RMGW20-565FB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> RMGW20-565FB

RMGW20-565FB: DescriptionFixed Resistor, Metal Glaze/thick Film, 0.125W, 5600000ohm, 150V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0805, CHIP; CategoryPassive components The resistor; File Size173KB，15 Pages; ManufacturerKamaya; Environmental Compliance

Download Datasheet Parametric View All

RMGW20-565FB Overview

Fixed Resistor, Metal Glaze/thick Film, 0.125W, 5600000ohm, 150V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0805, CHIP

RMGW20-565FB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	145013298456
package instruction	CHIP
Reach Compliance Code	compliant
Country Of Origin	Malaysia
ECCN code	EAR99
YTEOL	7.6
Other features	ANTI-SULFUR
structure	RECTANGULAR PACKAGE
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	0.55 mm
Package length	2 mm
Package form	SMT
Package width	1.25 mm
method of packing	BULK
Rated power dissipation(P)	0.125 W
Rated temperature	70 °C
Guideline	AEC-Q200
resistance	5600000 Ω
Resistor type	FIXED RESISTOR
size code	0805
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	200 ppm/°C
Terminal shape	WRAPAROUND
Tolerance	1%
Operating Voltage	150 V

RMGW20-565FB Preview

No.:

Date:

RMGW-K-HTS-0001

2018. 6. 29

Data sheet

Title:

FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE

ANTI-SULFURATION

Style:

RMGW06,10,16,20,32,35,50,63

AEC-Q200 qualified

RoHS COMPLIANCE ITEM

Halogen and Antimony Free

Note:

・Stock

conditions

Temperature:

+5°C ∼ +35°C

Relative humidity: 25%

∼

75%

The period of guarantee: Within 2 year from shipmen t by the company.

Solderability shall be satisfied.

・Product

specification contained in this data sheet

are subject to change at any time without notice

・If

you have any questions or a Purchasing Specification for any quality

Agreement is necessary, please contact our sales staff.

Hokkaido Research Center

Approval by: T. Sannomiya

Drawing by: M. Shibuya

No: RMGW−K−HTS−0001

Title:

FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE

ANTI-SULFURATION

RMGW06,10,16,20,32,35,50,63

Page:

1/14

1. Scope

1.1 This data sheet covers the detail requirements for fixed thick film chip resistors; rectangular type & anti-sulfuration,, style of

RMGW06,10,16,20,32,35,50,63.

1.2 Applicable documents

JIS C 5201−1: 2011, JIS C 5201−8: 2014, JIS C 5201−8−1: 2014

IEC60115−1: 2008, IEC60115−8: 2009, IEC60115−8−1: 2014

EIAJ RC−2134C−2010

2. Classification

Type designation shall be the following form.

(Example)

RMGW

Style

RMGW

Style

123

1 Fixed thick film chip resistors; rectangular type & anti-sulfuration

2 Rated dissipation and / or dimension

3 Temperature coefficient of resistance

±100×10

−6

/ °C

Standard

−(Dash)

4 Rated resistance

123

E24 Series, 3 digit, Ex. 123--> 12kΩ,

1000

E96 Series, 4 digit, Ex. 1000-->100Ω

1022--> 10.2kΩ

Chip jumper

5 Tolerance on rated resistance

±0.5%

±1%

±5%

6 Packaging form

Bulk (loose package)

Press pocket taping

Paper taping

Embossed taping

Style

Product specification contained in this data sheet are subject to change at any time without notice.

If you have any questions or a Purchasing Specification for any quality agreement is necessary, please contact our sales staff.

Issue: KAMAYA ELECTRIC CO., LTD. Research & Development Department HOKKAIDO Research center Last update: 2018.6.29

No: RMGW−K−HTS−0001

Title:

FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE

ANTI-SULFURATION

RMGW06,10,16,20,32,35,50,63

Page:

2/14

3. Rating

The ratings shall be in accordance with Table−1.

3.1 Resistor

Table−1(1)

Style

Rated

dissipation

(W)

Temperature coefficient of

resistance (10

-6

/ °C)

+600∼−200

Standard

RMGW06

0.05

Standard

RMGW10

0.1

Standard

RMGW16

0.1

Standard

RMGW20

0.125

Standard

RMGW32

0.25

Standard

RMGW35

0.33

Standard

+350∼−100

±200

+600∼−200

+350∼−100

±200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

Rated resistance

range (Ω)

1∼3.92

4.02∼9.76

10∼1M

1∼3.92

4.02∼9.76

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

E24

F(±1%), J(±5%)

E24, 96

F(±1%), J(±5%)

Preferred

number series

for resistors

Tolerance on

rated resistance

E24, 96

D(±1%), F(±1%)

F(±1%)

E24

J(±5%)

D(±1%), F(±1%)

F(±1%)

E24, 96

E24

J(±5%)

D(±1%), F(±1%)

F(±1%)

E24, 96

E24

J(±5%)

D(±1%), F(±1%)

F(±1%)

E24, 96

E24

J(±5%)

D(±1%), F(±1%)

F(±1%)

E24, 96

E24

J(±5%)

Product specification contained in this data sheet are subject to change at any time without notice.

