AFB
25 x 25 x 10 MM SERIES
DRAWING
25.0±0.5
(0.984±0.020)
20.0±0.3
(0.787±0.012)
10.0±0.5
(0.394±0.020)
■
DIMENSIONS
25.0±0.5
(0.984±0.020)
20.0±0.3
(0.787±0.012)
LABEL
4-Ø2.8±0.3
(4-Ø0.110±0.012)
10.0
(0.394)
150.0±10.0
(5.906±0.394)
UNIT :
mm
(INCH)
Air Pressure
20.0
(0.787)
(Ø Ø24
0. .0
94
5)
20.0
(0.787)
0.12
0.06
0
(IN H
2
O)
3.0
1.5
0
(mm H
2
O)
0
0
.015
0.6
.030
1.2
.045
1.8
L
.060
.075
(M
3
/MIN)
2.4
(CFM)
4-Ø2.8
(4-Ø0.110)
4-Ø2.8
(4-Ø0.110)
UNIT :
mm
(INCH)
Air Flow
MODEL
PART NO.
AFB02505LA
AFB02505MA
AFB02512MA
AFB02505HA
AFB02512HA
AFB02505HHA
AFB02512HHA
REV. FUNCTION
-A
-A
-A
-A
-A
-A
-A
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
-R00 / -F00
Rated
Voltage
VDC
5
5
2
5
2
5
2
Operating
Voltage
Range
VDC
4.0 to 5.5
4.0 to 5.5
9.5 to 3.2
4.0 to 5.5
7.0 to 3.2
4.0 to 5.5
7.0 to 3.2
Input
Current
Amp
0.04
0.06
0.04
0.2
0.06
0.6
0.08
Input
Power
Watt
0.20
0.30
0.48
0.60
0.72
0.80
0.96
Speed
R.P.M.
5000
7000
0000
3000
Maximum
Air Flow
m
3
/min
0.024
0.034
0.052
0.068
CFM
0.85
.20
.84
2.40
Maximum
Air Pressure
mmH
2
O
.5
2.8
4.48
7.65
IN H
2
O
0.045
0.085
0.76
0.300
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
6
http://www.deltaww.com
(Ø Ø24
0. .0
94
5)
*
Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic(UL 94V-0)
Lead Wires :
*
UL 06 AWG #26 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 0.5g (0.37 OZ)
*
Rib Type Only & One Side Flange
■
P
& Q CURVE
(AT RATED VOLTAGE)
9.0
7.5
6.0
4.5
■
MOUNTING
OUTLET SIDE
20.0
(0.787)
PANEL CUTOUT
INLET SIDE
20.0
(0.787)
0.36
0.30
0.24
0.18
AFB02505/12XA-A
HH
H
M
Noise
dB-A
8.0
20.0
23.5
28.0
