2.5mm
XMA
CONNECTOR
pitch/Disconnectable Crimp style Wire-to-wire connectors
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG#22)
• Voltage rating: 250V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m
Ω
max.
After environmental testing/20m
Ω
max.
• Insulation resistance: 500M
Ω
min.
• Withstanding voltage: 1,500V AC/minute
• Applicable wire: AWG#26 to #22
0.13mm
2
to 0.33mm
2
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
This connector is a 2.5mm pitch wire-to-
wire connector, having incomplete mating
prevention mechanism. 2-circuit and 3-
circuit connectors have control key to
prevent connector from mating with
incorrect circuits, thus, several same
circuit connectors can be used.
• Inertial lock structure with side lock
mechanism
• 3 type combination of control key with one
kind of circuit
• Secure locking structure
• Finger-friendly design
Standards
––––––––––––––––––––––
1
Certified LR20812
0
Recognized E 60389
Assembly layout
〈2,
3 circuits〉
〈4,
5 circuits〉
9.85
9.15
(25.9)
(27.4)
(25.9)
(27.4)
〈6
circuits〉
9.15
(22.9)
(24.4)
Note: The dimensions above should serve as a guideline. Contact JST for details.
1
XMA CONNECTOR
Contact
●Pin
contact
12.5
Model No.
Pin contact
Socket contact
Applicable wire
mm
2
Q’ty / reel
Insulation O.D.
(mm)
AWG #
Pin contact Socket contact
1.3∼1.9
7,000
8,000
SXM-001T-P0.6 SXA-001T-P0.6L
0.13∼0.33 26∼22
Material and Finish
1.9
Copper alloy, tin-plated (reflow treatment)
6.3
2.5
2.9
1.3
RoHS compliance
Applicator
Dies
2.4
Contact
0.8
Crimping
machine Crimp applicator
MKS-L
AP-K2N
*MKS-SC
MKS-L
*MKS-SC
Crimp applicator with dies
SXM-001T-P0.6
MK/SXA/M-001-06 APLMK SXA/M001-06
SC/SXA/M-001-06 APLSC SXA/M001-06
MK/SXA-001-06L
SC/SXA-001-06L
APLMK SXA001-06L
APLSC SXA001-06L
●Socket
contact
6.5
SXA-001T-P0.6L
1.9
Note: *Strip-crimp applicator
2.9
3.1
1.3
2.3
0.8
Receptacle housing (for pin contact)
〈2,
3 circuits〉
Circuits
Model No.
XMAR-02VF-1-S
2
1
Color
Natural (white)
Red
Blue
Natural (white)
Red
Blue
Natural (white)
Natural (white)
Natural (white)
Dimensions (mm)
A
2.5
B
12.5
Q’ty / bag
XMAR-02VF-2-R
XMAR-02VF-3-E
XMAR-03VF-1-S
1,000
B
3
2.5
A
2
3
XMAR-03VF-2-R
XMAR-03VF-3-E
XMAR-04VF-S
XMAR-05VF-S
XMAR-06VF-S
5.0
14.0
1,000
23.2
9.85
4
5
6
7.5
10.0
12.5
16.5
19.0
21.5
500
500
500
〈4,
5 circuits〉
Material
Glass-filled PBT, UL94V-0
A
1
B
2
RoHS compliance
4
3
23.2
9.15
〈6
circuits〉
B
3
2
1
2.5
6
5
4
20.2
9.15
2.5
A
2
XMA CONNECTOR
Plug housing (for socket contact)
〈2,
3 circuits〉
Circuits
Model No.
XMAP-02V-1-S
3
Color
Natural (white)
Red
Blue
Natural (white)
Red
Blue
Natural (white)
Natural (white)
Natural (white)
Dimensions (mm)
A
2.5
B
9.4
Q’ty / bag
2
A
XMAP-02V-2-R
XMAP-02V-3-E
XMAP-03V-1-S
1,000
B
1
2
2.5
3
XMAP-03V-2-R
XMAP-03V-3-E
XMAP-04V-S
XMAP-05V-S
XMAP-06V-S
5.0
11.9
1,000
13
9.65
4
5
6
7.5
10.0
12.5
14.4
16.9
19.4
1,000
500
500
〈4,
5 circuits〉
Material
4
Glass-filled PBT, UL94V-0
A
B
3
RoHS compliance
2.5
13
8.95
〈6
circuits〉
B
4
5
6
1
2
1
2
3
13
8.95
Retainer
Circuits
Model No.
XMAS-02V-S
XMAS-03V-S
XMAS-04V-S
XMAS-05V-S
XMS-06V
Color
Natural (ivory)
Natural (ivory)
Natural (ivory)
Natural (ivory)
Natural (ivory)
2.5
A
Dimensions (mm)
A
2.5
5.0
7.5
10.0
12.5
Q’ty / bag
1,000
1,000
1,000
1,000
1,000
〈2
to 5 circuits〉
2
3
A
4
5
6
2.9
9.3
2.5
Material
Glass-filled PA 66, UL94V-0
〈6
circuits〉
2.5
A
RoHS compliance
Note: 6 circuits of retainer is interchangeable with those of the XM and
XA connectors.
2.5
7.8
3
