Polyester Film Capacitors
LEADED
NAP Series
WRAP AND FILL, NON-INDUCTIVE, EXTENDED FOIL FILM
CAPACITORS, AXIAL LEADS
FEATURES
•
•
•
•
•
•
•
EXTENDED FOIL, NON-INDUCTIVE CONSTRUCTION
LOW DISSIPATION FACTOR
EXCELLENT MOISTURE RESISTANCE
HIGH INSULATION RESISTANCE
TIGHT TOLERANCE
SMALL SIZE AND ECONOMICALLY PRICED
TAPE AND REEL PACKAGING AVAILABLE
SPECIFICATIONS
Operating Temperature
Rated Voltage (VDC)
Capacitance Range
Capacitance Tolerance
Insulation Resistance
Dissipation Factor
Dielectric Strength
-40
o
C to +85
o
C
100V, 200V, 400V 600V, 1000V
0.001 to 1.0
µF
±2% (G), ±5% (J), ±10% (K)
50,000 Megohm Min.
≤
0.0075 (at 1 KHZ)
250% of Rated Voltage for 5 Seconds
PART NUMBER
NAP
103
K
100
TR
Series
Tape/Reel (Optional)
Voltage (DC)
Tolerance Code G =
±2%,
J =
±5%,
K =
±10%
Capacitance code in PFD, first two digits are
significant, third digit is no. of zeros.
E.G. 102 = .001µF, 103 = .01µF, 104 = .1µF,
105 = 1.0µF
dφ ± 0.06
φ
LEAD DIAMETER (mm)
OD
up to 8.0mm
over 8.0mm
d∅
0.6mm
0.8mm
38mm min.
L max.
38mm min.
Dφ max.
φ
STANDARD PRODUCTS AND CASE SIZE TABLE (mm)
Cap. (
µ
F)
0.001
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1.0
100VDC/63VAC
OD
L
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.5
14.0
6.0
14.0
6.5
14.0
6.5
16.0
7.5
16.0
8.5
19.0
8.5
23.0
9.5
27.0
10.5
32.0
12.5
32.0
14.5
32.0
17.0
39.0
200VDC/120VAC
OD
L
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
6.5
16.0
7.0
16.0
7.0
21.0
8.0
21.0
9.0
21.0
9.0
27.0
9.0
27.0
10.5
27.0
11.5
32.0
13.5
32.0
16.5
32.0
Working Voltage
400VDC/200VAC
OD
L
5.0
14.0
5.0
14.0
5.0
14.0
5.0
14.0
6.0
14.0
6.5
16.0
7.5
16.0
7.5
21.0
8.0
19.0
8.0
27.0
9.0
27.0
9.5
33.0
11.0
33.0
12.5
33.0
14.0
37.0
17.0
37.0
600VDC/200VAC
OD
L
5.5
14.0
5.5
14.0
6.0
16.0
7.0
16.0
7.0
16.0
7.0
19.0
7.5
21.0
7.5
27.0
9.0
27.0
10.0
27.0
10.0
33.0
11.5
33.0
13.5
33.0
17.0
33.0
1000VDC/260VAC
OD
L
6.5
16.0
7.0
16.0
6.5
19.0
7.0
19.0
8.0
19.0
8.0
23.0
9.0
23.0
10.0
23.0
11.5
23.0
11.5
32.0
13.0
32.0
14.0
37.0
17.0
37.0
20.0
37.0
®
186
NIC COMPONENTS
www.niccomp.com
www.lowESR.com
www.RFpassives.com
