Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
solder connection, pitch 3.5 | SL 3.5/180 | SL 3.5/180
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Fitted to PCB
Outgoing elbow
Pitch
Pitch in inch
No. of poles
Solder pin length
Can be coded
No. of rows
No. of solder pins per pole
Dia. of fitting hole
Fitting hole tolerance
L1 in mm
L1 in inch
Insulation resistance
1621460000
SL 3.5/23/180 3.2SN OR
PCB plug-in connector, Male connectors, Soldered
connection, Pitch: 3.50 mm, No. of poles: 23,
180°, Box
4008190173494
20 pc(s).
Soldered connection
180°
3.5 mm
0.138 inch
23
3.2 mm
Yes
1
1
1.3 mm
+ 0.1 mm
77 mm
3.031 inch
1 MΩ
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
solder connection, pitch 3.5 | SL 3.5/180 | SL 3.5/180
System parameters
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
IP 10
Safe from back-of-hand touch
PBT
orange
Similar to RAL 2000
IIIa
V-0
>= 200
CuSn
tinned
-25 °C
100
-25 °C
55 °C
80 %
17 A
12 A
14.5 A
10 A
160 V
2.5 kV
160 V
2.5 kV
320 V
2.5 kV
3 x 1s with 100 A
300 V
10 A
300 V
10 A
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
solder connection, pitch 3.5 | SL 3.5/180 | SL 3.5/180
Approvals
Approvals institutes
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
SL.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-04
Similar products
Order No.
1604770000
1604780000
1604790000
1604800000
1604810000
1604820000
1604830000
1604840000
1604850000
1604860000
Part designation
SL 3.5/2/180 3.2SN OR
SL 3.5/3/180 3.2SN OR
SL 3.5/4/180 3.2SN OR
SL 3.5/5/180 3.2SN OR
SL 3.5/6/180 3.2SN OR
SL 3.5/7/180 3.2SN OR
SL 3.5/8/180 3.2SN OR
SL 3.5/9/180 3.2SN OR
SL 3.5/10/180 3.2SN OR
SL 3.5/11/180 3.2SN OR
Version
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 2, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 3, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 4, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 5, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 6, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 7, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 8, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 9, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 10, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 11, 180°, Box
-3-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) | Plug connectors,
solder connection, pitch 3.5 | SL 3.5/180 | SL 3.5/180
1604870000
1604880000
1604890000
1604900000
1604910000
1621400000
1621410000
1621420000
1621430000
1621440000
1621450000
1621470000
SL 3.5/12/180 3.2SN OR
SL 3.5/13/180 3.2SN OR
SL 3.5/14/180 3.2SN OR
SL 3.5/15/180 3.2SN OR
SL 3.5/16/180 3.2SN OR
SL 3.5/17/180 3.2SN OR
SL 3.5/18/180 3.2SN OR
SL 3.5/19/180 3.2SN OR
SL 3.5/20/180 3.2SN OR
SL 3.5/21/180 3.2SN OR
SL 3.5/22/180 3.2SN OR
SL 3.5/24/180 3.2SN OR
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 12, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 13, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 14, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 15, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 16, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 17, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 18, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 19, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 20, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 21, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 22, 180°, Box
PCB plug-in connector, Male connectors, Soldered connection,
Pitch: 3.50 mm, No. of poles: 24, 180°, Box
-4-
