RoHS
Toroid Chokes
TC220
0.55
MAX
(13.97)
0.95
MAX
(24.13)
Dimensions:
Inches
(mm)
Tin lead to coil
0.50
(12.70)
C
A
B
Vertical Mount
Horizontal Mount
Allied
Part
Number
L(uH)
@15%
1 KHZ
Tolerance
(%)
L(µH)
±15%
@I rated
IDC
(A)
DCR
(Ω)
MAX
DIM
DIM
DIM
B
C
A
(Nom) (Nom) (Nom)
Features
•
•
•
•
Low Magnetic Radiation
Low Core Loss
High current capacity up to 12.5 Amps
Available in Horizontal or Vertical configuration
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
)TC220-100L-RC
)TC220-120L-RC
)TC220-150L-RC
)TC220-180L-RC
)TC220-220L-RC
)TC220-270L-RC
)TC220-330L-RC
)TC220-390L-RC
)TC220-470L-RC
)TC220-560L-RC
)TC220-680L-RC
)TC220-101L-RC
)TC220-121L-RC
)TC220-151L-RC
)TC220-181L-RC
)TC220-221L-RC
)TC220-271L-RC
)TC220-331L-RC
)TC220-391L-RC
)TC220-471L-RC
)TC220-561L-RC
)TC220-680L-RC
)TC220-821L-RC
)TC220-102L-RC
10
12
15
18
22
27
33
39
47
56
68
100
120
150
180
220
270
330
390
470
560
680
820
1000
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
6.7
7.9
9.6
11.3
13.4
16.0
21.6
25.0
29.3
34.1
45.7
64.0
84.4
102.7
105.9
125.6
149.4
176.8
235.3
275.9
320.1
377.2
441.5
521.3
12.5
12.0
11.3
10.8
10.3
9.8
7.4
7.1
6.7
6.4
4.9
4.4
3.3
3.1
3.8
3.6
3.4
3.3
2.5
2.3
2.2
2.1
2.0
1.9
.007
.008
.008
.009
.010
.011
.020
.022
.024
.026
.046
.056
.098
.110
.075
.083
.092
.100
.180
.190
.210
.230
.260
.280
.46
.46
.46
.46
.46
.46
.45
.45
.45
.45
.44
.44
.44
.44
.48
.48
.48
.48
.46
.46
.46
.49
.49
.49
.88
.88
.88
.88
.88
.88
.87
.87
.87
.87
.86
.86
.86
.86
.90
.90
.90
.90
.88
.88
.88
.91
.91
.91
.053
.053
.053
.053
.053
.053
.042
.042
.042
.042
.034
.034
.027
.027
.034
.034
.034
.034
.027
.027
.027
.027
.027
.027
Electrical
Inductance Range:
10µh to 1000µh
Additional values available
Tolerance:
15% over entire range
Test Frequency:
1KHz
Operating Temp:
-55ºC ~ +105ºC
Temp Rise:
∆
T=30ºC Typical at rated IDC
Test Equipment
(L):
100 LCR meter or equivalent
DCR:
Chen Hwa 502
Physical
Packaging:
Bulk
Marking:
None
Please specify Vertical or Horizontal Mount
by placing a V or H at the beginning of the part number,
i.e. VTC220-100L (Vertical Mount). All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 03/15/13
www.alliedcomponents.com
