AP2205
WIDE INPUT VOLTAGE RANGE, 200mA ULDO REGULATOR
Description
The AP2205 series is a positive voltage regulator IC fabricated by
high voltage EPNP process.
The AP2205 has features of wide input voltage range, high accuracy,
high ripple rejection, low dropout voltage, low noise, current limit and
ultra-low quiescent current which make it ideal for use in various USB
and portable devices.
Pin Assignments
(Top View)
3
VOUT
(Top View)
3
GND
2
1
SOT89R (Note 1)
VIN
GND
VOUT
GND
2
GND
NEW PRODUCT
The IC consists of a voltage reference, an error amplifier, a resistor
network for setting output voltage, a current limit circuit for current
protection, and a chip enable circuit, a low power shutdown mode for
extended battery life, over current protection, over temperature
protection, as well as reversed-battery protection.
The AP2205 has 1.5V, 1.8V, 2.5V, 2.8V, 3.0V, 3.3V, 5.0V fixed
voltage versions and adjustable voltage version.
1
VIN
SOT89 (Note 1)
Note 1: The substrate/exposed pad should be connected to GND or open.
(Top View)
VIN
1
2
3
5
VOUT
The AP2205 is available in space-saving SOT25 and SOT89
packages.
GND
EN
Features
Wide Input Voltage Range: 2.3V to 24V
Wide Output Voltage Range: 1.24V to 22V
Excellent Ripple Rejection: 60dB@ f = 1kHz
Low Dropout Voltage: V
DROP
= 100mV@ I
OUT
= 100µA
Low Ground Current
High Output Voltage Accuracy
Compatible with Low ESR Ceramic Capacitor
Excellent Line/Load Regulation
Thermal Shutdown Function
Totally Lead-Free & Fully RoHS Compliant (Notes 2 & 3)
Halogen and Antimony Free. “Green” Device (Note 4)
4
ADJ/NC
SOT25
Applications
Battery-powered Equipment
Laptop, Palmtops, Notebook Computers
Portable Information Appliances
Industrial/Automotive Applications
Notes:
2. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
3. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
4. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
Typical Applications Circuit
AP2205
Document number: DS41592 Rev. 1 - 2
1 of 18
www.diodes.com
January 2019
© Diodes Incorporated
AP2205
Absolute Maximum Ratings
(Note 5)
Symbol
V
IN
V
CE
I
OUT
T
LEAD
Parameter
Supply Input Voltage
Enable Input Voltage
Output Current
Lead Temperature (Soldering, 10sec)
Operating Junction Temperature
SOT25
Thermal Resistance (Note 6)
SOT89/SOT89R
JC
SOT25
Thermal Resistance
SOT89/SOT89R
T
STG
—
—
Notes:
Rating
36
36
250
+260
+150
160
Unit
V
V
mA
°
C
°
C
NEW PRODUCT
T
J
JA
°
C/W
129
29
°
C/W
26
°
C
V
V
Storage Temperature Range
ESD (Charge Device Model)
ESD (Human Body Model)
-65 to +150
1000
2000
5. Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
6.
JA
is measured with the component mounted on a 2-Layer FR-4 PCB board with 1.5cm*1.5cm thermal sink pad in free air.
Recommended Operating Conditions
Symbol
V
IN
T
J
Parameter
Supply Input Voltage
Operating Junction Temperature
Min
2.3
-40
Max
24
+125
Unit
V
°
C
AP2205
Document number: DS41592 Rev. 1 - 2
4 of 18
www.diodes.com
January 2019
© Diodes Incorporated
AP2205
Electrical Characteristics
(@V
IN
= V
OUT
+1V, T
J
= +25° I
OUT
= 100µA, C
IN
= 1.0µF, C
OUT
= 2.2µF,
Bold
typeface applies over -
C,
40° ≤T
J
≤ +125° unless otherwise specified.)
C
C,
Symbol
V
OUT
V
REF
V
IN
Parameter
Output Voltage
Reference Voltage
Input Voltage
Maximum Output Current
Line Regulation
Load Regulation
Conditions
Variation from Specified V
OUT
—
—
V
IN
-V
OUT
= 1V, V
OUT
= 98%V
OUT
V
OUT
+1V ≤V
IN
≤24V
1mA ≤I
OUT
≤200mA
I
OUT
= 100µA
I
OUT
= 50mA
Min
V
OUT
98%
1.215
2.3
200
—
—
—
—
—
—
—
—
—
—
—
Typ
—
1.24
—
250
0.05
0.5
100
270
320
360
36
0.5
1.3
2.5
0.01
60
60
100
30
0.5
3
—
—
Max
V
OUT
102%
1.265
24
—
—
—
150
350
Unit
V
V
V
mA
%
%
NEW PRODUCT
I
OUT(Max)
V
OUT
/V
IN
V
OUT
/V
OUT
V
DROP
Dropout Voltage (Note 7)
I
OUT
= 100mA
I
OUT
= 150mA
I
OUT
= 100µA
I
OUT
= 50mA
460
500
—
—
—
—
1.0
—
mV
µA
I
GND
Ground Current
I
OUT
= 100mA
I
OUT
= 150mA
mA
I
STD
Standby Current
V
IN
= V
OUT
+1V
V
EN
in OFF Mode
Ripple 0.5V
P-P
V
IN
= V
OUT
+1V
f = 100Hz
f = 1kHz
µA
—
—
—
—
—
—
2.0
—
PSRR
Power Supply Rejection Ration
Output Voltage Temperature
Coefficient
RMS Output Noise
ADJ Pin Current
EN Pin Current
EN “High” Voltage
EN “Low” Voltage
dB
—
—
—
—
—
—
0.4
ppm/°
C
µV
rms
µA
µA
V
V
∆V
OUT
/(V
OUT
∆T)
V
NOI
I
ADJ
I
EN
—
—
Note 7:
I
OUT
= 100µA,
-40°
≤T
J
≤+125°
C
C
T
J
= +25° 10Hz ≤ f ≤ 100kHz
C,
I
OUT
= 100µA
V
EN
= V
OUT
+1V
EN Input Voltage “High”
EN Input Voltage “Low”
Dropout voltage is only valid when V
OUT
≥ 2.3V because of the minimum input voltage limits.
AP2205
Document number: DS41592 Rev. 1 - 2
5 of 18
www.diodes.com
January 2019
© Diodes Incorporated