If you have any questions or a Purchasing Specification for any quality agreement is necessary, please contact our sales staff.

Issue: KAMAYA ELECTRIC CO., LTD. Research & Development Department HOKKAIDO Research center Last update: 2018.6.29

No: RMGW−K−HTS−0001

Title:

FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE

ANTI-SULFURATION

RMGW06,10,16,20,32,35,50,63

Table−1(2)

Style

Rated

dissipation

(W)

Temperature coefficient of

resistance (10

-6

/ °C)

Standard

RMGW50

0.75

Standard

RMGW63

Standard

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

±100

±200

+500∼−200

Rated resistance

range (Ω)

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

10∼1M

1.02M∼10M

1∼9.76

10∼1M

1.1M∼10M

1.0∼9.1

Preferred

number series

for resistors

E24, 96

Page:

3/14

Tolerance on

rated resistance

D(±1%), F(±1%)

F(±1%)

E24

J(±5%)

D(±1%), F(±1%)

F(±1%)

E24, 96

E24

J(±5%)

Style

RMGW06

RMGW10

RMGW16

RMGW20

RMGW32

RMGW35

RMGW50

RMGW63

3.2 Chip Jumper

Style

RMGW06

RMGW10

RMGW16

RMGW20

RMGW32

RMGW35

RMGW50

RMGW63

Limiting element voltage

(V)

150

200

Table−1(3)

Isolation voltage

Category temperature

(V)

range(°C)

100

−55~+155

500

Chip jumper

symbol

Table−1(4)

Resistance value of

chip jumper

50mΩmax.

Rated current of chip jumper

(A)

3.3 Climatic category

55/155/56

Lower category temperature

Upper category temperature

Duration of the damp heat, steady state test

−

55 °C

+155 °C

56days

3.4 Stability class

Limits for change of resistance:

−for

long−term tests

±(2%+0.1Ω) Chip jumper: 50 mΩ max.

−for

short−term tests

±(0.5%+0.05Ω) Chip jumper: 50 mΩ max.

Product specification contained in this data sheet are subject to change at any time without notice.

If you have any questions or a Purchasing Specification for any quality agreement is necessary, please contact our sales staff.

Issue: KAMAYA ELECTRIC CO., LTD. Research & Development Department HOKKAIDO Research center Last update: 2018.6.29

No: RMGW−K−HTS−0001

Title:

FIXED THICK FILM CHIP RESISTORS; RECTANGULAR TYPE

ANTI-SULFURATION

RMGW06,10,16,20,32,35,50,63

Page:

4/14

3.5 Derating

The derated values of dissipation (or current rating in case of chip jumper) at temperature in excess of 70 °C shall be as

indicated by the following curve.

100

Percentage of the

rated dissipation

(Current)

(%)

−55

Area of recommended

operation

155

Ambient temperature (°C)

Figure−1 Derating curve

3.6 Rated voltage

d. c. or a. c. r. m. s. voltage calculated from the square root of the product of the rated resistance and the rated dissipation.

E : Rated voltage (V)

E =

P · R

P : Rated dissipation (W)

R : Rated resistance (Ω)

Limiting element voltage can only be applied to resistors when the resistance value is equal to or higher than the critical

resistance value.

At high value of resistance, the rated voltage may not be applicable.

4. Packaging form

The standard packaging form shall be in accordance with Table−2.

Table−2

Symbol

Bulk (loose package)

Press pocket taping

(paper taping)

Paper taping

Embossed taping

Packaging form

Standard packaging

quantity / units

1,000 pcs.

15,000 pcs.

10,000 pcs.

5,000 pcs.

4,000 pcs.

Application

RMGW16,20,32,35,50,63

RMGW06

RMGW10

RMGW16,20,32

RMGW35

RMGW50,63

8mm width, 2mm pitches

8mm width, 4mm pitches

12mm width, 4mm pitches

Product specification contained in this data sheet are subject to change at any time without notice.

If you have any questions or a Purchasing Specification for any quality agreement is necessary, please contact our sales staff.

Issue: KAMAYA ELECTRIC CO., LTD. Research & Development Department HOKKAIDO Research center Last update: 2018.6.29
