DATA SHEET
ANTI-SULFURATED CHIP RESISTORS
AUTOMOTIVE GRADE
AA series
±5%, ±1%, ±0.5%
sizes 0201/0402/0603/0805/1206/
1210/1218/2010/2512
RoHS compliant & Halogen free
Product specification – December 08, 2015 V.3
Product specification
2
10
Chip Resistor Surface Mount
AA
SERIES
0201 to 2512
SCOPE
This specification describes AA0201
to AA2512 chip resistors with lead-
free terminations made by thick film
process.
APPLICATIONS
Car electronics
ORDERING INFORMATION - GLOBAL PART NUMBER
Part number is identified by the series name, size, tolerance, packaging
type, temperature coefficient, taping reel and resistance value.
GLOBAL PART NUMBER
AA XXXX X X X XX XXXX L
(1)
(2) (3) (4)
(5)
(6)
(7)
(1) SIZE
0201 / 0402 / 0603 / 0805 / 1206 / 1210 / 1218 / 2010 / 2512
Engine control unit
Body control system
Safety devices
(2) TOLERANCE
D =± 0.5%
F = ± 1%
J = ± 5% (for Jumper ordering, use code of J)
FEATURES
Superior resistance against sulfur
containing atmosphere
AEC-Q200 qualified
Moisture sensitivity level: MSL1
AA series soldering is compliant
with J-STD-020D
Halogen free epoxy
RoHS compliant
Reduce environmentally
hazardous waste
High component and equipment
reliability
The resistors are 100% performed
by automatic optical inspection
(3) PACKAGING TYPE
R = Paper/PE taping reel
K = Embossed taping reel
(4) TEMPERATURE COEFFICIENT OF RESISTANCE
–
= Base on spec
(5) TAPING REEL
07 = 7 inch dia. Reel
13 = 13 inch dia. Reel
(6) RESISTANCE VALUE
1Ω to 10 MΩ
There are 2~4 digits indicated the resistance value. Letter R/K/M is decimal point, no
need to mention the last zero after R/K/M, e.g.1K2, not 1K20.
(7) DEFAULT CODE
Letter L is the system default code for ordering only.
(Note)
Resistance rule of global part
number
Resistance coding
Example
rule
XRXX
(1 to 9.76
Ω)
XXRX
(10 to 97.6
Ω)
XXXR
(100 to 976
Ω)
XKXX
(1 to 9.76 KΩ)
XMXX
(1 to 9.76 MΩ)
XXMX
(10 MΩ)
1R = 1
Ω
1R5 = 1.5
Ω
9R76 = 9.76
Ω
10R = 10
Ω
97R6 = 97.6
Ω
100R = 100
Ω
976R = 976
Ω
1K = 1,000
Ω
9K76 = 9760
Ω
1M = 1,000,000
Ω
9M76= 9,760,000
Ω
10M = 10,000,000
Ω
O
RDERING EXAMPLE
The ordering code for an AA0402 chip
resistor, value 100 KΩ with ±1%
tolerance, supplied in 7-inch tape reel is:
AA0402FR-07100KL
NOTE
1. All our R-Chip products are RoHS
compliant and Halogen free. "LFP" of the
internal 2D reel label states "Lead-Free
Process".
2. On customized label, "LFP" or specific
symbol can be printed.
www.yageo.com
Dec 08, 2015 V.3
Product specification
3
10
Chip Resistor Surface Mount
AA
SERIES
0201 to 2512
MARKING
AA0201 / AA0402
No marking
ynsc007
Fig. 1
AA0603 / AA0805 / AA1206 / AA1210 / AA2010 / AA2512
03
Fig. 2
YNSC001
E-24 series: 3 digits, ± 5%
First two digits for significant figure and 3rd digit for number of zeros
Value=10 KΩ
AA0603
0
YNSC037
E-24 series: 3 digits, ± 1%
One short bar under marking letter
Fig. 3
Value = 24
Ω
E-96 series: 3 digits, ± 1%
First two digits for E-96 marking rule and 3rd letter for number of zeros
Fig. 4
Value = 12.4 KΩ
AA0805 / AA1206 / AA1210 / AA2010 / AA2512
00
AA1218
YNSC004
Both E-24 and E-96 series: 4 digits, ± 1%
First three digits for significant figure and 4th digit for number of zeros
Fig. 5
Value = 10 KΩ
YNSC099
E-24 series: 3 digits, ± 5%
First two digits for significant figure and 3rd digit for number of zeros
Fig. 6
Value = 10 KΩ
00
YNSC103
Both E-24 and E-96 series: 4 digits, ± 1%
First three digits for significant figure and 4th digit for number of zeros
Fig. 7
Value = 10 KΩ
NOTE
For further marking information, please refer to data sheet “Chip resistors marking”. Marking of AA series is the same as RC series.
www.yageo.com
Dec 08, 2015 V.3
Product specification
4
10
Chip Resistor Surface Mount
AA
SERIES
0201 to 2512
CONSTRUCTION
The resistors are constructed on top of an automotive
grade ceramic body. Internal metal electrodes are
added at each end and connected by a resistive glaze.
