ZPD
CONNECTOR
Emboss Tape
1.5mm pitch/Disconnectable Crimp style connectors
• Secure locking structure
• Low insertion force
• Suction area for picking up
• Improvement of engagement with prying
Specifications –––––––––––––––––––
• Current rating: 2A AC, DC (AWG #24)
• Voltage rating: 100V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/30m
Ω
max.
After environmental testing/60m
Ω
max.
• Insulation resistance:
500M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable wire: Conductor size/AWG #28 to #24
Insulation O.D./0.8 to 1.2mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
In order to correspond to the high-density
PC board designing, this ZPD connector is
designed as 1.5mm pitch double row type
connector with secure locking device.
Low insertion force is realized and good
mating feeling is also prepared, and these
provide the certain mating operation.
PC board layout (viewed from component side) and Assembly layout
Top entry type
A
Connector
outline
0.7
±0.05
±0.05
Side entry type
(8.6)
1.5
±0.05
±0.05
±0.05
(10.5)
1.7
(9.5)
3.5
±0.1
2.8
±0.05
8.95
±0.05
1
C
1
1.7
±0.1
±0.1
±0.1
0.7
±0.05
±0.05
1.5
A
±0.05
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SZPD-002T-P0.3
6.6
2.9
3.15
1.07
1
Applicable wire
mm
2
AWG#
0.08∼0.21
28∼24
1.7
±0.05
Insulation O.D.
(mm)
0.8∼1.2
Q´ty /
reel
16,000
Material and Finish
Copper alloy, tin-plated (reflow treatment)
RoHS compliance
Crimping
machine
Crimp applicator
MKS-L
Contact
Applicator
Dies
MK/SZE-002-03
Crimp applicator with dies
APLMK SZE002-03
SZPD-002T-P0.3
AP-K2N
1
(9.2)
8.3
Circuit No.N
Circuit No.N-1
Circuit No.2
Circuit No.1
Circuit No.1
Circuit No.2
Circuit No.N-1
Circuit No.N
1.7
±0.1
Connector
outline
±0.1
ZPD CONNECTOR
Housing
(10 circuits)
B
8.6
Circuit No.1 mark
Circuits
10
Model No.
ZPDR-10V-S
ZPDR-12V-S
ZPDR-14V-S
ZPDR-16V-S
ZPDR-18V-S
ZPDR-20V-S
ZPDR-22V-S
ZPDR-24V-S
ZPDR-26V-S
ZPDR-28V-S
ZPDR-30V-S
Material
Dimensions (mm)
A
B
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
11.2
12.7
14.2
15.7
17.2
18.7
20.2
21.7
23.2
24.7
26.2
Q'ty / bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
7.6
12
14
16
18
20
8.6
Circuit No.1 mark
1.5
A
(12 to 24 circuits)
B
22
24
26
28
30
1.5
A
7.6
(26 to 30 circuits)
PBT, UL94V-0, natural
B
8.6
Circuit No.1 mark
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
ZPDR-10V-S-
S...natural Z...ivory MG...moss green TR...tomato red
DPK...dark pink E...blue
7.6
1.5
A
Shrouded header
Top entry type
B
Side entry type
B
7.4
1
Circuit No.1 mark
(5.7)
5.55
(10 circuits)
(10 circuits)
Circuit No.1 mark
0.3
6.7
0.6
7.85
1.5
A
(12 to 30 circuits)
B
Circuit No.1 mark
(5.7)
5.55
(12 to 30 circuits)
7.4
1
1.5
A
B
0.3
6.7
0.6
Circuit No.1 mark
7.85
A
1.5
1.5
A
Top entry type
Circuits
10
12
14
16
18
20
22
24
26
28
30
Side entry type
Model No.
Dimensions (mm)
A
B
C
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
11.2
12.7
14.2
15.7
17.2
18.7
20.2
21.7
23.2
24.7
26.2
9.2
10.7
12.2
13.7
15.2
16.7
18.2
19.7
21.2
22.7
24.2
Q'ty /
reel
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
Circuits
10
12
14
16
18
20
22
24
26
28
30
Model No.
SM10B-ZPDSS-TF
SM12B-ZPDSS-TF
SM14B-ZPDSS-TF
SM16B-ZPDSS-TF
SM18B-ZPDSS-TF
SM20B-ZPDSS-TF
SM22B-ZPDSS-TF
SM24B-ZPDSS-TF
SM26B-ZPDSS-TF
SM28B-ZPDSS-TF
SM30B-ZPDSS-TF
Dimensions (mm)
A
B
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
11.2
12.7
14.2
15.7
17.2
18.7
20.2
21.7
23.2
24.7
26.2
(8)
(8)
Q'ty /
reel
700
700
700
700
700
700
700
700
700
700
700
BM10B-ZPDSS-TF
BM12B-ZPDSS-TF
BM14B-ZPDSS-TF
BM16B-ZPDSS-TF
BM18B-ZPDSS-TF
BM20B-ZPDSS-TF
BM22B-ZPDSS-TF
BM24B-ZPDSS-TF
BM26B-ZPDSS-TF
BM28B-ZPDSS-TF
BM30B-ZPDSS-TF
Material and Finish
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Polyamide, UL94V-0, natural
Reinforcing tab: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Material and Finish
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Polyamide, UL94V-0, natural
RoHS compliance
This product displays (LF)(SN) on a label.
This products listed above are supplied on embossed-tape.
RoHS compliance
This product displays (LF)(SN) on a label.
This products listed above are supplied on embossed-tape.
<For reference>
As the color identification, the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
BM10B-ZPDSS-TF- SM10B-ZPDSS-TF-
S...natural Z...ivory MG...moss green TR...tomato red DPK...dark pink E...blue
2
