For resistors operated in ambient temperatures above 70°C , power rating shall be derated in accordance with figure below.
SERIES: RC
100
80
Rated Load(%)
60
40
20
0
20
40
60
80 100
120
Ambient Temperature (°C)
125
VOLTAGE RATING
Rated Voltage: The resistor shall have a DC continuous working voltage or a RMS AC continuous working voltage at commercial-line frequency and wave form
corresponding to the power rating, as determined from the following:
E = Rated voltage (v)
E =
√RxP
P = power rating (w)
R = Nominal resistance(Ω )
DIMENSIONS
Dimensions
Type
Size Code
RC110C
RC110T
RC115C
RC115T
RC210C
RC210T
RC315C
RC315T
RC350C
RC350T
RC500C
RC500T
RC1000C
RC1000T
2512
6.30±0.20
3.20±0.20
0.55±0.10
0.6±0.20
0.60±0.20
2010
5.00±0.20
2.60±0.20
0.55±0.10
0.60±0.20
0.60±0.20
1210
3.10±0.10
2.55±0.10
0.55±0.10
0.50±0.20
0.60±0.20
0402
1.0
L
+0.10
-0.05
W
0.5±0.05
+0.15
-0.05
+0.10
-0.05
H
0.30±0.05
L1
0.2±0.10
L2
0.25±0.10
0603
0805
1206
1.6±0.10
2.05±0.10
3.10±0.10
0.80
1.25
0.45±0.10
0.50±0.10
0.55
+0.10
-0.05
0.30±0.15
0.35±0.20
0.45±0.20
0.30±0.15
0.35±0.15
0.35±0.15
1.55±0.10
