4
THIS DRAWING IS UNPUBLISHED.
RELEASED FOR PUBLICATION
BY -
ALL RIGHTS RESERVED.
20
3
2
REVISIONS
P
LTR
DESCRIPTION
1
DATE
DWN
APVD
C
COPYRIGHT
20
P/N 0-293270-1 AS SHOWN
POLARIZATION KEY HV-1
P/N 0-293270-2 AS SHOWN
POLARIZATION KEY HV-1
S
T
V
Y
REMOVED CABLE H05VVH2-F
REVISED PER ECR-14-006605
ECR-14-018570
REVISED PER ECR-17-008252
22AUG2012
21MAY2014
15DEC2014
19JUN2017
MZ
RS
KR
RK
JC
DD
JC
JL
19.0
D
34.0 DIMENSION AT
PRE-LOKING CONDITION
10 $
9.8
43.8
29.0 DIMENSION AT
CLOSED CONDITION
D
20.0
SECTION
SECTION
A-A
CABLE CONFIGURATION
CABLE H03VVH2-F
2x0.75 mm2
A-A
3.0
11.0
SECTION
A-A
3.40
C
0.50
5.60
C
0.60
P/N 0-293270-3 AS SHOWN
POLARIZATION KEY HV-1
P/N 0-293270-4 AS SHOWN
POLARIZATION KEY HV-1
29.0 DIMENSION AT
CLOSED CONDITION
B
NOTES:
CONTACTS BRASS PRE TINNED
HOUSINGS POLYAMMIDE UL94 V0
B
293270-9
293270-8
293270-7
293270-6
293270-5
END CONNECTOR WITHOUT FLANGE
END CONNECTOR WITHOUT FLANGE
CONNECTOR WITHOUT FLANGE
END CONNECTOR WITH FLANGE
CONNECTOR WITH FLANGE
END CONNECTOR WITHOUT FLANGE
CONNECTOR WITHOUT FLANGE
END CONNECTOR WITH FLANGE
CONNECTOR WITH FLANGE
DESCRIPTION
HV-1
LV-2
LV-2
LV-2
LV-2
HV-1
HV-1
HV-1
HV-1
POL.
KEY
BLACK
YELLOW
YELLOW
YELLOW
YELLOW
WHITE
WHITE
WHITE
WHITE
COLOR
SECTION
A-A
SECTION
A-A
293270-4
293270-3
293270-2
293270-1
MISSING DIMENSION SEE P/N 0-...-1
THIS DRAWING IS A CONTROLLED DOCUMENT.
DWN
CHK
DIMENSIONS:
NOTES
PART NUMBER
A
A. Vecchia
G. Turco
18JAN2007
18JAN2007
24MAY2007
NAME
TE Connectivity
mm
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
APVD
A
MATERIAL
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
ANGLES
FINISH
PRODUCT SPEC
G. Turco
0.3
0.05
APPLICATION SPEC
108-94018
114-20131
SIZE
BUS BAR 2 POSITION
SEALED
CAGE CODE
DRAWING NO
RESTRICTED TO
WEIGHT
-
1471-9 (3/13)
-
CUSTOMER DRAWING
A2
00779
293270
SCALE
2:1
SHEET
1
OF
2
REV
-
Y
