Product catalogue | Terminals | Tension clamp technology | Modular isolating terminals | Standard form
General ordering data
Order No.
Part designation
Version
EAN
Qty.
Product notes
Note, technical data
Product description
Note, accessories
Additional technical data
Colour of insulating material
Connection direction
End plate required
Explosion-tested version "Ex e"
Installation advice
Insulating material
Levels cross-connected internally
No. of levels
No. of terminal strips per level
Open sides
Operating temperature range
Product family
Type of connection
Type of mounting
UL 94 flammability rating of insulation material
Version
7920900000
ZTR 2.5/4AN
Disconnect and modular disconnect terminal, 2.5
mm², Tension clamp connection, Wemid, dark
beige, TS 35
4032248279005
100 pc(s).
2.5 mm² flexible conductors with wire end ferrules
are crimped with the Weidmüller PZ 6/5 crimping
tool.
Z-series standard ranges provide solutions for
conductor cross-sections from 0.05 to 35 mm².
If the disconnection lever is replaced by the SIHA
3, this creates a fuse terminal.
dark beige
top
Yes
No
TS 35
Wemid
No
1
4
right
- 50 °C, + 120 °C
Z-series
Tension clamp connection
Snap-on
V-0
Test-disconnect terminals
-1-
Product catalogue | Terminals | Tension clamp technology | Modular isolating terminals | Standard form
Additional technical data
CSA rating data
Voltage (CSA)
CSA current
Min. cross-section (CSA)
Max. cross-section (CSA)
Conductors for clamping (additional
connection)
Flexible with ferrule, min. (DIN 46228 pt 1)
Flexible with ferrule, max. (DIN 46228 pt 1)
Conductors for clamping (rated connection)
Clamping range, min.
Clamping range, max.
Type of connection
Connection direction
No. of connections
Stripping length
Blade size
Gauge to IEC 60947-1
Solid, min.
Solid, max.
Flexible, min.
Flexible, max.
Flexible with ferrule, min. (DIN 46228/1)
Flexible with ferrule, max. (DIN 46228/1)
Flexible, min., ferrule with plastic collar (DIN
46228 pt 4)
Flexible, max., ferrule with plastic collar (DIN
46228 pt 4)
AWG conductor size, min.
AWG conductor size, max.
AWG conductor size, min.
AWG conductor size, max.
Dimensions
Width
Height of lowest version
Length
TS 35 offset
Disconnect terminals
Cross-disconnect
Integral test socket
Slitting
Rating data
Rated cross-section
Rated voltage
Rated impulse voltage
300 V
10 A
AWG 26
AWG 12
0.5 mm²
1.5 mm²
0.05 mm²
2.5 mm²
Tension clamp connection
top
2
10 mm
0.6 x 3.5 mm
A2
0.5 mm²
2.5 mm²
0.5 mm²
2.5 mm²
0.5 mm²
1.5 mm²
0.5 mm²
1.5 mm²
AWG 30
AWG 12
0.05 mm²
3.31 mm²
5.1 mm
39.1 mm
82.5 mm
46 mm
without
No
Pivoting
2.5 mm²
400 V
6 kV
-2-
Product catalogue | Terminals | Tension clamp technology | Modular isolating terminals | Standard form
Rating data
Rated current
Standards
Current with max. conductor
Pollution severity
UL rating data
Voltage (UL)
Current (UL)
Min. cross-section (UL)
Max. cross-section (UL)
Approvals
Approvals institutes
16 A
IEC 60947-7-1
16 A
3
300 V
10 A
AWG 30
AWG 12
Classifications
eClass 4.1
eClass 5.0
eClass 5.1
27-14-11-17
27-14-11-26
27-14-11-26
Similar products
Order No.
1745400000
1798330000
1831280000
8731710000
8731680000
8731720000
8731730000
8731690000
8728450000
Part designation
ZDTR 2.5
ZDTR 2.5 BL
ZTR 2.5
ZTR 2.5 BL
ZTR 2.5 OR
ZTR 2.5/3AN
ZTR 2.5/3AN BL
ZTR 2.5/3AN OR
ZTR 2.5/3AN/O.TNHE
Version
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, dark beige, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, blue, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, beige, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, blue, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, Orange, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, beige, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, blue, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, Orange, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, beige, TS 35
-3-
Product catalogue | Terminals | Tension clamp technology | Modular isolating terminals | Standard form
7920930000
7920940000
7920950000
1831130000
ZTR 2.5/4AN BL
ZTR 2.5/4AN OR
ZTR 2.5/4AN/O.TNHE
ZTR 2.5/O.TNHE
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, blue, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, Orange, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, dark beige, TS 35
Disconnect and modular disconnect terminal, 2.5 mm², Tension
clamp connection, Wemid, beige, TS 35
-4-
