Product catalogue | Terminals | Tension clamp technology | Modular feed-through terminals | Roof-Style | 6 mm²
General ordering data
Order No.
Part designation
Version
EAN
Qty.
Product notes
Note, ordering data
Product description
PT OKIECEx/ATEX rating data
EU-type examination certificate
Download, German
Download English
ATEX voltage
ATEX current
ATEX conductor cross-section
Voltage when using cross-connections
Operating temperature range
Marking EN 60079-7
Marking ATEX Directive 94/9/EC
Additional technical data
Colour of insulating material
Connection direction
End plate required
Explosion-tested version "Ex e"
Installation advice
Insulating material
1771390000
ZDU 6-2/2AN BL
Feed-through terminal, 6 mm², Tension clamp
connection, Wemid, blue, TS 35
4032248143122
50 pc(s).
The rated voltage is reduced to 400 V when using
the cross-connection.
The compact terminal range for conductor cross-
sections 0.13 to 16 mm²
KEMA97ATEX4677U
KEMA97ATEX4677U_d.pdf
KEMA97ATEX4677U_e.pdf
550 V
36 A
6 mm²
CrossConnectionGuide.pdf
Einsatztemperaturbereich siehe EG-
Baumusterprüfbescheinigung/IECEx-Certificate of
Conformity
Ex e II
Ex II 2 G D
blue
Inclined / angled
Yes
Yes
TS 35
Wemid
-1-
Product catalogue | Terminals | Tension clamp technology | Modular feed-through terminals | Roof-Style | 6 mm²
Additional technical data
Levels cross-connected internally
No. of identical terminals
No. of levels
No. of terminal strips per level
Open sides
Operating temperature range
Product family
Type of connection
Type of mounting
UL 94 flammability rating of insulation material
Version
CSA rating data
Voltage (CSA)
CSA current
Min. cross-section (CSA)
Max. cross-section (CSA)
Conductors for clamping (additional
connection)
Flexible with ferrule, min. (DIN 46228 pt 1)
Flexible with ferrule, max. (DIN 46228 pt 1)
Conductors for clamping (rated connection)
Clamping range, min.
Clamping range, max.
Type of connection
2nd type of connection
Connection direction
No. of connections
Stripping length
Blade size
Gauge to IEC 60947-1
Solid, min.
Solid, max.
Flexible, min.
Flexible, max.
Flexible with ferrule, min. (DIN 46228/1)
Flexible with ferrule, max. (DIN 46228/1)
Flexible, min., ferrule with plastic collar (DIN
46228 pt 4)
Flexible, max., ferrule with plastic collar (DIN
46228 pt 4)
Twin wire-end ferrule, min.
Twin wire end ferrule, max.
AWG conductor size, min.
AWG conductor size, max.
AWG conductor size, min.
AWG conductor size, max.
No
1
1
2
right
- 50 °C, + 120 °C
Z-series
Tension clamp connection
Snap-on
V-0
Feed-through terminal
600 V
50 A
AWG 20
AWG 8
0.5 mm²
6 mm²
0.22 mm²
10 mm²
Tension clamp connection
clamped
Inclined / angled
2
12 mm
0.6 x 3.5 mm
A5
0.5 mm²
10 mm²
0.5 mm²
10 mm²
0.5 mm²
6 mm²
0.5 mm²
6 mm²
0.5 mm²
2.5 mm²
AWG 22
AWG 8
0.33 mm²
8.37 mm²
-2-
Product catalogue | Terminals | Tension clamp technology | Modular feed-through terminals | Roof-Style | 6 mm²
Dimensions
Width
Height of lowest version
Length
TS 35 offset
Rating data
Rated cross-section
Rated voltage
Rated impulse voltage
Rated current
Standards
Current with max. conductor
Pollution severity
UL rating data
Voltage (UL)
Current (UL)
Min. cross-section (UL)
Max. cross-section (UL)
Approvals
Approvals institutes
8.1 mm
50 mm
68 mm
21.5 mm
6 mm²
800 V
8 kV
41 A
IEC 60947-7-1
41 A
3
600 V
45 A
AWG 22
AWG 8
Classifications
eClass 4.1
eClass 5.0
eClass 5.1
27-14-11-20
27-14-11-20
27-14-11-20
Similar products
Order No.
1771380000
1771410000
1771420000
1771430000
Part designation
ZDU 6-2/2AN
ZDU 6-2/3AN
ZDU 6-2/3AN BL
ZDU 6-2/3AN OR
Version
Feed-through terminal, 6 mm², Tension clamp connection, Wemid,
dark beige, TS 35
Feed-through terminal, 6 mm², Tension clamp connection, Wemid,
dark beige, TS 35
Feed-through terminal, 6 mm², Tension clamp connection, Wemid,
blue, TS 35
Feed-through terminal, 6 mm², Tension clamp connection, Wemid,
Orange, TS 35
-3-
