H
IGH
C
APACITANCE
C
HIP
C
APACITORS
KEY FEATURES
• Rated Working Voltages from 50 to 250 VDC
• Low ESR Ceramic Out-performs Tantalums
• Compact MLC Designs Smaller Than Film or Disc
• MIL-PRF-55681 Screened Versions Available
• Custom Sizes, Voltages, and Values Available
APPLICATIONS
• Power Supplies
• Voltage Multipliers
• Data Isolation
• Surge Protection
• Industrial Control Circuits
• Custom Applications
C
APACITANCE
/ V
OLTAGE
S
ELECTION
NPO
X7R
CASE SIZE
(JDI/EIA)
Capacitance
Value Code
1000 pF
1500 pF
2200 pF
3300 pF
4700 pF
6800 pF
.010 µF
.015 µF
.022 µF
.033 µF
.047 µF
.068 µF
.100 µF
.150 µF
.220 µF
.330 µF
.470 µF
.680 µF
1.00 µF
1.20 µF
1.50 µF
2.20 µF
3.30 µF
4.70 µF
6.80 µF
10.0 µF
102
152
222
332
472
682
103
153
223
333
473
683
104
154
224
334
474
684
105
125
155
225
335
475
685
106
S49/1825
50 V
63 V
100 V
200 V
250 V
S47/2220
50 V
63 V
100 V
200 V
250 V
S48/2225
50 V
63 V
100 V
200 V
250 V
H47/2520
50 V
63 V
100 V
200 V
250 V
H51/3530
200 V
250 V
50 V
63 V
100 V
H54/3640
200 V
250 V
50 V
63 V
100 V
H62/4540
63 V
100 V
200 V
184
393 333 333
563 563
683 683
333 333
473
753 753
563
273 273
393 393 473 473 393
124 124 104
823 823
184 184
124 104 104
224 224
154 154
684 684
105
125
185 185
185 185
824 824
155
225 225
105 105
185 185
105 824 824
225 225
335
475 475
825 825
475
565 475
225 225
275
475 475
Consult factory for other tooled sizes such as 3327 & 4020
8
823 Gateway Center Way, San Diego, California 92102 • (619) 266-0762 • FAX (619) 266-0718
250 V
50 V
www.johanson-caps.com
D
IELECTRIC
C
HARACTERISTICS
TEMPERATURE COEFFICIENT:
TYPICAL CAPACITANCE
CHANGE VS TEMPERATURE:
NPO DIELECTRIC
0 ± 30 ppm / °C , -55 to 125°C
2.0%
1.5%
1.0%
0.5%
0.0%
-0.5%
-1.0%
-1.5%
-2.0%
-55°C
25%
20%
15%
10%
X7R DIELECTRIC
0 ± 15% ,-55 to 125°C
NPO
5%
0%
-5%
-10%
-15%
-20%
-25%
X7R
-25°C
0°C
25°C
50°C
75°C
100°C
125°C
-55°C
-25°C
0°C
25°C
50°C
75°C
100°C
125°C
DISSIPATION FACTOR:
AGEING:
INSULATION RESISTANCE:
DIELECTRIC STRENGTH:
TEST PARAMETERS:
.001 (0.1%) max, 1Khz, 25°C
None
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
(2.0 X WVDC for ratings
≥
200V)
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
.025 (2.5%) max, 1KHz, 25°C
4.0% / decade hour
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
(2.0 X WVDC for ratings
≥
200V)
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
M
ECHANICAL
C
HARACTERISTICS
H42
W
S49
0.180
4.57
S47
0.225
5.72
S48
0.225
5.72
H47
0.250
6.35
H51
0.350
8.89
H54
0.360
9.14
H62
0.450
11.4
LENGTH
(± 10%)
In.
mm
0.150
3.81
WIDTH
L
E/B
T
In.
mm
mm
mm
0.150
3.81
0.250
6.35
0.200
5.08
0.250
6.35
0.200
5.08
0.300
7.62
0.400
10.2
0.400
10.2
(± 10%)
(Max)
(± 0.015”)
THICKNESS In.
END BAND In.
0.150
3.81
0.110
2.79
0.110
2.79
0.110
2.79
0.150
3.81
0.200
5.08
0.150
3.81
0.200
5.08
0.025
0.64
0.025
0.64
0.025
0.64
0.025
0.64
0.025
0.64
0.025
0.64
0.025
0.64
0.025
0.64
H
OW TO
O
RDER
630
VOLTAGE
Standard Voltages:
500 = 50 V
630 = 63 V
101 = 100 V
201 = 200 V
251 = 250 V
H51
CASE SIZE
See Chart
W
DIELECTRIC
N = NPO
W = X7R
475
CAPACITANCE
EIA: 1st two digits are
significant; third digit
denotes number of
zeros.
102 = 1000 pF
103 = 0.01 µF
825 = 8.2 µF
K
TOLERANCE
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80% -20%
Y
TERMINATION
Y = Palladium-Silver
V = Nickel-Tin
4
MARKING
4 = Unmarked
6 = EIA "J" Code*
3 = Specified
SPECIAL MODIFIER
E = 7” Reel Taped
H = High Rel Testing
(Customer Specified)
S = Special Part
Part number written: 630H51W475KY4
9
823 Gateway Center Way, San Diego, California 92102 • (619) 266-0762 • FAX (619) 266-0718
