PIN
RECEPTACLES
FOR 0,56 - 0,86 DIAMETER PINS AND 0,64 SQUARE PINS
0291
2,01 DIA.
0291-0-15-XX-16-XX-10-0
Hex press-fit in 1,7 plated through-hole
0,46
0,38
2,11
3,05
3,68
0293
0293-0-15-XX-16-XX-10-0
Press-fit in 1,7 mounting hole
0287
0287-0-15-XX-16-XX-10-0
0285
Solder mount in 1,65 min. mounting hole
Also available on 8mm wide carrier tape:
3,250 parts per 330mm reel
Order as: 0287-0-57-XX-16-XX-10-0
0285-0-15-XX-16-XX-10-0
Solder mount in 1,65 min. mounting hole
0,38
0,71
2,18 DIA.
1,78 DIA.
KNURL
1,55 DIA.
1,52 2,31
4,32
5,08
2,03 DIA.
1,57 DIA.
1,14
2,03 DIA.
1,27
1,55 DIA.
2,18
2,29
2,11 2,29
1,57 DIA.
1,8 DIA.
2,29
1,3 DIA.
HOLE
1,3 DIA.
HOLE
0284
0284-0-15-XX-16-XX-10-0
Solder mount in 1,78 min. mounting hole
8114
1,63 DIA.
1,73 DIA.
8114-0-15-XX-16-XX-04-0
0407
2,18 DIA.
1,75 DIA.
Press-fit from underside of pc board
into 1,65 mounting hole
1,65
0407-0-15-XX-16-XX-04-0
Press-fit in 1,68 mounting hole
0,79
0,71 2,49
5,59
1,52 DIA.
13,72
0415
0415-0-15-XX-16-XX-10-0
Solder mount in 1,6 min. mounting hole
Also available on 24mm wide carrier tape:
1,500 parts per 330mm reel
Order as: 0415-0-57-XX-16-XX-10-0
0,46
1,98 DIA.
2,11
2,11
3,81
4,32
3,18 DIA.
2,62
5,33
2,67
1,6 DIA.
1,73 DIA.
3,68
1,52 DIA.
0,51 DIA.
5,08
0,51 DIA.
4,06
4,19
4,83
0303
2,16 DIA.
1,75 DIA.
0303-0-19-XX-16-XX-10-0
0306
1,91 DIA.
MAX.
Press-fit in 1,7 mounting hole
Wire Crimp Termination. Accepts wire
sizes 26 AWG Max. / 30 AWG Min.
0,79
0,71 2,11
3,56
0306-0-19-XX-16-XX-10-0
0273
Wire Crimp Termination. Accepts wire
sizes 20 AWG Max. / 24 AWG Min.
2,11
7,11
9,96
1,83 DIA.
0273-0-15-XX-16-XX-10-0
Press-fit in 1,98 mounting hole
0,38
2,49 DIA.
2,06 DIA.
0,71
2,11
5,33
7520
2,18 DIA.
1,75 DIA.
1,57 DIA.
0,76 DIA.
1,57 DIA.
7520-0-15-XX-16-XX-10-0
Press-fit in 1,68 mounting hole
0,79
1,52
2,62
3,73
4,47
1,57 DIA.
8,94
1,85 DIA.
1,4 DIA.
1,7 DIA.
0,64
1,52
0,74 DIA.
HOLE
3,81
1,3 DIA.
HOLE
5,59
6,3
1,3 DIA.
HOLE
0,51
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Millimeters
Tolerances On:
Lengths: ± 0,13
Diameters: ± 0,05
Angles:
±2°
ORDER CODE: XXXX - X - 1X - XX -
16
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
5,04μm TIN/LEAD OVER NICKEL
80
5,04μm TIN OVER NICKEL (RoHS)
15
0,25μm GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
01
5,04μm TIN/LEAD OVER NICKEL
80
5,04μm TIN OVER NICKEL (RoHS)
27
0,76μm GOLD OVER NICKEL (RoHS)
2011/65/EU
RoHS - 2
SELECT CONTACT:
#16
CONTACT (DATA ON PAGE 256)
(For alternate contact choices, see group D on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 175 | PIN RECEPTACLES
