8LAM009S-334E datasheet, PDF - EEWORLD Datasheet

8LAM009S-334E: DescriptionD Type Connector, 9 Contact(s), Female, 0.108 inch Pitch, Solder Terminal, #4-40, Plug; CategoryThe connector The connector; File Size175KB，1 Pages; ManufacturerFreeport Resources Enterprises Corp

Download Datasheet Parametric View All

8LAM009S-334E Overview

D Type Connector, 9 Contact(s), Female, 0.108 inch Pitch, Solder Terminal, #4-40, Plug

Parameter Name	Attribute value
Objectid	1166332905
Reach Compliance Code	unknown
ECCN code	EAR99
body width	0.494 inch
subject depth	0.43 inch
body length	1.216 inch
Body/casing type	PLUG
Contact to complete cooperation	AU ON NI
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	STAGGERED
Contact resistance	15 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	1000VAC V
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Plug contact pitch	0.108 inch
Match contact row spacing	0.112 inch
Installation option 1	#4-40
Installation option 2	SCREWLOCKS
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	2.8448 mm
Plating thickness	30u inch
Rated current (signal)	2.5 A
Guideline	UL
reliability	COMMERCIAL
Shell surface	TIN
Terminal length	0.145 inch
Terminal pitch	2.7432 mm
Termination type	SOLDER
Total number of contacts	9
