
300
160
–
Units
nf
nf
nf
ns
ns
ns
ns
ns
µC
Diode Reverse Recovery Time**
Diode Reverse Recovery Charge**
**Represents characteristics of the anti-parallel, emitter-to-collector free-wheel diode (FWDi).
Thermal and Mechanical Characteristics,
T
j
= 25
°C
unless otherwise specified
Characteristics
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Case
Contact Thermal Resistance
Symbol
R
th(j-c)
Q
R
th(j-c)
D
R
th(c-f)
Test Conditions
Per IGBT 1/2 Module
Per FWDi 1/2 Module
Per Module, Thermal Grease Applied
Min.
–
–
–
Typ.
–
–
0.035
Max.
0.19
0.35
–
Units
°C/W
°C/W
°C/W
30
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CM200DU-12H
Dual IGBTMOD™ U-Series Module
200 Amperes/600 Volts
OUTPUT CHARACTERISTICS
(TYPICAL)
TRANSFER CHARACTERISTICS
(TYPICAL)
COLLECTOR-EMITTER
SATURATION VOLTAGE CHARACTERISTICS
(TYPICAL)
400
COLLECTOR CURRENT, I
C
, (AMPERES)
V
GE
= 20V
320
15
320
COLLECTOR-EMITTER
SATURATION VOLTAGE, V
CE(sat)
, (VOLTS
)
T
j
= 25
o
C
400
14
COLLECTOR CURRENT, I
C
, (AMPERES)
5
V
CE
= 10V
T
j
= 25°C
T
j
= 125°C
V
GE
= 15V
T
j
= 25°C
T
j
= 125°C
13
4
3
2
1
12
240
11
240
160
10
160
80
0
80
9
8
0
0
2
4
6
8
10
COLLECTOR-EMITTER VOLTAGE, V
CE
, (VOLTS)
0
0
4
8
12
16
20
0
80
160
240
320
400
GATE-EMITTER VOLTAGE, V
GE
, (VOLTS)
COLLECTOR-CURRENT, I
C
, (AMPERES)
COLLECTOR-EMITTER
SATURATION VOLTAGE CHARACTERISTICS
(TYPICAL)
FREE-WHEEL DIODE
FORWARD CHARACTERISTICS
(TYPICAL)
CAPACITANCE VS. V
CE
(TYPICAL)
10
COLLECTOR-EMITTER
SATURATION VOLTAGE, VCE(sat), (VOLTS)
10
3
T
j
= 25°C
10
3
T
j
= 25°C
CAPACITANCE, C
ies
, C
oes
, C
res
, (nF)
V
GE
= 0V
f = 1MHz
8
6
4
2
I
C
= 400A
EMITTER CURRENT, I
E
, (AMPERES)
10
2
I
C
= 200A
10
2
10
1
C
ies
C
oes
10
0
C
res
I
C
= 80A
0
0
4
8
12
16
20
GATE-EMITTER VOLTAGE, V
GE
, (VOLTS)
10
1
0.6
1.0
1.4
1.8
2.2
2.6
3.0
10
-1
10
-1
10
0
10
1
10
2
EMITTER-COLLECTOR VOLTAGE, V
EC
, (VOLTS)
COLLECTOR-EMITTER VOLTAGE, V
CE
, (VOLTS)
HALF-BRIDGE
SWITCHING CHARACTERISTICS
(TYPICAL)
REVERSE RECOVERY CHARACTERISTICS
(TYPICAL)
di/dt = -400A/µsec
T
j
= 25°C
REVERSE RECOVERY CURRENT, I
rr
, (AMPERES)
GATE CHARGE, V
GE
10
4
REVERSE RECOVERY TIME, t
rr
, (ns)
10
4
V
CC
= 300V
V
GE
=
±15V
R
G
= 3.1
Ω
T
j
= 125°C
10
2
20
GATE-EMITTER VOLTAGE, V
GE
, (VOLTS)
I
C
= 200A
16
12
8
4
SWITCHING TIME, (ns)
V
CC
= 200V
V
CC
= 300V
10
3
t
f
t
d(off)
10
3
I
rr
10
1
10
2
t
d(on)
t
r
10
2
t
rr
10
0
10
1
10
1
10
2
COLLECTOR CURRENT, I
C
, (AMPERES)
10
3
10
1
10
1
10
-1
10
2
EMITTER CURRENT, I
E
, (AMPERES)
10
3
0
0
100
200
300
400
500
600
GATE CHARGE, Q
G
, (nC)
31
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CM200DU-12H
Dual IGBTMOD™ U-Series Module
200 Amperes/600 Volts
NORMALIZED TRANSIENT THERMAL IMPEDANCE, Z
th(j-c)
Z
th
= R
th
• (NORMALIZED VALUE)
10
-3
10
1
10
-2
10
-1
10
0
10
1
NORMALIZED TRANSIENT THERMAL IMPEDANCE, Z
th(j-c)
Z
th
= R
th
• (NORMALIZED VALUE)
TRANSIENT THERMAL
IMPEDANCE CHARACTERISTICS
(IGBT)
TRANSIENT THERMAL
IMPEDANCE CHARACTERISTICS
(FWDi)
10
-3
10
1
10
-2
10
-1
10
0
10
1
10
0
Single Pulse
T
C
= 25°C
Per Unit Base = R
th(j-c)
= 0.19°C/W
10
0
Single Pulse
T
C
= 25°C
Per Unit Base = R
th(j-c)
= 0.35°C/W
10
-1
10
-1
10
-1
10
-1
10
-2
10
-2
10
-2
10
-2
10
-3
10
-5
TIME, (s)
10
-3
10
-4
10
-3
10
-3
10
-5
TIME, (s)
10
-3
10
-4
10
-3
