2404KL-04W-B39-B50: Descriptionfan DC axial 12v 60x10.3mm tac; CategoryThermal management products; File Size291KB，1 Pages; ManufacturerNMB ( Minebea ); Websitehttp://www.nmbtc.com; Environmental Compliance

Download Datasheet Parametric Compare View All

2404KL-04W-B39-B50 Overview

fan DC axial 12v 60x10.3mm tac

2404KL-04W-B39-B50 Parametric

Parameter Name	Attribute value
Datasheets
2404KL
DC Axial Fan Part Numbering Guide
Fans & Blowers Catalog
Other Related Documents
Fan Agency Approvals
RoHS Informati
2404KL-04W-B39-B50 Material
Standard Package	360
Category	Fans, Thermal Manageme
Family	DC Fans
Voltage - Rated	12VDC
Size / Dimensi	Square - 60mm L x 60mm H x 10.3mm W
Air Flow	13.7 CFM (0.388m³/min)
Static Pressure	0.067 in H2O (16.7 Pa)
Bearing Type	Ball
Fan Type	Tubeaxial
Features	Speed Sensor (Tach)
Noise	29 dB
Power (Watts)	1.20W
RPM	3600 RPM
Terminati	3 Wire Leads
Ingress Protecti	-
Weigh	0.055 lb (24.95g)
Operating Temperature	14 ~ 158°F (-10 ~ 70°C)
Current Rating	0.100A
Voltage Range	10.2 ~ 13.8VDC
Life Expectancy	-
Material - Frame	Plastic
Material - Blade	Plastic
Associated Produc	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN
Other Names	2404KL04WB39B502404KL04WB39B50-ND

Preview

Download Datasheet

View All

2404KL (60

X

10

L

)

EMINEBEA.COM

Auto Restart/Polarity Protection

10M Ω or over with a DC500V Megger

AC 700V 1s

B50 Class:

-10°C ~ +60°C (Operating)

B30, B40 Class: -10°C ~ +70°C (Operating)

All Class:

-40°C ~ +70°C (Storage)

(non-condensing environment)

inch

Units: (mm)

In H

2

O

(Pa)

7.87

(200) min

ROTATION

.137

(3.5

0.3)

.251

4 – (½6.4

0.3)

Static Pressure

.169

4 – (½4.3

0.3)

.16

.128

.09

40

32

24

16

8

0

(m

3

/min)

CFM

B50

B40

B30

AIR

1.97

(50.0

0.3

)

2.36

(60.0

0.3

)

NAME

PLATE

Ps

.06

.03

.40

(10.3

0.5

)

1.97

(50.0

0.3

)

2.36

(60.0

0.3

)

0

0.1

0.2

0.3

0.4

0.5

Rib Type Only

3.5

7.0

10.6

Air Flow

14.1

17.6

1.69

4 – (φ4.3)

2.28

(58.0)

1.97

(50.0)

8

2.4 3.0)

6

(

φ

Casing : Plastic (Black) 94V-0

Impeller : Plastic (Black) 94V-0

Bearing : Ball Bearing

Lead Wire : UL1061, AWG26, +Red, -Black

1.97

(50.0)

2.28

(58.0)

INLET SIDE / OUTLET SIDE

Rated

Operating

Voltage

Current

Input

Power

Speed

Max.

Air Flow

Max. Static

Pressure

Noise

Mass

MODEL

Product

No.

2404KL-04W-B30-

-

2404KL-04W-B40-

-

2404KL-04W-B50-

-

Rotation: Clockwise

Voltage

(V)

12

(V)

10.2 ~ 13.8

(A)

*1

0.10

0.20

0.27

(W)

*1

1.20

2.40

3.24

(min

-1

)

*1

3600

4200

4800

CFM

*1

(m

3

/min)

*1

in H

2

O

13.7

16.2

19.0

0.39

0.46

0.54

.07

.09

.12

(Pa)

*1

16.7

23.0

30.1

(dB)

*1

29.0

33.0

36.0

(g)

