KDE0502PFB2-8V datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Thermal management products> KDE0502PFB2-8V

KDE0502PFB2-8V: Descriptionfan 5vdc 25x10mm .6W 2.0cfm; CategoryThermal management products; File Size484KB，4 Pages; ManufacturerSunon Fans

Download Datasheet Parametric View All

KDE0502PFB2-8V Overview

fan 5vdc 25x10mm .6W 2.0cfm

KDE0502PFB2-8V Parametric

Parameter Name	Attribute value
Datasheets
KDE Series
KDE0502PFB2-8(V) DC Brushless F
Product Photos
KDE0502PFB2-8V
PCN Obsolescence/ EOL
KD,KDE,GM,PMD Series 25/Nov/2011
Standard Package	100
Category	Fans, Thermal Manageme
Family	DC Fans
Voltage - Rated	5VDC
Size / Dimensi	Square - 25mm L x 25mm H x 10mm W
Air Flow	2.5 CFM (0.071m³/min)
Static Pressure	0.160 in H2O (39.8 Pa)
Bearing Type	Ball
Fan Type	Tubeaxial
Features	-
Noise	24 dB(A)
Power (Watts)	0.60W
RPM	9500 RPM
Terminati	2 Wire Leads
Ingress Protecti	-
Weigh	0.015 lb (6.8g)
Operating Temperature	14 ~ 158°F (-10 ~ 70°C)
Current Rating	0.120A
Voltage Range	4 ~ 6VDC
Life Expectancy	-
Material - Frame	Polybutylene Terephthalate (PBT)
Material - Blade	Polybutylene Terephthalate (PBT)
Other Names	259-1062E0525PFH28---VE

Preview

Download Datasheet
