POLYESTER FILM
PULSE CAPACITOR
NON-INDUCTIVE, EXTENDED FOIL, WAX IMPREGNATED, WRAP AND FILL
TYPE 6001 & 6002
APPLICATION
Timing light and heavy duty pulse circuits.
GENERAL SPECIFICATION
1.
OPERATING TEMPERATURE:
-40°C to 85°C
Derate DC voltage 1.5%/°C above
85°C to 100°C
2.
VOLTAGE RANGE:
400 and 600 VDC
3.
CAPACITANCE RANGE:
0.1 to 2.2 Mfd
4.
DIELECTRIC STRENGTH:
250° of rated voltage for 5 sec. 25°C
5.
CAPACITANCE TOLERANCE:
±5%, ±10% and ±20%
6.
INSULATION RESISTANCE:
50,000 Meg. Ohm min. at 25°C
FEATURES
• Will withstand highest volts/micron thickness of any
film capacitor.
• Meet requirements for steep voltage spike
characteristics.
• Excellent humidity protection that comply with
MIL–STD–202 method 103B.
• Specials available upon request.
Part Number Example: See Page F.2
Maximum pulse rise time (dv/dt) V/µsec
VDC
L max
400
600
31.0
170
–
36.0
80
120
41.0
–
70
49.0
30
40
7.
DISSIPATION FACTOR:
1.0% max. at 1 KHz 25°C
VDC
Mfd
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
L
OD
400 VDC
T
H
dø
L
OD
600 VDC
T
H
dø
31.0
31.0
31.0
36.0
36.0
36.0
49.0
49.0
49.0
10.5
11.5
12.5
11.0
13.0
15.5
16.5
19.0
22.0
8.0
8.5
9.0
8.5
10.0
12.0
12.0
13.0
15.0
14.0
15.0
16.0
15.0
17.0
19.5
20.0
23.5
27.5
0.8
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.0
36.0
36.0
36.0
41.0
41.0
41.0
49.0
49.0
49.0
11.0
12.5
14.0
14.0
16.0
18.5
18.2
22.0
25.8
8.5
9.5
10.5
9.5
11.5
14.0
13.0
16.0
16.5
14.5
15.5
16.5
16.5
19.0
22.5
22.5
26.0
29.5
0.8
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.0
F.16
Tecate Industries 858.513.2300 Fax 858.513.2345 E-mail tiinfo@tecategroup.com
PART NUMBERING SYSTEM
More ex.
IF FORMED TO 5mm L/S .................................... 914-250/104K10B1/5
IF CUT & FORMED TO 5mm L/S ........................ 914-250/104K10B5/5
IF CUT & FORMED TO 5mm L/S & 3mm L/L .. 914-250/104K10B1/5#1
(#1=one deviation from std ex.: L/L)
snap-in
B8
F.2