25

X00

Airﬂow Outlet: Air Out Over Struts

*1: Average Values in Free Air

2404KL-04W-B39-B50 Related Products

	2404KL-04W-B39-B50	2404KL-04W-B39-B00	2404KL-04W-B59-B50	2404KL-04W-B40-B00	2404KL-04W-B30-B00	2404KL-04W-B49-B50
Description	fan DC axial 12v 60x10.3mm tac	fan DC axial 12v 60x10.3mm lrtr	fan DC axial 12v 60x10.3mm tac	fan DC axial 12v 60x10.3mm	fan DC axial 12v 60x10.3mm	fan DC axial 12v 60x10.3mm tac
Standard Package	360	210	210	210	360	360
Category	Fans, Thermal Manageme	Fans, Thermal Manageme	Fans, Thermal Manageme	Fans, Thermal Manageme	Fans, Thermal Manageme	Fans, Thermal Manageme
Family	DC Fans	DC Fans	DC Fans	DC Fans	DC Fans	DC Fans
Voltage - Rated	12VDC	12VDC	12VDC	12VDC	12VDC	12VDC
Size / Dimensi	Square - 60mm L x 60mm H x 10.3mm W	Square - 60mm L x 60mm H x 10.3mm W	Square - 60mm L x 60mm H x 10.3mm W	Square - 60mm L x 60mm H x 10.3mm W	Square - 60mm L x 60mm H x 10.3mm W	Square - 60mm L x 60mm H x 10.3mm W
Air Flow	13.7 CFM (0.388m³/min)	13.7 CFM (0.388m³/min)	19.0 CFM (0.538m³/min)	16.2 CFM (0.459m³/min)	13.7 CFM (0.388m³/min)	16.2 CFM (0.459m³/min)
Static Pressure	0.067 in H2O (16.7 Pa)	0.067 in H2O (16.7 Pa)	0.121 in H2O (30.1 Pa)	0.092 in H2O (23.0 Pa)	0.067 in H2O (16.7 Pa)	0.092 in H2O (23.0 Pa)
Bearing Type	Ball	Ball	Ball	Ball	Ball	Ball
Fan Type	Tubeaxial	Tubeaxial	Tubeaxial	Tubeaxial	Tubeaxial	Tubeaxial
Features	Speed Sensor (Tach)	Locked Rotor Sens	Speed Sensor (Tach)	-	-	Speed Sensor (Tach)
Noise	29 dB	29 dB	36 dB	33 dB	29 dB	33 dB
Power (Watts)	1.20W	1.20W	3.24W	2.40W	1.20W	2.40W
RPM	3600 RPM	3600 RPM	4800 RPM	4200 RPM	3600 RPM	4200 RPM
Terminati	3 Wire Leads	3 Wire Leads	3 Wire Leads	2 Wire Leads	2 Wire Leads	3 Wire Leads
Weigh	0.055 lb (24.95g)	0.055 lb (24.95g)	0.055 lb (24.95g)	0.055 lb (24.95g)	0.055 lb (24.95g)	0.055 lb (24.95g)
Operating Temperature	14 ~ 158°F (-10 ~ 70°C)	14 ~ 158°F (-10 ~ 70°C)	14 ~ 140°F (-10 ~ 60°C)	14 ~ 158°F (-10 ~ 70°C)	14 ~ 158°F (-10 ~ 70°C)	14 ~ 158°F (-10 ~ 70°C)
Current Rating	0.100A	0.100A	0.270A	0.200A	0.100A	0.200A
Voltage Range	10.2 ~ 13.8VDC	10.2 ~ 13.8VDC	10.2 ~ 13.8VDC	10.2 ~ 13.8VDC	10.2 ~ 13.8VDC	10.2 ~ 13.8VDC
Material - Frame	Plastic	Plastic	Plastic	Plastic	Plastic	Plastic
Material - Blade	Plastic	Plastic	Plastic	Plastic	Plastic	Plastic
Associated Produc	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN	8467K-ND - GUARD FAN FOR 2 1/2" FAN PLASTIC8465K-ND - GUARD ASSY 2.36"SQ FOR 2 1/2"FAN
Other Names	2404KL04WB39B502404KL04WB39B50-ND	2404KL04WB39B002404KL04WB39B00-ND	2404KL04WB59B502404KL04WB59B50-ND	2404KL04WB40B002404KL04WB40B00-ND	2404KL04WB30B002404KL04WB30B00-ND	2404KL04WB49B502404KL04WB49B50-ND
