OH200-71005SV-005.0M datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> OH200-71005SV-005.0M

OH200-71005SV-005.0M: DescriptionSine Output Oscillator, 5MHz Nom, ROHS COMPLIANT, HERMETIC SEALED, RESISTANCE WELDED PACKAGE-5; CategoryPassive components oscillator; File Size337KB，4 Pages; ManufacturerConnor-Winfield; Websitehttp://www.conwin.com/; Environmental Compliance

Download Datasheet Parametric View All

OH200-71005SV-005.0M Overview

Sine Output Oscillator, 5MHz Nom, ROHS COMPLIANT, HERMETIC SEALED, RESISTANCE WELDED PACKAGE-5

OH200-71005SV-005.0M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1209882322
Reach Compliance Code	unknown
Ageing	0.05 PPM/FIRST YEAR
Maximum control voltage	4.5 V
Minimum control voltage	0.5 V
Frequency Adjustment - Mechanical	NO
frequency stability	0.005%
Frequency Stability - Voltage	0.005 ppm
input power	1.1 W
Installation features	THROUGH HOLE MOUNT
Nominal operating frequency	5 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	SINE
Output impedance	50 Ω
Output level	1.125 V
Oven power supply voltage	5V
physical size	36.0mm x 27.0mm x 12.7mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
Preheating power	3.2 W
Maximum warm-up time	5 Minute

Preview

Download Datasheet

View All

Available at Digi-Key**

www.digikey.com

Stratum 3E High Stability

Oven Stabilized Oscillator

OH200-Series

OCXO / VCOCXO

Description

Connor-Winfield’s high

stability OH200- series

are exceptionally precise

frequency standards,

excellent for use in cellular

base stations, test

equipment, Synchronous

Ethernet, VSAT and Stratum

3E applications

These unique OCXO / VCOCXO oscillator

products provide temperature stabilities in the

range of ±3 ppb to ±25 ppb, over the commercial,

extended commercial or the industrial temperature

range. Power requirements are 3W over the

commercial temperature range and 4.5W over the

industrial temperature range. Additionally, excellent

aging is achieved through the use of overtone SC

cut crystals.

The OH200 series is available with CMOS logic

or Sinewave output along with Voltage Controlled

option. These oscillators provide outstanding

phase noise that varies depending on frequency.

Frequencies are available from 5.0 to 40.0 MHz.

Allan Variance specifications are rated for primary

reference standards. Warm up times are on the order

of 5 minutes to 0.10 ppm of final frequency.

2.8

2111 Comprehensive Drive

Aurora, Illinois 60505

Phone: 630- 851- 4722

Fax: 630- 851- 5040

www.conwin.com

US Headquarters:

630-851-4722

European Headquarters:

+353-61-472221

Features

•

Frequency Range: 5.0 to 40.0 MHz

•

OCXO - Fixed Frequency

•

VCOCXO - Voltage Controlled Option

•

3.3 Vdc, 5.0 Vdc or 12.0 Vdc Operation

•

Available Frequency Stabilities:

±3

ppb,

±5

ppb,

±10

ppb or

±25

ppb

•

Available Temperature Ranges:

0 to 70°C, -20 to 70°C,

-40 to 70°C or -40 to 85°C

•

Low Phase Noise / Phase Jitter

•

Available Outputs: CMOS or Sinewave

•

Package: 1.1" x 1.4" x 0.5" (CO-8)

•

RoHS Compliant / Lead Free

Ordering Information

OH200-

Package

OH200- = 1.1x1.4 CO8

Temperature

Range

5 = 0 to 70°C

6 = -40 to 85°C

7 = -20 to 70°C

8 = -40 to 70°C

Frequency

Stability

06 = ±3 ppb *

10 = ±5 ppb *

20 = ±10 ppb

50 = ±25 ppb

{±(Fmax-Fmin)/(2*Fo)}

Supply Voltage

03 = 3.3 Vdc

05 = 5.0 Vdc

12 = 12.0 Vdc

Output Type

C = CMOS

S = Sinewave

OCXO Type

F = Fixed

Freq.

V = Voltage

Controlled

Option

- 012.8M

Output Frequency

Frequency Format

-xxx.xM Min

-xxx.xxxxxxM Max

*Min 1 and Max

6 digits after the

decimal point.

M = MHz

* Frequency stability option 06 is only available for temperature ranges 0 to 70°C and -20 to 70°C.

* Frequency stability options 06 and 10 are only available at frequencies less than or equal to 25MHz.

OH200-61003CF-012.8M = 1.1" x 1.4" x 0.5" CO-8 package, -40 to 85°C temperature range, ±5.0 ppb frequency stability, 3.3 Vdc supply voltage,

CMOS square wave output, fixed frequency OCXO, 12.8 MHz output frequency.

To order a OH200-61003CF with an output frequency of: 6.4 MHz = OH200-61003CF-006.4M

To order a OH200-61003CF with an output frequency of 16.384 MHz = OH200-61003CF-016.384M.

OH200-72005SV-040.0M = 1.1" x 1.4" x 0.5" CO-8 package, -20 to 70°C temperature range, ±10.0 ppb frequency stability, 5.0 Vdc supply voltage,

Sinewave output, voltage controlled output frequency VCOCXO, 40 MHz output frequency.

Example Part Number:

Bulletin

Page

Revision

Date

Cx193

1 of 4

24 April 2018

Attention: System Designers please review Application Note AN2093:

System Design Information and Printed Circuit Board Layout Guidelines for OCXO

Oscillators. @ www.conwin.com/support.html
