Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.00 / 5.08 mm (0.197 / 0.200 inch) |
Socket connectors, tension clamp connection, pitch 5.00/5.08 | BLZP 5.00-5.08/90/270 | BLZP 5.00/270 SN
Material data
Connectable conductors
Clamping range, min.
Clamping range, max.
Conductor connection cross-section AWG, min.
Conductor connection cross-section AWG, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
w. wire end ferrule, DIN 46228 pt 1, min
with wire end ferrule, DIN 46228 pt 1, max.
w. plastic collar ferrule, DIN 46228 pt 4, min.
with plastic collar ferrule, DIN 46228 pt 4, max.
Gauge to EN 60999 a x b; ø
DIN IEC rating data
Rated current, min. No. of poles (Tu=20°C)
Rated current, max. No. of poles (Tu=20°C)
Rated current, no. of poles (Tu=40°C), min.
Rated current, no. of poles (Tu=40°C), max.
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage at overvoltage category/pollution
degree III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group B)
Rated current (use group B)
Rated voltage (Use group C)
Rated voltage (use group D)
Rated current (use group D)
Wire cross-section, AWG, min.
Wire cross-section, AWG, max.
UL 1059 rating data
Rated voltage (use group B)
Rated current (use group B)
Rated voltage (use group C)
Rated voltage
Rated current
Wire cross-section, AWG, min.
0.13 mm²
4 mm²
AWG 26
AWG 12
0.2 mm²
4 mm²
0.2 mm²
4 mm²
0.2 mm²
4 mm²
0.2 mm²
2.5 mm²
2.8 mm x 2.4 mm
15.5 A
13 A
12 A
10.5 A
400 V
320 V
250 V
4 kV
4 kV
4 kV
3 x 1s with 120 A
300 V
10 A
50 V
300 V
10 A
AWG 26
AWG 12
300 V
10 A
50 V
300 V
10 A
AWG 26
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.00 / 5.08 mm (0.197 / 0.200 inch) |
Socket connectors, tension clamp connection, pitch 5.00/5.08 | BLZP 5.00-5.08/90/270 | BLZP 5.00/270 SN
UL 1059 rating data
Wire cross-section, AWG, max.
Approvals
Approvals institutes
Classifications
eClass 6.0
Notes
Notes
AWG 12
CURUS
27-26-07-08
Similar products
Order No.
1958870000
1958860000
1958850000
1958840000
1958830000
1958820000
1958810000
1958800000
1958790000
1958780000
1959150000
1958760000
1958750000
1958740000
1958730000
1958720000
1958710000
Part designation
BLZP 5.00/02/270 SN OR BX
BLZP 5.00/03/270 SN OR BX
BLZP 5.00/04/270 SN OR BX
BLZP 5.00/05/270 SN OR BX
BLZP 5.00/06/270 SN OR BX
BLZP 5.00/07/270 SN OR BX
BLZP 5.00/08/270 SN OR BX
BLZP 5.00/09/270 SN OR BX
BLZP 5.00/10/270 SN OR BX
BLZP 5.00/11/270 SN OR BX
BLZP 5.00/12/270 SN OR BX
BLZP 5.00/14/270 SN OR BX
BLZP 5.00/15/270 SN OR BX
BLZP 5.00/16/270 SN OR BX
BLZP 5.00/17/270 SN OR BX
BLZP 5.00/18/270 SN OR BX
BLZP 5.00/19/270 SN OR BX
Version
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 2, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 3, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 5, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 7, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 8, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 9, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 10, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 11, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 12, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 14, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 15, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 16, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 17, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 18, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 19, 90°, Box
-3-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 5.00 / 5.08 mm (0.197 / 0.200 inch) |
Socket connectors, tension clamp connection, pitch 5.00/5.08 | BLZP 5.00-5.08/90/270 | BLZP 5.00/270 SN
1958700000
1958690000
1958680000
1958670000
1958660000
BLZP 5.00/20/270 SN OR BX
BLZP 5.00/21/270 SN OR BX
BLZP 5.00/22/270 SN OR BX
BLZP 5.00/23/270 SN OR BX
BLZP 5.00/24/270 SN OR BX
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 20, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 21, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 22, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 23, 90°, Box
PCB plug-in connector, Clamping yoke connection, Clamping range,
max.: 4 mm², Pitch in mm: 5 mm, No. of poles: 24, 90°, Box
-4-