The resistive glaze is covered by a lead-free glass.
The composition of the glaze is adjusted to give the
approximately required resistance value and laser
trimming of this resistive glaze achieves the value within
tolerance. The whole element is covered by a protective
overcoat. Size 0603 and bigger is marked with the
resistance value on top. Finally, the two external
terminations (Ni / matte tin) are added, as shown in Fig.8.
OUTLINES
marking layer
overcoat
protective glass
resistive layer
(Jumper chip is a conductor)
inner electrode
termination(Ni/matte tin)
inner electrode
YNSC088
ceramic substrate
Fig. 8
Chip resistor outlines
DIMENSIONS
Table 1
For outlines, please refer to Fig. 9
TYPE
L (mm)
AA0201
AA0402
AA0603
AA0805
AA1206
AA1210
AA1218
AA2010
AA2512
0.60 ± 0.03
1.00 ± 0.05
1.60 ± 0.10
2.00 ± 0.10
3.10 ± 0.10
3.10 ± 0.10
3.10 ± 0.10
5.00 ± 0.10
6.35 ± 0.10
W (mm)
0.30 ± 0.03
0.50 ± 0.05
0.80 ± 0.10
1.25 ± 0.10
1.60 ± 0.10
2.60 ± 0.15
4.60 ± 0.10
2.50 ± 0.15
3.20 ± 0.15
H (mm)
0.23 ± 0.03
0.35 ± 0.05
0.45 ± 0.10
0.50 ± 0.10
0.55 ± 0.10
0.57 ± 0.10
0.57 ± 0.10
0.57 ± 0.10
0.57 ± 0.10
I
1
(mm)
0.12 ± 0.05
0.20 ± 0.10
0.25 ± 0.15
0.35 ± 0.20
0.45 ± 0.20
0.45 ± 0.20
0.45 ± 0.20
0.55 ± 0.20
0.60 ± 0.20
I
2
(mm)
0.15 ± 0.05
0.25 ± 0.10
0.25 ± 0.15
0.35 ± 0.20
0.50 ± 0.20
0.50 ± 0.20
0.50 ± 0.20
0.55 ± 0.20
0.60 ± 0.20
For dimension, please refer to Table 1
AA0201 / AA0402
AA0603/0805/1206/
1210/2010/2512
AA1218
I
1
Side view for all type
I
1
I
1
W
W
W
I
2
H
Fig. 9
Chip resistor dimensions
L
L
L
YNSC096
www.yageo.com
Dec 08, 2015 V.3
Product specification
5
10
Chip Resistor Surface Mount
AA
SERIES
0201 to 2512
ELECTRICAL CHARACTERISTICS
Table 2
CHARACTERISTICS
TYPE
Operating
Max.
Max.
Dielectric
RESISTANCE
RANGE Temperature Range Working Overload Withstanding
Voltage Voltage
Voltage
Temperature
Coefficient
of Resistance
Jumper Criteria
AA0201
25V
50V
50V
1Ω
≤
R
≤
10Ω, Rated Current 0.5A
-100/+400 ppm/°C
10Ω < R
≤
10 MΩ,
± 300 ppm/°C
Max. Current 1.0A
Rated Current
Max. Current
Rated Current
Max. Current
Rated Current
1A
2A
1A
2A
2A
AA0402
AA0603
AA0805
AA1206
AA1210
AA1218
AA2010
AA2512
5% (E24)
1Ω≤ R
≤
22MΩ
(0201: Max. 10MΩ.
1218: Max. 1MΩ)
0.5%, 1% (E24/E96)
1Ω≤ R
≤10MΩ
(1218: Max. 1MΩ)
Jumper < 50mΩ
50 V
75V
150 V
–55
°C to +155 °C
200 V
200 V
200 V
200 V
200 V
100 V
150 V
300 V
400 V
500 V
500 V
500 V
500 V
100 V
150 V
300 V
500 V
Max. Current 5A
1Ω
≤
R
≤
10Ω,
± 200 ppm/°C Rated Current 2A
10Ω < R
≤
10 MΩ, Max. Current 10A
± 150 ppm/°C Rated Current 2A
500 V 10 MΩ < R
≤
22 MΩ,
Max. Current 10A
± 200 ppm/°C
Rated Current 6A
500 V
Max. Current 10A
500 V
500 V
Rated Current
Rated Current
2A
2A
Max. Current 10A
Max. Current 10A
www.yageo.com
Dec 08, 2015 V.3
