Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.50 / 7.62 mm (0.295 / 0.300 inch) | Plug
connectors, solder connection, pitch 7.50/7.62 | SL 7.50-7.62/90 | SL 7.50/90B
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Fitted to PCB
Outgoing elbow
Pitch
Pitch in inch
No. of poles
Solder pin length
Can be coded
No. of rows
No. of solder pins per pole
Dia. of fitting hole
Fitting hole tolerance
L1 in mm
L1 in inch
Insulation resistance
1628530000
SL 7.50/8/90B3.2SN OR
PCB plug-in connector, Male connectors, Soldered
connection, Pitch: 7.50 mm, No. of poles: 8, 90°,
Box
4008190201333
50 pc(s).
Soldered connection
90°
7.5 mm
0.295 inch
8
3.2 mm
Yes
1
1
1.3 mm
+ 0.1 mm
52.5 mm
2.067 inch
1 MΩ
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.50 / 7.62 mm (0.295 / 0.300 inch) | Plug
connectors, solder connection, pitch 7.50/7.62 | SL 7.50-7.62/90 | SL 7.50/90B
System parameters
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
Safe from finger touch, plugged
PBT
orange
Similar to RAL 2000
IIIa
V-0
>= 200
CuSn
tinned
-25 °C
100 °C
-25 °C
55 °C
80 %
18.5 A
17 A
16 A
14.5 A
500 V
6 kV
630 V
6 kV
800 V
6 kV
3 x 1s with 120 A
300 V
10 A
300 V
10 A
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.50 / 7.62 mm (0.295 / 0.300 inch) | Plug
connectors, solder connection, pitch 7.50/7.62 | SL 7.50-7.62/90 | SL 7.50/90B
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
SL.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1628470000
1628480000
1628490000
1628500000
1628510000
1628520000
1628540000
1628550000
1628560000
1628570000
Part designation
SL 7.50/2/90B3.2SN OR
SL 7.50/3/90B3.2SN OR
SL 7.50/4/90B3.2SN OR
SL 7.50/5/90B3.2SN OR
SL 7.50/6/90B3.2SN OR
SL 7.50/7/90B3.2SN OR
SL 7.50/9/90B3.2SN OR
SL 7.50/10/90B3.2SN OR
SL 7.50/11/90B3.2SN OR
SL 7.50/12/90B3.2SN OR
Version
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 2, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 3, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 5, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 7, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 9, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 10, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 11, 90°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 7.50 mm, No. of poles: 12, 90°, Box
-3-
